Summary of Contents for DResearch HydraIP

  • Page 1 Manual HydraIP Recording System...
  • Page 2 Manual Version: 4.1.0 Software/Firmware Version: 4.0.124 Date: 21.08.2015...

  • Page 3: Table Of Contents

    ..........................28 Storage disk removal ..........................29 Battery replacement 5. Stamp stick 6. Signalling of system states ..........................31 Meaning of LED codes LED1 STATE ........................32 LED2 ERROR ........................33 LED3 RECORD ........................33 © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 4 Detailed configuration General ........................69 Variable topology ............................. Vehicle tab ............................73 Rec tab ............................73 Master slave ............................74 Network configuration ............................. Configuration plug-ins ............................. Creating and changing user profiles for the ServiceTool ........................76 © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 5 Wiring diagram for GPIO – SC_2/3 adapter cable ..........................109 Illustrated schematic diagram ..........................110 General schematic diagram MR3060-4 ..........................111 General schematic diagram MR3060-6 ..........................112 General schematic diagram MR3080-8 13. Abbreviations 14. Warranty 15. Copyright © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 6 HydraIP Recording System Index © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 7: Introduction

    ImageFinder NX analysis software. The HydraIP recording system uses a replaceable storage device which can only be removed using an electronic key. The storage device containing the video data is thus protected against unauthorised removal.

  • Page 8: Supported Systems

    § HydraIP adapter cable CONTROL 400 mm AMP standard (for system connector 1) § HydraIP adapter cable GPIO 150 mm AMP standard (for using up to three GPIs: one adapter cable GPIO for system connector 2; when using more than three GPIs: two adapter cables GPIO for system connectors 2 and 3) §...

  • Page 9: Regarding The Manual

    Never try to insert objects through openings of the device because you might cause short- circuits or electric shocks due to the voltage applied within the device. Make sure you check the wiring and all voltages before using the HydraIP recording system! Before connecting the HydraIP recording system make ABSOLUTELY sure all ground potentials are checked.

  • Page 10: Factory Settings

    HydraIP Recording System Introduction Factory settings If no specific settings are made, the HydraIP recording system will operate as delivered with the following factory settings: § PAL system § Frame rate: 6 Frames/sec per channel (applies for analog cameras) § Format: 2CIF (PAL half screen) §...

  • Page 11: Changes / New Functions

    § Communication with fleet management can now be (de)activated (section update: Communication with fleet management) § Note on firmware update in the recording system in a network. (Section update: Firmware update) © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 12: System Variations

    Moreover, it is also possible to pass the video images from one recorder to the monitor output or the data carrier of another recorder. In addition, DResearch systems have the option of independently determining their position in a "loosely" linked car group (changing car order) and automatically adjusting the sequence (topology) of video through- connections accordingly.

  • Page 13: General Installation Manual

    There must be adequate space for inserting the electronic key and removing the storage disk between the HydraIP recording system and other vehicle parts. The width of the gap should be a minimum of 13 cm (measured from the storage disk in removal direction).

  • Page 14: Mounting Of The System

    General Installation Manual Mounting of the system All HydraIP recording systems can be fixed within the vehicle using the integrated screw channels or the mounting plate available as accessory. Using the mounting plate offers the advantage of being able to quickly dismount the HydraIP recording system for service purposes by unscrewing a single screw.

  • Page 15: Power Supply

    General Installation Manual Power supply Make sure the HydraIP recording system is operated at a constant voltage of 24 V DC from a stable source of power (maximum voltage range of 9...32 V). Ensure that the device is switched on and off exclusively by the ignition contact/set-up signal.

  • Page 16: Interfaces

    General Installation Manual Interfaces HydraIP recording systems offer numerous interfaces. Some are implemented via standard connectors (e.g. Video In & Out, USB service), others are integrated in special system connectors (e.g. power supply, GPIO, IBIS). A complete overview of the system can be found in chapter Wiring diagrams.
  • Page 17 Side, front & M12 D-coded Network communication M12 Ethernet* back between HydraIP devices as well as with other systems * Available only for master systems ** MR3080-8M offers 2 video outputs and 4 network connectors © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 18: System Connectors

    Pin 1 of system connector SC_1 CONTROL (directly at the device) = system voltage (24 V DC +) 3.4.3 Adapter cable DResearch offers two adapter cables as optional accessories: the CONTROL adapter cable as well as the GPIO adapter cable. The naming convention is as follows:...

