Heat & Cool HCUMR-903 Operation Manual

HCUMR-903

The HCUMR-903 is a Universal Wireless Mo on Remote Controller
with a mo on sensor, programmable for unparalleled energy savings
up to 60% in the opera on of any air-condi oning system that
incorporates a built-in remote-control receiver. HCUMR-903 can
detect human mo on within a 25-foot distance and control
the opera on of an air-condi oner according to the presence
of human mo on and can be programmed to turn the air-
condi oner completely off or have the se ng temperature
increased to a desired se ng for incredible energy savings.
It is capable of opera ng over 6,000 different brands and
models of air-condi oners.
BRAND CODE Se ng
· Find the code from the brand code list. If there are too many
codes for one brand, try the first. If it doesn't work, please try
the second un l it does work. For example: DAIKIN, first
you try '0171', if it doesn't work, try '0172','0173','0174'etc.
· Press the 'SELECT' bu on for 3 seconds and the brand code
on the LCD will flash. Press
code appears. Pressing the 'MODE' bu on allows each press
to increase the code value in increments of a hundred. Then
press the 'ENTER' bu on, the brand code will stop flashing.
Se ng is complete, and you can control your air condi oner.
AUTO-SEARCH Code Se ng
If you don't know the brand of your air-condi oner or can't fi nd
the required brand from the brand code list, please operate as per
the following steps:
· Press and hold the 'SELECT' bu on for 6 seconds, then release it
(the code displayed on the LCD screen increases automa cally).
When the air-condi oner receives the corresponding signal and
produces a buzzer sound, press any bu on to confirm the se n g
quickly.
· A er turning on the air condi oner, try other func on bu on s. If
they don't work, repeat above steps un l they do.
PIR (Passive Infrared) Human Detec on Se ng
The sensor detects emi ed infrared energy from objects
(humans and animals) in the form of heat.
The 'PIR' bu on is used for 'ECO' and 'DELAYED STOP' func ons.
ECO func on is the default se ng for COOLING, HEATING and DRY
modes. The 'DELAYED STOP' func on is disabled when
is in ECO mode.
HCUMR-902
Every me the air condi oner is turned on or switched between
different modes, the ECO func on sign will be displayed. In ECO
Mode, the air-condi oner will automa cally adjust temperature
se ngs once there is no mo on detected within the given me .
In 'DELAYED STOP' mode, the unit will stop running a er the set
me and will not turn back on automa cally when mo on is
detected.
DDWDW
HEAT & COOL - HCUMR-903 - SMART OPERATION MANUAL
or un l the required brand

DELAYED STOP

DELAYED STOP func on is disabled when
Mode. To cancel the ECO set ng and switch to DELAYED STOP ,
press and hold the 'PIR' and 'ENTER' bu ons for 3 seconds,
then press the 'PIR' bu on to enter the DELAYED STOP
se ng.
Pressing the 'PIR' bu on at any me will cancel the DELAYED
STOP func on. When
it will switch back to ECO as the default se ng.
Default se ng: Will turn off the A/C in half an hour
·
without any mo on detec on. This me is adjustable.
Se ng method: Press 'TIMER' and 'SWING' bu ons
·
simultaneously to enter the me se ng mode. Then press
TEMP+ or TEMP- to adjust me, each press will increase or
decrease the se ng for 0.5 hours (range is 0.5 – 4 hours).
Press 'ENTER' to finalize the se ng.
·
Air-condi oning unit will not turn back on automa cally
·
when any mo on is detected.
ECO Func on
ECO func on is the default se ng for COOLING, HEATING
and DRY modes, and is ac ve each me the air condi oner is
turned on or switched between different modes.
To cancel the ECO se ng, press and hold the 'PIR' and
'ENTER' bu ons for 3 seconds.
ECO se ng is invalid in the FAN ONLY (Ven la on) mode.
· Default se ng: A er 15/30 minutes, the temperature rises
to 79/86F or 26/30C in cooling mode, and 68/61F or 20/16F
in hea ng mode. Time and temperature are both adjustable.
· Se ng method: Press 'TIMER' and 'MODE' simultaneously
to enter the me se ng. Then press TEMP+ or TEMP- to
adjust me. Each press increases 5 minutes (range is 5 – 60
minutes). Press 'ENTER' to finalize the se ng.
· Press 'TIMER' and 'FAN' simultaneously to enter the
temperature se ng. Then press TEMP+ or TEMP- to adjust
the temperature of the first ECO period set. Each press
increases the temperature by 2F or 1C (range is 2-57F or 1-14C).
Press'ENTER' and the second period of temperature can be set.
Press 'ENTER' to confirm the se ngs.
· In ECO mode when any mo on is detected, the air-
condi oning unit will reset back to its original se ng.
www.HeatAndCool.com
HCUMR-903
HCUMR-903 is turned OFF then back ON,
HCUMR-903 - 06/2020
