RACING CHAIR
Operating Instructions & Parts Manual
Model
RCHW100
SFA Companies
10939 N. Pomona Ave. Kansas City, MO 64153
customerservices@heinwerner-automotive.com
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Printed in Taiwan
© May 2014
RCHW100-M0_052014
Advertisement
Table of Contents
Summary of Contents for HEIN-WERNER AUTOMOTIVE RCHW100
- Page 1 RACING CHAIR Operating Instructions & Parts Manual Model RCHW100 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 customerservices@heinwerner-automotive.com Read this manual and follow all the Safety Rules and Operating Instructions before using this product. Printed in Taiwan © May 2014...
- Page 2 ASSEMBLY BREAKDOWN M8 * 7 PCS WASHER M8 * 20MM * 3 PCS 5/16" * 25MM * 4PCS 1/4" * 3/4" BOLT * 6 PCS 6MM * 1 PCS SPRING WASHER * 4 PCS` BACK CUSHION * 1 PCS HANDLEBAR * 1 PCS M8 WASHER * 3PCS M8 * 20MM * 3 PCS SEAT * 1 PCS...
- Page 3 ASSEMBLY INSTRUCTIONS Attach the #2 left handlebar on the #4 seat, secure with screw- driver. Repeat the same process to assemble the #3 right handlebar on the #4 seat. Assemble #7 gas height adjustment with #6 dust cover and then insert into #5 plate.
- Page 4 OPERATING INSTRUCTIONS SEAT BACK INCLINATION ADJUSTMENT This picture shows the position of the control shaft for seat back angle adjust- ment. In normal situations, it is located at the level as the picture indicates. Pull the control shaft outward to release the seat back.
- Page 5 REPLACEMENT PARTS Individual replacement parts are not available for this product. For questions call or write: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. E-mail: customerservices@heinwerner-automotive.com ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, SFA Companies, Inc. will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage.