  • Page 19: Gpio Adapter Cable

    SC_3 of the HydraIP recording system. The adapter cable also provides two connectors that may be used to supply power from the HydraIP recording system to external devices (e.g. cameras). Please note that the maximum current available is 2 A.

  • Page 20: System Connector 2 & Gpio Adapter Cable

    For application in trains, this requires the identification of potentials applied in the vehicle that must be used. For application in trains, the HydraIP recording system is constructed galvanically isolated and uses different potentials (enclosure potential, electric potential as well as negative power supply).
  • Page 21 On GPI 1 and 2, use normal buttons (e.g. for alarm & video sequence) in conjunction with the switching voltage of the system and ensure that the correct system connector SC_2 is used! If SC_3 is used by mistake, the system will not respond as desired. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 22: System Connector 3 & Gpio Adapter Cable

    General Purpose Output 4 – common contact 14_11 OUT4_COM 14_12 OUT3_COM General Purpose Output 3 – common contact General Purpose Output 4 – normally closed (NC) 14_13 OUT4_NC 14_14 OUT3_NC General Purpose Output 3 – normally closed (NC) © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 23: Video Inputs And Outputs

    HydraIP Recording System General Installation Manual 3.4.7 Video inputs and outputs HydraIP recording systems provide the option to record analog camera signals. When a network interface is available, digital camera signals may be recorded as well. Model Video inputs Network...

  • Page 24: Operating Voltage And Ignition Signal

    3.4.10 Operating voltage and ignition signal Recording systems of the HydraIP series require a stabilised voltage of 24 V DC for operation. Only use the ignition/setup voltage (12…24 V DC) of the vehicle to switch the HydraIP recording system on and off.

  • Page 25: Digital Switching Inputs (Gpis)

    The GPOs can be set up via the configuration application. More information can be found in chapter Configuration relay. The status of the GPOs can be displayed using the ServiceTool, tab Maintenance. More information can be found in chapter ServiceTool / GPOs. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 26: Power Supply For External Devices

    3.4.14 Audio inputs Recording systems of the HydraIP series use two audio inputs in addition to the video inputs in order to record audio data as well as video data. The audio inputs are located on system connector 3 (SC_3). The audio outputs are not let out via the HydraIP adapter cable GPIO standard.

  • Page 27: Electronic Key

    However, implementation of a locking system using hierarchies is not possible. The STANDARD key code applies to ALL HydraIP recording systems, which have been linked to the standard code. In theory, a storage disk of a third-party system may also be removed using the standard code.

  • Page 28: Storage Disk Removal

    § Remember to remove the key after the storage disk has been removed. § If access is denied, an error is displayed via the LED status display of the HydraIP recording system (LED 1 and 2 flash red 3 times).

  • Page 29: Battery Replacement

    Cd=Cadmium, Hg=Mercury, Pb=Lead (the name is given on the batteries e.g. under the rubbish bin symbol shown on the left). You may deposit your used batteries free-of-charge at the collection points in your community or anywhere else where batteries are sold. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 30: Stamp Stick

    § Connect the stamp stick to the recording device for which the position is to be changed. § The position number will be removed. § Proceed with the new numbering as with assigning position numbers. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 31: Signalling Of System States

    Signalling of system states Signalling of system states HydraIP recording systems offer both configurable and predefined options for signalling system states. Depending on system configuration, certain messages may be output on a connected monitor or assigned to a digital output (GPO).

