GB
Autocode-Mini
Getting Started Guide
Original operating instructions
PC Software
Installation Instructions
Original operating instructions
D
Autocode-Mini
De første trin
PC-Software
Installationsvejledning
Westfalia-Automotive GmbH
Am Sandberg 45
D-33378 Rheda-Wiedenbrück
www.westfalia-manuals.com
Pages 2-12
Pages 13-28
Side 2-12
Side 13-28
900 001 400 391 - 001
Advertisement
Table of Contents
Related Manuals for Westfalia Automotive Autocode-Mini
Summary of Contents for Westfalia Automotive Autocode-Mini
- Page 1 Autocode-Mini Getting Started Guide Pages 2-12 Original operating instructions PC Software Installation Instructions Pages 13-28 Original operating instructions Autocode-Mini De første trin Side 2-12 PC-Software Installationsvejledning Side 13-28 www.westfalia-manuals.com Westfalia-Automotive GmbH Am Sandberg 45 D-33378 Rheda-Wiedenbrück 900 001 400 391 - 001...
-
Page 2: Table Of Contents
Menu & icons............................8 Quick Start Guide ........................... 12 Autocode-Mini De første trin Denne vejledning fører dig gennem de første trin i brugen af din Autocode-Mini. Indhold Teknisk support ............................3 Juridiske og sikkerhedsmæssige anvisninger ................... 5 Funktioner og specifikationer ........................6 Indhold .............................. -
Page 3: Technical Help Line
Læs venligst disse oplysninger omhyggeligt, inden du bruger din nye Autocode-mini. Tak fordi du valgte at købe Autocode-Mini. Denne vejledning hjælper dig med at bruge enheden. Hvis der opstår problemer, skal du kontakte vores hotline for teknisk support på følgende... -
Page 4: Legal And Safety Notices
Westfalia-Automotive is not liable for any damage to person or property or any losses incurred as a result of incorrect use of the product. Before using the Autocode-Mini, please ensure that the battery in the vehicle to be coded is sufficiently well charged. Coding being interrupted due to a flat battery can cause problems with control units in the vehicle. -
Page 5: Juridiske Og Sikkerhedsmæssige Anvisninger
Dog fraskrives ansvaret ved uforudsete konsekvenser som følge af brugen af Autocode-Mini. Før du bruger Autocode-Mini, skal du sørge for, at batteriet af det køretøj, der skal indkodes, er tilstrækkeligt opladet. Kodningsafbrydelse på grund af et tomt batteri kan medføre problemer i køretøjet. -
Page 6: Features & Specifications
Features: Specifications: - Numerous Systems covered - ISO High & Low Speed - Supports Vehicles with a 16 pin DLC connector - CAN - Simple Push Button Operation - Fault Tolerant CAN Funktioner: Specifikationer - En række forskellige systemer understøttes - ISO høj og lav hastighed - Understøtter køretøjer med 16-polet OBD-stik - CAN... -
Page 7: Kit Contents
Kit contents Indhold 1. Autocode-Mini handset 1. Autocode-Mini enhed 2. PC data cable 2. PC-datakabel 3. User Manuals 3. Brugermanual Autocode-Mini navigation 4 arrows: Control the cursor around the screen 4 pile: Flytter markøren på skærmen OK Button: Confirms the selected option ESC button: Cancels an OK-knap: Bekræfter... -
Page 8: Menu & Icons
Mini. For more information on how to use this, refer to the System Setup Menu section on the next page. Systemindstillinger – Vælg dette ikon for at tilpasse indstillingerne for din Autocode-Mini. For mere information om denne menu, se Systemindstillinger på næste side. Information Icon – Select this to display software and hardware version information. - Page 9 System Setup Menu Systemindstillinger Clock – Select this to change the date and time of the Autocode-Mini. Ur – Vælg dette ikon for at ændre dato og klokkeslæt for Autocode-Mini. Contact Us – Select this to display the information needed to contact Westfalia, includes telephone number and the support email address.
- Page 10 Data Logging – Select this icon to log communication messages from the vehicle. Used for software support purposes. Dataprotokol – Vælg dette ikon for at gemme meddelelserne. Bruges til software support formål. Beta – Used for engineering purposes. Select this icon to test unreleased software.
- Page 11 Additional Icons used Yderligere ikoner Diagnostic Trouble Codes – Select this to read the Diagnostic Trouble codes on the vehicle you are currently diagnosing. Diagnosefejlkoder – Vælg dette ikon for at læse køretøjets fejlkoder. Erase Diagnostic Trouble Codes – Select this to delete the Diagnostic Trouble codes on the vehicle you are currently diagnosing.
