Modulate Straight 1824 Manual

Modulate Straight 1824
TM
MOD-S-1824
Modulate consists of a set of frames made from aluminium tubes (Ø30 mm) covered
TM
with a printed tension fabric graphic. These frames can be connected together using
formats.
- Thanks to the exclusive MagLink magnetic system built into the structure, you can connect the
frames by simply touching them together.
With the Twist & Lock system, simply position the foot under the structure, turn it and it's locked!
-
- The graphics are very easy to maintain thanks to the crease-resistant and machine washable textile
360° MagLink connector
in each pole. 4 magnets
per structure
Self-locking system
with bungee poles and
push-buttons
Central reinforcement
tube (Ø 18 mm)
Double-sided tension
fabric. Zip system
Item
Code
Structure dimensions
Graphic visual area
Boxed dimensions (2 boxes)
Structure weight
Boxed weight (2 boxes)
Modulate half feet (pair)
MOD-HALF-FOOT-P
218 (w) x 6 (h) x 80 (d) mm
Straight 420 Straight 424 Straight 810
MOD-S-420 MOD-S-424 MOD-S-810
400 mm extension
included
Simple assembly with
numbered frame parts
2 stabilising feet with
Twist & Lock supplied
with each frame
Modulate
bag with dedicated
compartments for the
feet and graphics
Modulate Straight 1824
MOD-S-1824
1818 (w) x 2400 (h) x 400 (d) mm
1800 (w) x 2382 (h) mm
1000 (w) x 245 (h) x 125 (d) + 460 (w) x 65 (h) x 65 (d) mm
8.18 kg
8.65 kg
Spot LED Flood Spot LED Strip
LED-FLOOD-ARM-BDLK LED-STRIP-ARM-BDLK
Straight 820 Straight 824
MOD-S-820 MOD-S-824
TM carry
2400 mm
400 mm
Fixing for 30mm Ø tubing
US903
Curved 820 Curved 824 Slope 1
MOD-C-820 MOD-C-824 MOD-SS-824-01
1800 mm
Aluminium Tubes
Ø 30 mm
4 MagLink connectors
per structure
Central reinforcement
Ø 18 mm
400 (w) x 6 (h) x 80 (d) mm
1818 mm
Slope 2 Straight 1820 Straight 1824
MOD-SS-824-02 MOD-S-1820 MOD-S-1824
PATENT
PENDING