  • Page 32: Led1 State

    Attempt a restart – the problem may be fixed afterwards. Shutdown and restart may be forced by inserting the electronic key twice in a row. If you still encounter the error, please contact the Technical Support Department. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 33: Led2 Error

    30 s before the storage disk is erased and new data is recorded. For more information on this function, refer to chapter Detailed configuration / General © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 34: Led4 Modem/Fill

    3G online, no data traffic Flashes green 3G online, data transfer in progress Glows yellow WLAN online, no data traffic Flashes yellow WLAN online, data transfer in progress Glows red Incorrect PIN configured Flashes red ATTACH/Dial-up not possible © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 35: Led Function Test At System Start

    RTC error (Real Time Clock error) has occurred. green The recording system returns an incorrect RTC time LED2 & 4 flash green/ (before 2010). All LEDs flash yellow Recording system boot procedure has been started. once. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 36: Led Codes When Using The Electronic Key

    Configuration has been downloaded and saved. showing red However, no new configuration has been applied. Please check whether a new configuration has been supplied on the USB stick. Red chaser light Configuration has not been completed successfully. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 37: Led Codes During Firmware Update

    Data download to USB stick is being started. Yellow-to-green Data download to USB stick is in progress. chaser light Green chaser light Data download to USB has been completed successfully. Red chaser light Data download to USB has not been completed successfully. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 38: On-Screen Display (Osd)

    Signalling of system states On-screen display (OSD) Using the so-called on-screen display (OSD), HydraIP recording systems show additional information on the monitor in the form of symbols and text when specific system events and errors occur. For information on how to configure the OSD, refer to chapter Configuring the on-screen display (OSD).

  • Page 39: Signalling Via Gpos

    Signalling via GPOs It is possible to signal various error messages and system states via the digital outputs (GPOs) of the HydraIP recording system. For information on how to configure the digital outputs (GPOs) refer to chapter Configuration relays. When using factory settings, GPO 1 and GPO 2 are already configured as group detector for errors (GPO 1) and status display (GPO 2).

  • Page 40: Servicetool

    For convenient maintenance of the HydraIP recording system, you can use the HydraIP ServiceTool. The ServiceTool is a part of the firmware of the HydraIP recording systems. You may access the ServiceTool using a network connection and an internet browser. As administrator you can generate user accounts with individual access privileges for secure access to the recording system.

  • Page 41: Creating A Network Connection For The Recording System

    7.1.1 Enabling network discovery To ensure that HydraIP recording systems are listed as network devices, network discovery must be activated in the system settings of your Windows operating system. Connected HydraIP recording systems will then appear as symbols in the Windows network environment. This may take up to 60 seconds.

  • Page 42: Alternative Network Connection

    Firefox or Google Chrome for it to work. 7.1.3 Alternative network connection You will usually connect the HydraIP recording system to your computer via the USB service interface. Alternatively, the connection to the recording systems MR3060-6M and MR3080-8M can also be realised in a different way: §...

  • Page 43: Opening And Closing The Servicetool

    (version 10 or above) or Google Chrome). § Open the HydraIP ServiceTool with a double-click on the network symbol of the recording system. § Alternatively, enter the IP address of the recording system in the address bar of your browser.

  • Page 44: Maintenance Tab

    Status LEDs HydraIP recording systems are equipped with a block of status LEDs on the front side. Four vertical bars on the ride side of the HydraIP ServiceTool header reflect the states of the status LEDs of the recording system.

  • Page 45: Camera And Recording Control

    The browser manufacturers are gradually discontinuing support for plug-ins. For example, the VLC Web plug-in is now no longer supported in Google Chrome. DResearch is working on an alternative, more effective solution for displaying camera images in the HydraIP service tool.

  • Page 46: System Information

    The following may appear in the camera list to indicate recording status: Symbol Meaning Ring mode recording No recording Alarm recording 7.3.3 System information The area System shows the most important data of the recording system at a glance. © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 47 Status unknown Storage device not detected No symbol IBIS detected Status of IBIS IBIS Status unknown IBIS not detected No symbol Counting modules detected Counting modules Status of the counting modules Counting modules not detected © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 48: Gpo Display

    GPI display Recording systems of the HydraIP series are equipped with 6 digital inputs (GPIs). These GPIs may be used to control various functions of the system. For each GPI, you can specify whether it is activated by closing or opening of the respective contact.

  • Page 49: Ibis Display

    7.3.6 IBIS display HydraIP recording systems record all data on the IBIS vehicle bus relevant for the analysis. This data is stored in a database along with video data and other event data. This is done automatically and does not require special configuration.

