Summary of Contents for Kay Home Products Patio-Mate
- Page 1 Patio-Mate ® Owner’s Guide and Assembly Instructions All Models With 45” Wide Panels...
- Page 2 Remove roof, U-channels, rafter tubes and bag of parts from packing carton, verifying parts lists at the end of this manual. • You must erect your Patio-Mate on a level base. The recommended base should be concrete, a wood deck or minimally, a 2" x 4" weather-treated wood base, placed directly on and anchored securely to level ground.
- Page 3 Rafter Bracket (Item 6) then through C-channel hole and driven into furring strip, as shown in Figure 2. ‘C’-channel must be level and centered on horizontal furring strip. ® 7 Panel Patio-Mate ® 8 and 10 Panel Patio-Mate Figure 2 ® 9 and 11 Panel Patio-Mate 2. To assemble the wall: A) Attach a 75"...
- Page 4 B) Set packing carton upright and remove wall panel assembly. Save this packing carton for off-season storage of your ® Patio-Mate C) Unfold the wall assembly like an accordion (Figure 4) and identify top by riv-nut threaded inserts and wide baffle above door.
- Page 5 6. The door panel and the displaced screen panel must be attached in their new locations by sliding in their two hinges and replacing their four hinge retainers. When installing the door retainers remember that 2 of the door retainers are marked ‘L’ for left side and ‘R’ for right side of panel assembly as viewed from outside of Patio-Mate. ®...
- Page 6 The Right Front Stabilizer (Item 13) has a threaded hole nearest the right end of the channel. Install stabilizers over the top of the ® front wall panels so that the threaded holes are facing the outside of Patio-Mate as shown in Figure 7. Number of Panels...
- Page 7 (S3), provided as shown in Figure 8d. Repeat this step for the other corner ® brace at the other front corner of your Patio-Mate Note: Step 3A varies depending on the number of panels on your particular unit. Perform only the step 3A that matches the number of panels on your Patio-Mate ®...
- Page 8 4. Repeat steps 2 and 3 for remaining rafters. 5. Drill a 5/32” diameter hole at each corner of Patio-Mate and fasten a Tie-Down Tab (Item 9), as shown in Figure 11, with #10 x 1/2 Screw (S3) provided, 2" below top of wall panel. See Figure 11...
- Page 9 Grommet on Tab C should be to outside edge of last roof rafter, to center roof on unit. See Figure 16. G) Turn roof valance back over roof. H) Cut remaining cord in half. Figure 14 Figure 13 Figure 15 Figure 16 ® Patio-Mate (7, 8, 8, 10, and 11 Panel Models with 45” wide Panels)
- Page 10 , lace roof grommet strip to tie-down tabs as shown in Figure 17. Tie one end ® of cord to Tie-Down Tab (Item 9) located at center front of your Patio-Mate . Begin lacing grommets to the left of center.
- Page 11 5. To install the door: ® A) Position Door Track(s) (Item 18) 5” from edge of door frame, on the inside of the Patio-Mate as shown in Figure 19 with the overhang in the direction that it is desired to have the door slide.
- Page 12 Clean the roof before storage by using mild detergent and warm water, scrubbing with a medium-bristle brush. Rinse thoroughly. • Store your disassembled Patio-Mate in its carton in a dry heated place. 8. To order parts: A combination parts/accessories order form is included with your screen house. To order, fill it out and send us the entire form.
-
Page 13: Parts List
® Patio-Mate 7, 8, 9, 10, 11 Panel x 45” Wide Panel Parts List Quantity Item Description 7 Panel 8 Panel 9 Panel 10 Panel 11 Panel Roof Item 6 C’-Channel - (L)eft C’-Channel - (C)enter C’-Channel - (R)ight Side “C” Channel - (L)eft... - Page 14 ® Patio-Mate (7, 8, 8, 10, and 11 Panel Models with 45” wide Panels)
- Page 15 ® Patio-Mate (7, 8, 8, 10, and 11 Panel Models with 45” wide Panels)
- Page 16 ® Patio-Mate (7, 8, 8, 10, and 11 Panel Models with 45” wide Panels)
- Page 17 ® Patio-Mate (7, 8, 8, 10, and 11 Panel Models with 45” wide Panels)
- Page 18 ® Patio-Mate (7, 8, 8, 10, and 11 Panel Models with 45” wide Panels)
- Page 19 ® Patio-Mate (7, 8, 8, 10, and 11 Panel Models with 45” wide Panels)
- Page 20 Kay Home Products 90 McMillen Road Antioch, IL USA 60002 (800) 626-5296 This product manufactured under one or more of the following patents: United States: 3,952,463 3,996,706 4,561,227 Canada: 1,021,660 1,165,086 Other U.S. and Canadian patents pending SH 115 Rev 103...
