If you have the Artist
or Professional
model and are using
LaserSoft SilverFast
4.0, you'll find the
electronic manual for
that scanner
software on the
LaserSoft SilverFast
CD-ROM.
4
Using the Auto Document Feeder - B813162
The auto document feeder (part number B813162) automatically loads
multiple-page documents into your scanner. It is particularly useful for
OCR (optical character recognition) scanning or for creating an image
database. Follow the steps in these sections to install and use the ADF:
Unpacking the Auto Document Feeder
Installing the Auto Document Feeder
Loading Paper in the Auto Document Feeder
Fixing Paper Jams in the Auto Document Feeder

Advertisement

Table of Contents
loading

Related Manuals for Epson B813162

Summary of Contents for Epson B813162

  • Page 1 Using the Auto Document Feeder - B813162 The auto document feeder (part number B813162) automatically loads multiple-page documents into your scanner. It is particularly useful for OCR (optical character recognition) scanning or for creating an image If you have the Artist database.

  • Page 2: Unpacking The Auto Document Feeder

    Unpacking the Auto Document Feeder Make sure that the following items are included in the ADF box. Contact your EPSON dealer if anything is missing or damaged. installation screws auto document feeder...

  • Page 3: Installing The Auto Document Feeder

    The ADF is large, so clear a wide space around the scanner before unpacking and installing it. To use the ADF, you must install EPSON Don’t remove the protective foam block from the ADF’s mounting TWAIN Pro. hardware until you’ve finished installing it.
  • Page 4 3 Position the ADF’s mounting slots over the two mounting screws located at the back of the scanner. Slide the ADF forward slightly until the two holes in front of these slots are aligned with the screw holes at the back of the scanner. Do not remove the protective foam block until you’ve...
  • Page 5 4 Insert the two installation screws that came with the ADF into the screw holes, then tighten the screws with a coin. install the screws in the screw holes 5 Remove the protective foam block from the ADF’s mounting hardware and gently close the ADF.
  • Page 6 6 Attach the ADF’s connector to the scanner’s option interface. Secure the connection by tightening the connector screws. 7 Reattach all the scanner cables and turn on the scanner.

  • Page 7: Loading Paper In The Auto Document Feeder

    Loading Paper in the Auto Document Feeder The ADF can hold up to 30 sheets of the following paper sizes, based on a paper weight of 17 lb and a thickness of 0.2 inch (6.0 mm) or less: Do not feed Checks: photographic sheets or valuable original...
  • Page 8 Follow the steps below to load paper in the ADF: 1 Slide the edge guides all the way out. For checks, move the left edge guide toward the center until it stops, then place your checks in the tray. Move the right edge guide flush against the checks.

  • Page 9: Loading Documents Manually

    Loading documents manually. Don’t open the ADF while scanning. You’ll get an option error 4 Follow the steps in your electronic EPSON TWAIN Pro User’s Guide to and possibly a paper scan your document. feeding error. Loading documents manually You can load documents manually while the ADF is installed.

  • Page 10: Fixing Paper Jams In The Auto Document Feeder

    Fixing Paper Jams in the Auto Document Feeder If there is a paper jam, open the ADF’s cover to see where the paper jam occurred. Pull the jam-release lever forward and slowly pull the jammed paper out of the feeder mechanism. Be careful not to pull too hard on the paper.