  • Page 50: Backup Tab

    The browser manufacturers are gradually discontinuing support for plug-ins. For example, the VLC Web plug-in is now no longer supported in Google Chrome. DResearch is working on an alternative, more effective solution for displaying camera images in the HydraIP service tool.
  • Page 51 Individual tracks are shown underneath. Data tracks are visualised as coloured bars in the navigation area, enabling you to immediately recognise alarm recordings. Colour Meaning Green Ring mode recording Pre-alarm recording Pink Alarm recording No data available Grey © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 52 To the end of the recording Time window size Set the resolution of the time bar (time frame of 60 minutes / 24 hours / 7 days). Expand/collapse the time bar view. Time bar view © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 53: Saving Data

    § Confirm your input data by clicking on OK. § If you wish to stop the input process and close the date and time selection menu, click anywhere outside of the calendar window. Setting the duration of data being saved © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 54: Configuration Tab

    This refers to the online configuration. This type of configuration is especially suited to testing during the installation phase of the system. For information on how to edit a configuration in the ServiceTool, refer to chapter Editing a configuration. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 55: Configuration

    HydraIP Recording System Configuration Configuration There are two methods to configure the HydraIP series: online via a network connection or offline via a USB stick prepared accordingly (configuration stick). Offline configuration Using the offline method, a configuration is transmitted via a standard USB stick to the HydraIP recording system.

  • Page 56: Downloading An Existing Configuration

    8.1.2 Downloading an existing configuration If a configuration stick is connected to a HydraIP recording system, the configuration on the device will be read and saved on the configuration stick. To achieve this, proceed as follows: §...

  • Page 57: Managing Configurations

    The tab Overview of all DVR is used to manage all configurations available on the configuration stick. Configurations for several recording systems can be created, edited and released for uploading. Default configurations for all types of the HydraIP recording system are marked with the model number. © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 58 Instead of a duplicated default configuration set, a downloaded configuration set may also be edited. If a configuration set was read from a HydraIP recording system via a configuration stick, it will be displayed in the overview. For information on how to download a configuration, refer to chapter...
  • Page 59 HydraIP Recording System Configuration To upload a configuration to a HydraIP recording system, the serial number of the recording system must correspond to the serial number of the released configuration. If a downloaded configuration is released again after editing, this is guaranteed automatically.

  • Page 60: Creating A Configuration Set/ Fleet Configuration

    Creating from a template § Click on Create. A drop-down box will open. § Click on Use a template, then on the matching model number for your recording system. § An input window will open: © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 61: Example Of A Typical Offline Configuration Procedure

    In addition to creating a configuration set from a template, a downloaded configuration set can also be edited. If a configuration set from a HydraIP recording system has already been selected with the configuration stick, this will appear in the overview. You can learn how to download a configuration in the chapter...

  • Page 62: Uploading A Configuration

    8.1.7 Uploading a configuration § Insert the prepared configuration stick into the USB service interface on the front side of the HydraIP recording system, the configuration has been edited for. (In case of a fleet configuration, you may perform the upload on each HydraIP recording system. The configuration is then applied independently of the label and serial number.)

  • Page 63: Removing A Configuration Set From The List

    8.1.9 Fleet configuration For a fleet using multiple HydraIP recording systems, it is not necessary to create a separate configuration set for every serial number. You may instead create a fleet configuration under the tab Overview of all DVR. It is sufficient to create a single fleet configuration. The resulting configuration stick may then be used on all recording systems of the fleet.
  • Page 64 Excel. § Open the file fleetConfig.txt within the folder of the configuration application with e.g. MS Excel. § You may easily add and manage data in the prepared table. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 65: Editing A Configuration

    Open configuration application. § Mark the configuration you want to edit. § Click on Edit and select a configuration (ORIGINAL, EDITING, RELEASE). § The dialog box for editing the configuration will open as a third tab. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 66: Configuration Editing (In General)

    § Click on Change all. § A drop-down list will appear. Select the column you wish to alter. The data will be applied to the whole column. § The change will only be applied when you save the configuration. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 67: Saving/Resetting A Configuration

    § Before saving, editing of a configuration may be reset via the button Reset. This will cause all changes to be undone. This action will no longer be possible once the configuration has been saved. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 68: Exporting/Importing A Configuration

    Edit, ORIGINAL. § The tab DVR configuration will open. Click on Import. § A window will open. Select the file hydraip.json.export and click on Open. § The configuration will open in the configuration application. § The configuration needs to be released before being installed in Configuration administration.

