- Page 1 UTILITY SHARPENER CAT 139 4500 CAUTION: FOR YOUR OWN SAFETY; Read and follow all Safety and Operating Instructions before operating this Utility Sharpener.
-
Page 2: General Safety Instructions
SAFETY INSTRUCTIONS GENERAL SAFETY INSTRUCTIONS Operating a Utility Sharpener can be dangerous if safety and common sense are ignored. The operator must be familiar with the operation of the tool. Read this manual to understand this Utility Sharpener. DO NOT operate this Utility Sharpener if you do not fully understand the limitations of this tool. DO NOT modify this Utility Sharpener in any way. - Page 3 SAFETY INSTRUCTIONS (cont.) ALWAYS WEAR EYE PROTECTION. Any power tool can throw debris into eyes during operations, which could cause severe and permanent eye damage. Everyday eyeglasses are NOT safety glasses. ALWAYS WEAR HEARING PROTECTION. Plain cotton is not an acceptable protective device. Hearing equipment should comply with ANSI S3.19 Standards.
-
Page 4: Know Your Utility Sharpener
KNOW YOUR UTILITY SHARPENER The Utility Sharpener is designed with numerous features to quickly and safely sharpen various items around the house and shop. A fine grit grinding wheel is used to produce a sharp and precise cutting edge. Two multi-position tool rests provide a firm work surface at a variety of angles. A water trough is used to keep the grinding wheel and the workpiece cool during sharpening operations., The Utility Sharp- ener additionally has been outfitted with an electrical power switch that permits the grinding wheel to rotate in the Forward and Reverse directions. - Page 5 KNOW YOUR UTILITY SHARPENER (cont.) Sharpening is an easy operation to perform as long as the following items are followed: CLEAN the item to be sharpened prior to beginning any sharpening operations. ALWAYS use the factory bevel (cutting edge angle) as a guide to sharping the tool. SHARPEN the tools prior to starting any job involving the tools.
-
Page 6: Operating The Utility Sharpener
OPERATING THE UTILITY SHARPENER The Utility Sharpener is designed for sharpening knives, scissors, flat chisels, and more. ALWAYS WEAR EYE PROTECTION! Hot sparks may be produced during sharpening operations. The electrical power switch must be in the OFF position. The power cord must be unplugged from the electrical receptacle. Place the Utility Sharpener on flat, firm, and water resistant surface. - Page 7 OPERATING THE UTILITY SHARPENER (cont.) If the item to be sharpened is in good condition, then proceed to lay the item flat on either of the tool rests as shown in Fig. D. Loosen the lock knobs and adjust the tool rest until the original bevel angle of the item to be sharpened is matched.
-
Page 8: Maintenance
MAINTENANCE Turn the power switch “OFF” and unplug the power cord from its power source prior to any mainte- nance. CLEANING With the Utility Sharpener unplugged, rotate the abrasive wheel slowly and inspect for any damage. CAUTION: REPLACE the abrasive wheel if there is any damage at all. FAILURE to replace a damaged wheel can cause serious injury to the operator. -
Page 9: Parts List
PARTS LIST Key No. Description Qty. Key No. Description Qty. Motor Bottom housing 5mm flat washer * Strain relief 4-0.7 x 12mm hex head bolt Plate 3 x 22mm dowel pin Cord clamp 11T pulley 14-1.0mm hex nut Drive belt Capacitor 35/11T pulley 5-0.8 x 55mm carriage bolt... - Page 10 PARTS LIST UTILITY SHARPENER PARTS LIST...
