- Page 1 Instructivo de 20 kg 1600 W Demolition Hammer Applies for: Code Model 100893 MADE-20NX MADE-20NX Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Parts Assembly and adjustments Keep this manual for future references. Start up The illustrations in this manual are for reference only. They might be different from the real tool. Maintenance Authorized service centers Warranty policy MADE-20NX ENGLISH... -
Page 3: Technical Data
Technical Data MADE-20NX Code 100893 Description 20 kg Demolition hammer Voltage 127 V~ Frequency 60 Hz Current 15 A Power Impact energy 1 600 W 55 Joules Weight 20 kg Tool holder HEX 1 ” Work cycle 50 min work per 20 min rest. Maximum 6 hours per day Conductors 16 AWG x 2C with insulating temperature of 221 °F... -
Page 4: General Power Tool Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For The Use Of Demolition Hammers
Safety warnings for the use of Demolition Hammers Choose the appropriate drill or attachment While operating the demolition hammer CAUTION • The tool is designed to work with bits CAUTION • Hold the tool by its handle and by or accessories with 1 1/8" HEX shanks. Choose the the auxiliary handle. -
Page 6: Parts
Parts Vibration absorber Non-skid handle Switch Ventilation slots Auxiliary handle Aluminum head Retaining lever Cable protector Power cord Tool holder Assembly and adjustments Auxiliary handle Operate the power tool only with the CAUTION auxiliary handle installed (A). • The auxiliary handle can be rotated to any position and tilted back and forth for safe, low-fatigue positioning. - Page 7 Assembly and adjustments Accessory mounting CAUTION To prevent accidents, confirm that the switch is off and disconnect the plug from the power supply. WARNING Wear gloves whenever you change accessories. They can become extremely hot during the operation. • Clean the accessories shanks and apply grease before mounting in the tool chuck (A).
-
Page 8: Start Up
Start up ON AND OFF • To turn on the demolition unit, press “ I ” on the switch. • To turn it off press “O” on the switch. Maintenance Cleaning and care Lubrication • Clean the machine with a soft cloth, moistened with soap •... -
Page 9: Authorized Service Centers
In the event of any problem contacting a Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 0187-8737 to get information about the nearest Service Center. DE TODO PARA LA CONSTRUCCIÓN FIX FERRETERÍAS... -
Page 10: Warranty Policy
. Transportation costs resulting from compliance of this warranty will be covered by For questions or comments, call 800-690-6990. Made in China. Imported by Truper S.A. de C.V. Parque Industrial 1, Jilotepec, Edo. de Méx. C.P. 54240 Stamp of the business.