  • Page 69: Language Setting

    Detailed configuration The following chapter describes the options for the individual configuration of the HydraIP recording system. You may perform the configuration by accessing the tab Configuration in the ServiceTool or via the configuration application on the configuration stick. For information on how to edit tables and input fields in...
  • Page 70 (LED3 will flash yellow for 30 s). If a storage device has been inserted by mistake, you may remove it within 30 s by using the electronic key before its data will be erased. © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 71 If you do use special characters, a red exclamation mark will be displayed and the label will be reset to the last valid name that was saved when you try to save it. In this case, enter a valid label. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 72: Variable Topology

    Variable topology Select vehicle type Variable topology to set up a linked system. You can fully configure a permanently linked system with the user interface. Project-specific plug-ins created during project planning by DResearch are required for a variably linked system.

  • Page 73: Vehicle Tab

    For master-slave systems, the tabs are given the default name master and slave. You can process all settings that apply for all topology recorders in the Vehicle tab. The settings cannot be changed in the Rec tab. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 74: Master Slave

    The tab structure of the configuration application changes. Now the Vehicle tab and two other tabs (Master and Slave) are available. The Topology (overview) contains two recording devices: a master and a slave. No new recording devices can be added. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 75: Network Configuration

    When using the configuration type Generated, a static IP address will be generated using the serial number of the recording system. When using the configuration type Static, you may assign a static IP address to the recording system. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 76: Configuration Plug-Ins

    For example, a factory employee must be able to access the Maintenance tab of the HydraIP recording system, but must not be able to access to video data on account of data privacy.
  • Page 77 § Generate a name and account password for the HTTP user profile. § Assign access privileges using the checkboxes. Configuration This privilege enables the user to configure the HydraIP recording system online. This privilege enables the user to access recorded video data.

  • Page 78: Detectors

    GPIs to control the output of video signals on the monitor. The status of the GPIs is signalled in the ServiceTool under the Maintenance tab. More information can be found in the chapter ServiceTool / GPIs. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 79: Gpo Relays

    The GPO will be set whenever a ring recording is active. The GPO will be set during a live video transmission from the vehicle to the Live video (analog) DResearch fleet management system and whenever live image has been active activated in the ServiceTool, tab Cameras.

  • Page 80: Externe Gpios

    Configuration Externe GPIOs If you have a HydraIP GPIO 4210-E external additional unit, activate it in the tab Detector, section Activate external USB GPIOs. Click on the checkbox Activate external USB GPIOs to open the section to set the GPIOs.

  • Page 81: Set Acceleration Sensor

    HydraIP Recording System Configuration Set acceleration sensor The recording systems for the HydraIP series are fitted with an internal acceleration sensor. More information can be found in the chapter Recording additional data). The vibration detector serves to execute an action when a set threshold for the acceleration data has been exceeded.

  • Page 82: Defining Video/Audio Inputs

    Select a profile to be used for alarm recording. The moment an alarm is triggered (e.g. Alarm profile manually via GPI 1), recording will apply this alarm profil. For information on how to create your own recording profiles, refer to chapter Creating recording profiles. © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 83 Select an alarm profile. The moment an alarm is triggered (e.g. manually via the GPI 1), the recording is done according to the alarm profile assigned here. To learn how to create independent recording profiles, refer to the chapter Create recording profiles. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 84: Creating Recording Profiles

    You may create recording profiles via the tab Video/audio inputs. Using these recording profiles, you can define the quality, resolution and frame rate for video data storage. You may create as many profiles as you like. © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 85 When configuring recording profiles, ensure the selected resolution can be processed by the camera. Failure to do so will result in recording errors. Pay attention to the technical data of your IP camera before creating recording and live stream profiles. © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 86 Using udp there may be gaps in the recording if network load is high. In contrast to tcp, udp does not have any control mechanisms to ensure that sent data arrives. DResearch recommends the use of tcp. IP-Brickcom-MD, IP-Hikvision Select the appropriate screen resolution for recording and output on the monitor.

