Owner's Manual

4 foot, 3-Point Mounted Snow Blower

270 West Park Avenue

Huron, SD 57350

866-526-5682

Serial Number: _____________________

Date of Purchase: ______________

Page | 1

7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers

Red Devil Snow Blowers is a registered trademark of Lankota Group.

Need help?

Do you have a question about the RED23304 and is the answer not in the manual?

Questions and answers

Summary of Contents for RED DEVIL RED23304

Page 1 4 foot, 3-Point Mounted Snow Blower 270 West Park Avenue Huron, SD 57350 866-526-5682 Serial Number: _____________________ Date of Purchase: ______________ Page | 1 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 2 See Figure 1. 1. The Red Devil Snow Blower will arrive on a pallet as shown in Figure 1. In the accompanying box you will find the following: Part Numbers Description Quantity RED56SH-0007 Chute Gear Ring RED56SH-0006 Half-Moon Chute Gear Clamps...
Page 3 Page | 3 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 4 7. Slide motor and gear assembly forward to make a tight fit with the chute gear and tighten bolts attaching the motor to the housing as shown in figure 5. Figure 3 Figure 2 Figure 4 Figure 5 Page | 4 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 5 1. Attach the orbital motor (RED10110) to the back of the snow blower housing with the shaft of the orbital motor pointed up. 2. Attach the fittings and hoses to the motor. Page | 5 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 6 4. Adjust the hook (RED56MSH-0034) so the handle sits in an ideal location for your tractor - this will act as a holder for your handle during operation. Page | 6 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 7 Attach the hydraulic cylinder (RED2010111) to the snow blower chute (RED56SH). Then attach the hydraulic hoses and fittings to the cylinder. Page | 7 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 8 Use the diagram for assembly assistance Attach the manual chute deflector assembly (REDMSH0030) to the snow blower chute (RED56SH). Page | 8 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 9 2. This serial number is required for product registration and is needed for all warranty issues. (As shown in Figure 7) Figure 7 Page | 9 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 10 Make sure the hydraulics are in good working condition by testing each function and checking for leaks. Use Synthetic 80/90 Gear Oil In Gear Box Page | 10 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 11: Operating The Snow Blower
Make sure to read and understand every safety sign on your machine. Stay clear of the blower at all times while the PTO is engaged. Page | 11 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 12 Once the driveline is installed, slowly lift the snow blower thru the complete arc of 3-point mount. Make sure driveline does not bottom out anywhere throughout the arc. Make sure the shields do not separate. Page | 12 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 13 If your driveline is making a chattering noise you may be running at too steep of an angle. You may need to move the mounting out to lessen the angle.  Drivelines must always have at least 5” of overlap. Grease before operating your snow blower. Page | 13 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 14 Red Devil warranties its new products to be free from defects in material and workmanship for a period of one (1) year following the date of purchase by the retail purchaser. Red Devil warrants genuine Red Devil replacement parts and components to be free from defects in material and workmanship for a period of ninety (90) days following the date of purchase or the remainder of the original equipment warranty period, whichever is longer.
Page 15 Page | 15 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 16 Refer to Figures 8a and 8b. Page | 16 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 17 Figure 8a. Figure 8b. Page | 17 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 18 Page | 18 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 19 Page | 19 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 20 Page | 20 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 21 Shown with optional MANUAL Shown with optional HYDRAULIC chute deflector (RED56MSH0030) chute deflector (RED56HYD0030) Page | 21 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
Page 22 Page | 22 7/25/2017 www.reddevilsnowblowers.com | Red Devil Snow Blowers Red Devil Snow Blowers is a registered trademark of Lankota Group.
