Summary of Contents for Ross RossGear AFR-7814C
- Page 1 Ross Video Limited AFR-7814C Audio DA Mounting Frame User Manual...
- Page 2 The material in this manual is furnished for informational use only. It is subject to change without notice and should not be construed as commitment by Ross Video Limited. Ross Video Limited assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
-
Page 3: Symbol Meanings
Important Regulatory and Safety Notices Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below to avoid personnel injury and to prevent product damage. Products may require specific equipment, and/or installation procedures to be carried out to satisfy certain regulatory compliance requirements. - Page 4 Notice — Changes or modifications to this equipment not expressly approved by Ross Video Limited could void the user’s authority to operate this equipment.
-
Page 5: Environmental Information
The crossed-out wheeled bin symbol invites you to use these systems. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration. You can also contact Ross Video for more information on the environmental performances of our products. -
Page 7: Installation
AFR-7814C is part of a full line of products within the RossGear Terminal Equipment family of products, backed by Ross Video’s experience in engineering and design expertise since 1974. Should you have a question pertaining to the installation or operation of your AFR-7814C, please contact us at the numbers listed on the back cover of this manual. - Page 8 Overview The design of the mounting frame will more than satisfy the most demanding network considerations. The frame incorporates efficient ventilation and cooling engineering. The mounting frame holds four amplifier modules and one power supply. The frame door is completely removable to provide convenient access in any rack installation position.
- Page 9 (mobile trucks, etc.) it may be desirable to also support the rear of the frame. Rear support brackets (Ross part #FSB-7110) are available for a nominal cost. The rear support bars can be attached to the AFR-7814C in six possible positions (Figure 1.1).
- Page 10 Ventilation To minimize heat buildup and improve module reliability, maintain a blank rack space both above and below each installed chassis. Figure 1.2 Frame Stacking Power Supply PS-7813 The AFR-7814C frames uses a single 20 volt PS-7813 power supply. Turning the power supply off before inserting or removing it from the frame will ensure longer connector life.
-
Page 11: Technical Specifications
+/- 20V Output Current 1.0A Line Regulation 350mV change over full input range Output Ripple <60mVpp For safety reasons, Ross power supplies do not fit into the rack frames of other manufacturers. Height 1.75” (44mm) Width 19” (483mm) Rack Frame Depth 13”... - Page 12 1–6 • Installation AFR-7814C User Manual (Iss. 02)
-
Page 13: Service Information
This chapter contains the following sections: • Warranty and Repair Policy Note — All Ross Video Limited terminal equipment frames include one power supply. A redundant power supply may be installed in all two rack unit frames, if required. AFR-7814C User Manual (Iss. 02) -
Page 14: Warranty And Repair Policy
In the event that your AFR-7814C proves to be defective in any way during this warranty period, Ross Video Limited reserves the right to repair or replace this piece of equipment with a unit of equal or superior performance characteristics. - Page 15 Notes:...
- Page 16 P.O. Box 880, Ross Video Incorporated Ogdensburg, New York, USA 13669-0880 Visit Us Please visit us at our website for: • Company information • Related products and full product lines • On-line catalog • News • Testimonials Ross Video Product Number: 7814CDR-004-02...