  • Page 87: Setting Up Recordings

    Old data will be deleted in chunks of one hour based on the FIFO principle (First In First Out). If you set this to 0, recordings will only be deleted once the storage device is full. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 88: Recording Additional Data

    These are also available for analysis during research with ImageFinder NX. HydraIP series recording systems are equipped with an internal acceleration sensor. When the vehicle is started up, the acceleration sensor is recalibrated and independently sets the Z-axis to 1 g .

  • Page 89: Event-Controlled Recording

    For use in vehicles, video output on the driver monitor can be configured to automatically display a black screen on triggering of a digital input (GPI), e.g. by the 3 km/h signal. This avoids distraction of the driver by the surveillance monitor. The signals may be assigned priorities. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 90: Setting Up Video Output

    Layouts for surveillance monitor In addition to outputting individual camera signals on the monitor output of the HydraIP recording systems, it is possible to define layouts in order to display several signals (up to 9) in parallel using so-called multiviews.

  • Page 91: Controlling Video Output Via Gpis

    You may configure control of the video output by GPIs via the tab Video output, section Trigger (GPI). You may set up playback of video signals on the monitor of the HydraIP recording system as well as its automatic or manual control via GPIs.

  • Page 92: Controlling Video Output On The Monitor

    § When the scheme is complete, confirm with OK. Controlling video output on the monitor You may configure control of the video output on the monitor via the tab Video output, section Control of the video output at the monitor. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 93: Configuring The On-Screen Display (Osd)

    In section System events and errors, use the checkboxes to configure which information is to be shown on the OSD. For more information on this refer to chapter Event output. To learn more about the information displayed on the OSD refer to chapter On-screen display (OSD). © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 94: Communication

    Configuration 8.3.6 Communication HydraIP recording system may be integrated into the device cluster of a vehicle using the IBIS vehicle bus, and into the DResearch fleet management via WLAN or 3G. Configuring the IBIS vehicle bus You may configure communication of the recording system using the IBIS vehicle bus via the tab Communications, section IBIS.

  • Page 95: Configuring A Modem

    Using the UMTS modem, data will be transferred via 3G. The internal GPS module may be used by the HydraIP recording system to record and/or transmit GPS data in order to e.g. determine the vehicle position in addition to the live transmission from a moving vehicle or to determine the vehicle position at the time of recording while analysing the video data with the analysis software ImageFinder NX.

  • Page 96: Configuring Wlan

    Communication, section WLAN - Network. Method Disabled: The WLAN module will be deactivated. Choose this setting, if your HydraIP recording system is not equipped with a WLAN module. Static: Assign a static IP address in the mobile networt to the recording system.

  • Page 97: Communication With Fleet Management

    Configuration Communication with fleet management You may configure the connection to the HydraIP fleet management via the tab Communications, section Fleet management. Communication with the HydraIP fleet management will only work if a network connection (e.g. via 3G or WLAN) is available.

  • Page 98: Event Output

    A video signal is missing (e.g. after failure of a camera). Camera error Alarm recording active An alarm recording is currently being made. There is a malfunction in the people counting system. People counting error © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 99: Firmware Update

    § The HydraIP recording system will automatically recognise the update package and start the update process. § The status LEDs of the HydraIP recording system will be showing a yellow chaser light after a few moments. § Wait until ALL LEDs of the chaser light have turned green.

  • Page 100: Troubleshooting

    Ensure all components have been connected properly and powered using correct voltage. Check the configuration of the system Please contact the technical support of the system integrator or the manufacturer when necessary. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 101: Problems Involving Electronic Keys And Storage Devices

    Check whether the storage device can be denied. ejected using another key available. Switch off the HydraIP recording system and try ejecting the storage device using the electronic key's internal battery. If this works, it may indicate a defect on the storage device.