-
Page 12: Quick Start Guide
Quick Start Guide Now you are ready to start using the Autocode-Mini to program towbar modules on the range of cars covered. Remember you can download the latest application list and instruction manuals from www.westfalia-manuals.com. Hurtig brugervejledning Nu kan du med Autocode-Mini programmere styremoduler på alle kompatible køretøjer. Den mest aktuelle applicationsliste og alle instruktioner kan downloades fra www.westfalia-manuals.com. -
Page 13: Autocode-Mini
Autocode-Mini PC Software Installation Instructions This guide provides you with details of how to install the Autocode-Mini PC Software. Software Download: www.westfalia-automotive.com/uk/downloads PC-Software Installationsvejledning Denne vejledning indeholder detaljerede oplysninger om installationen af Autocode-Mini PC software. Software download: www.westfalia-automotive.com/dk/downloads 900 001 400 391 - 001... - Page 14 If you experience any problems then contact Product Support on +44 1225 702104. Autocode-Mini: Download af programmet Følg vejledningen for at få den aktuelle version af Autocode-Mini Suite via www.westfalia- automotive.com/dk/downloads. Hvis der opstår fejl, bedes du kontakte teknisk support på telefonnummeret +45 63 44 22 00.
- Page 15 Follow this procedure if you are a new Autocode-Mini user and your screen displays ‘Not subscribed’. Autocode-Mini installation Følg denne vejledning, hvis du er en ny Autocode-Mini-bruger. 2. Select ‘Download Autocode-Mini PC 1. To download the Autocode-Mini PC software’, select ‘Save File’ and follow the on- software go to the downloads page of the screen instructions to install.
- Page 16 Når softwaren er installeret, skal venligst 'Next'. du vælge 'Next'. 8. Run the Autocode-Mini PC software application 7. You will see the screen ‘Installation from the start menu, select ‘Start’ – ‘Programs’ Complete’ that confirms that the installation –...
- Page 17 Lav evt. et print screen og gem det på skrivebordet. 14. The Autocode-Mini PC software first needs to 13. Connect your Autocode-Mini as per detect the Autocode-Mini. the instructions within the Autocode-Mini update PC software.
- Page 18 Autocode-Mini.* 16. The latest updates are displayed, select 15. The Autocode-Mini PC software will ‘Download’ to update your Autocode-Mini. It will then connect to the Internet to register the be updated with the latest applications. Autocode-Mini and download your first update.
- Page 19 *Hvis meddelelsen " Found New Hardware Wizard" vises, skal du udføre driverinstallationen, før du klikker på "Next". Autocode-Mini Update Procedure / Autocode-Mini opdateringsprocedure 2. Select the option ‘Get Autocode-Mini 1. Run the Autocode-Mini PC software 900 001 400 391 - 001...
- Page 20 4. The software will now download the latest 3. The PC software will now connect your updates that you are entitled to. Autocode-Mini to the download website to confirm your Customer Number & Postcode. 4. Softwaren vil nu downloade de seneste 3.
- Page 21 6. Følg instruktionerne på skærmen. 5. De seneste opdateringer vises. Vælg 'Download' for at opdatere din Autocode-Mini med de seneste opdateringer. 900 001 400 391 - 001...
- Page 22 4. Når du klikker på knappen ‘Tests and checks’ 3. Her kann du ændre dit , kan du kontrollere, om Autocode-Mini fungerer abonnementsnummer og postnummer. korrekt og forbinder sig med www.westfalia- Indtast venligst den e-mail-adresse, hvortil automotive.com for at få...
- Page 23 6. Selecting the ‘Autocode-Mini re-install’ 5. You will be asked to perform these button allows you to force the Autocode-Mini to tests if you experience problems and need to download your latest update again. This can be contact a Product Support representative or used if you think there is a problem with your last engineer.
- Page 24 Application Viewer The Application viewer functionality allows you to view all of the vehicles supported. The Application viewer allows you to narrow your search by Manufacturer, Model and Type and then shows you the coverage for different engine sizes and year. This allows you to identify if a vehicle will be supported prior to coming in to have work done.
- Page 25 Purchase Voucher / Køb af koder (kan pt. ikke købes igennem WAMnet. Kontakt salgsafdelingen i Danmark på +45 63 44 22 00) 2. Select ‘Webshop’. 1. As a registered user, navigate to the Westfalia WAMnet and log in. 2. Vælg ‘Webshop’ (netbutik). 1.
- Page 26 4. The PC software first needs to connect to the 3. Follow the On-Screen Instructions. Autocode-Mini, then it will connect to the Internet to verify your voucher code. 4. Først skal pc-softwaren genkende enheden. 3. Følg instruktionerne på skærmen.
- Page 27 How do I know when an update is available? You will be notified of updates as they become available through the built in notification tool that installed as part of the Autocode-Mini suite. I am getting a message saying ‘File Missing’? The appropriate file is missing.
- Page 28 Technical Specification Dimensions (without cables): 133mm x 78mm x 38mm Cable Length: 1.10m Weight (with cables): 285g Supply Voltage: 8-18Vdc Current Draw for vehicle supply: Up to 150 mA Current draw for USB PC Connection: <100 mA Operating Temperature Range: 0°C to 40°C Storage Temperature Range: 0°C to 50°C...
