P1
mz-8 HoTT
◎ GRAUPNER
8th F, 202 Dong, Chunui Techno-Park II, 202,Chunui-
Dong, Wonmi-Gu,
Bucheon-Si, Gyeonggi-do, SOUTH KOREA.
TEL:
070-7863-3675 FAX
E-mail:
service@openhobby.com
FUNCTION
Main function and Channel
Basic 4 Channels and added 6 Channels.
6 Channel is as below.
① LED : ON / OFF
-> CH8
1100us / 1900us
② SPEED : Attitude mode / Rate mode
-> CH5
1100us / 1900us
③ SNAP : Taking pictures
-> CH9
1100us (1500us nothing)
④ RECORD : Film movies
-> CH9
1900us
⑤ FLIP : Use the button on top left of image (360° FLIP)
-> CH10
1100us / 1900us
now channel 10, later channel 7, (Alpha 150 not active
in autopilot mode as soon as GPS is connected it will be
channel 6 coming home function)
⑥ 3D / EASY : Use the button on top right of image
(180° revolution and additional function)
-> CH6
1100us / 1900us
CH6, when AKRO3D is adjusted in the receiver, for
normal flight mode with GPS (Alpha 150) it will be
autopilot function
:
070-7863-3670
⑦ 2.4GHz Quad with 6-Axis Gyro
⑧ You can attach camera and video module by
choosing option. You can take a video on the radio
using Photo & Video button.
mz-8
Frequency band
Modulation
Transmission output
Temperature range
Antenna
Battery
Operating voltage
Output voltage
Dimension
Weight
2400MHz ~2483.5 MHz
FHSS
about 1mW
-10 ... +55 ℃
Monopole Antenna
AA Size x 3 pcs
3.6 ... 4.8V
about 50mA
151 x 134 x 63.7 mm
about 260g (Incl. battery)