  • Page 102: Problems During Bringing Into Service

    Incorrect configuration of the Ensure the system has been configured system correctly. Faulty connection of audio device Ensure the audio device has been No audio recordings connected properly. Audio device defective Test another audio device. © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 103 Contact the technical support and explain Faulty behaviour of the the problem. The service team of the system or other Incorrect configuration system integrator or manufacturer will problems strive to resolve the issue as soon as possible © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 104: Problems During Offline Configuration

    Firmware and configuration set are Due to the ongoing development of incompatible. the HydraIP recording system, incompatibilities between firmware and configuration application may occur. Use a current firmware and the associated configuration application. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 105: Problems During Online Configuration

    IP address (see been saved, the active browser address may have been assigned. Network configuration). window becomes invalid Close the invalid browser window and check the network environment. Re-establish the connection in a new browser window. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 106: Technical Support

    Before returning the product, you will receive a special code (RMA) for the delivery! The manufacturer will not accept any liability for damage caused during transport or transport insurance. We are unable to accept shipments without freight prepaid. © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 107: Wiring Diagrams

    HydraIP Recording System Wiring diagrams 12 Wiring diagrams 12.1 Wiring diagram for CONTROL – SC_1 adapter cable © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 108: Wiring Diagram For Gpio - Sc_2/3 Adapter Cable

    HydraIP Recording System Wiring diagrams 12.2 Wiring diagram for GPIO – SC_2/3 adapter cable © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 109: Illustrated Schematic Diagram

    HydraIP Recording System Wiring diagrams 12.3 Illustrated schematic diagram © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 110: General Schematic Diagram Mr3060-4

    HydraIP Recording System Wiring diagrams 12.4 General schematic diagram MR3060-4 © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 111: General Schematic Diagram Mr3060-6

    HydraIP Recording System Wiring diagrams 12.5 General schematic diagram MR3060-6 © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 112: General Schematic Diagram Mr3080-8

    HydraIP Recording System Wiring diagrams 12.6 General schematic diagram MR3080-8 © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 113: Abbreviations

    First In First Out Fleet Management System General Purpose Input General Purpose Input and Output GPIO General Purpose Output IBIS Integrated Board Information System Local Area Network On Screen Display Universal Serial Bus Wireless Local Area Network WLAN © 2015 DResearch Fahrzeugelektronik GmbH...

  • Page 114: Warranty

    DResearch Fahrzeugelektronik GmbH. The general terms and conditions are part of the documents supplied by DResearch Fahrzeugelektronik GmbH and are also available in the internet under www.dresearch.de. There will be no additional, express or implied warranty.

  • Page 115: Copyright

    All company names and product names mentioned in this manual are trademarks of the respective owner. All rights reserved. This manual is a publication of DResearch Fahrzeugelektronik GmbH. All rights including translation are reserved. Reproductions of any kind are permitted only with the written permission of the publisher.
  • Page 116 Individual recorder 12 Configurations methods 55 Installation 13 Copyright 115 Installation location 13 Intended use 7 - D - Interfaces 16, 16 IP address 75 Data backup 50 Delete configuration set 63 Delete row in table 66 © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 117 Offline configuration 55, 55, 55, 65 System events 98 Online configuration 41, 54, 55, 65 System information for maintenance 46 On-screen display 38 System requirements 10 On-screen display (OSD) 93 System states 31 Opening of configuration application 56 © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 118 Video output control 91, 92 Video outputs 23 Video sequence 91 - W - Warranty 114 Wiring diagram for "CONTROL" adapter cable 107 Wiring diagram for "GPIO" adapter cable 108 Wiring diagrams 107 WLAN: 94, 96 © 2015 DResearch Fahrzeugelektronik GmbH...
  • Page 119 DResearch Fahrzeugelektronik GmbH Phone: +49 (30) 515932-0 Mail: contact@dresearch-fe.de Web: www.dresearch-fe.de...

This manual is also suitable for:

Mr3060-4Mr3060-4mMr3060-6Mr3060-6mMr3080-8Mr3080-8m

Table of Contents
