Summary of Contents for Resources Unlimited Hand Held Edge Deletion Tool
- Page 1 Hand Held Edge Deletion Tool Operation Manual P.O. Box 173, Carleton, MI 48117 http://www.resourcesunlimitedcompany.com...
-
Page 2: Table Of Contents
4.3 Changing the Edge Deletion Wheel ..............10 4.4 Changing the Hand Held Edge Deletion Tool Teflon Guide ......12 5. Edge Deletion Hand Held Parts Listing ............13 Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 2... -
Page 3: Safety Information
Use the machine hand held machine SAFETY GUARDS adjust properly to your operation as provided with unit. Make sure no one is standing in front or back of the wheel when starting machine. Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 3... -
Page 4: Hand Held Edge Deletion Tool Set-Up
2.1 Adjusting Tool Air Flow Before using the hand held edge deletion tool, you will need to adjust the air flow through the tool. The air flow has been turned down to a very low setting for shipment. To adjust the tool speed: 1. - Page 5 5. Reconnect the Hand Held Edge Deletion tool to the air supply. Test your setting by edge deleting one edge of a coated piece of glass and measuring using a flat steel ruler. Adjust the position of the wheel using the steps above if necessary.`...
-
Page 6: Using The Hand Held Edge Deletion Tool
3. Using the Hand Held Edge Deletion Tool 3.1 Power The hand held edge deletion tool is designed to be powered by factory compressed air - typically about 90 PSI. The tool uses a 1/4 NPTF male quick-disconnect, requiring a ¼ NPTF female quick-disconnect attached to the compressed air line. - Page 7 5. Place the Hand-held Edge Deletion Tool on the edge of the coated substrate with the coated side of the glass facing up. Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 7...
- Page 8 The coating is removed when the ohmmeter shows no reading. An ohm reading indicates the edge deletion has not been successful. Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 8...
-
Page 9: Maintenance
1. Adjust the arbor so that the wheel is far enough from the white plastic guide so that a regular wire brush can be placed against the entire edge of the wheel but still under the guard. Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 9... -
Page 10: Changing The Edge Deletion Wheel
2. Holding the large air tool nut behind the guard with a ¾” wrench or a crescent wrench, use a 9/16” wrench or socket wrench to remove the nut holding the grinding wheel on the arbor. Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 10... - Page 11 One is mounted on the tool the second is a spare. If you are interested in purchasing wheels from us, please check our website at www.resourcesunlimitedcompany.com for pricing. We can also be reached at 734-654-9728. Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 11...
-
Page 12: Changing The Hand Held Edge Deletion Tool Teflon Guide
See Section 2.2 on Hand Held Edge Deletion Tool Operation for more information on setting the position of the grinding wheel. Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 12... -
Page 13: Edge Deletion Hand Held Parts Listing
E/D Hand Held 3” x ½” Unitized Aluminum Oxide Wheel EDT Plastic Guide E/D Hand Held Teflon Glass Guide Please visit our webpage at www.ResourcesUnlimitedCompany.com for pricing and delivery information on parts. Hand Held Edge Deletion Tool Manual ● Resources Unlimited Company, Inc. ● Rev. 2.11 ● Page 13...
