Model Number
642A12
Performance
Measurement Range
Output
Frequency Range(± 10 %)
Broadband Resolution
Non-Linearity
Environmental
Temperature Range
Electrical
Excitation Voltage
Settling Time(within 2% of value)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight(without cable)
Mounting Thread
Mounting Torque(Stud)
Mounting Torque(hex nut)
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Cable Termination
Electrical Connections(Red)
Electrical Connections(Blue)
Cable Length
Cable Type
[7]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change
specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
4-20 MA OUTPUT VELOCITY SENSOR
ENGLISH SI
0.0 to 2 in/sec pk 0 to 50.8 mm/s pk
4-20 mA 4-20 mA
180 to 60,000 cpm 3 to 1 kHz
0.01 in/sec rms 0.26 mm/s rms
± 1 % ± 1 %
-40 to 185 °F -40 to 85 °C
12 to 30 VDC 12 to 30 VDC
<15 sec <15 sec
8 8
>10 Ohm >10 Ohm
7/8 in x 1.41 in 22.2 mm x 35.8 mm
3.8 oz 108 gm
1/4-28 UNF 1/4-28 UNF
3 to 4 ft-lb 4.1 to 5.4 Nm
2 to 3 ft-lb 2.7 to 4.1 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
Integral Cable Integral Cable
Side Side
Blunt cut Blunt cut
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
10 ft 3.0 m
Polyurethane Polyurethane
[1]
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[2][3]
[4] - Hazardous Area Approval- contact factory for specific approvals
EX
Hazardous Area Approval
EEx ia IIC T4, -40°C≤Ta≤80°
Hazardous Area Approval
EEx nL IIC T4, -40°C≤Ta≤80°
Hazardous Area Approval
DIV I, CL I, II, III, GRPS A-G,
Hazardous Area Approval
- Metric Mount
M
Supplied Accessory : Model M080A163A (1) replaces Model 080A162
[5][6]
- Buffered Analog Signal Output - 100 mV/g (±20%)
RV
Electrical Connector
Electrical Connections(Red)
Electrical Connections(Black)
Electrical Connections(White)
Electrical Connections(Green)
- Temperature Output
TO
NOTES:
[1] Conversion Factor 1 in/sec = 0.0254 m/sec.
[2] 1Hz = 60 cpm (cycles per minute).
[3] Current will fluctuate at frequencies below 5 Hz.
[4] Typical value.
[5] 1/8" hex Allen key required for English version, 3mm hex Allen key required for metric
version.
[6] Stud torque must exceed sensor hex nut torque to ensure proper dismantling.
[7] See PCB Declaration of Conformance PS039 or PS053 for details.
SUPPLIED ACCESSORIES:
Model 080A162 Mounting Stud (1)
Model ICS-4 NIST-traceable single-axis amplitude response calibration from 0 cpm (0 Hz) to
upper 10% frequency for 4 - 20 mA output vibration sensor
Entered: LK Engineer: gs
Date: 10/2/2017 Date: 10/2/2017
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 47262
OPTIONAL VERSIONS
DIV II, CL I, GRPS A-D, DIV II, CL I, GRPS A-D,
ExnL, AExnA, IIC T4 ExnL, AExnA, IIC T4
EEx ia IIC T4, -40°C≤Ta≤80°
C, II 1 G C, II 1 G
EEx nL IIC T4, -40°C≤Ta≤80°
C, II 3 G C, II 3 G
DIV I, CL I, II, III, GRPS A-G,
Exia, AExia, IIC T4 Exia, AExia, IIC T4
Integral Cable Integral Cable
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
Signal Output Pos Signal Output Pos
Signal Output Neg Signal Output Neg
Sales: MC Approved: NJF
Date: 10/2/2017 Date: 10/2/2017
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
Spec Number:
36742
