- Page 1 EQUATOR MSR1280 UNDERWATER LIGHT Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Preface ............................... 3 Features ............................. 3 Precautions ............................3 Components and Connectors ......................4 Installation ............................5 Controls .............................. 7 Appearance ............................9 Technical Specifications ........................9 Warranty ............................10 Declaration of Conformity ......................... 11 ________________________________________________________________________________... -
Page 3: Preface
PREFACE PRECAUTIONS The EQUATOR MSR1280 series of a compact • The underwater light has to be installed and ultra-thin underwater light with built-in driver is used in accordance with the instructions of designed to use the latest LED lighting this manual only. -
Page 4: Components And Connectors
COMPONENTS AND CONNECTORS (1) Optical window High-grade polycarbonate glass optical window. (2) Underwater light casing Aluminium bronze or stainless steel casing with fixing holes and cable gland. (3) Cable The 4-pole multi-core cable to connect the 12-24Vdc power supply and optional remote control or switch. -
Page 5: Installation
• 4 x fixing screw M6x80 with nut M6 and washer • Operating Instructions with Declaration of Conformity and Warranty conditions The EQUATOR MSR1280 has to be installed on a flat surface on the stern or both sides of the hull of the vessel. - Page 6 (not included). The power supply voltage has to be from 10 - 30Vdc. Note: • The main DC power supply of the vessel has to be switched off before installation. The underwater light has to be connected as described in the table below: EQUATOR MSR1280 FUNCTION wire colour + DC Power Supply...
-
Page 7: Controls
The multi-color underwater light can be controlled by using the momentary-switch. When the light is turned-off the color or mode of lighting can be changed sequentially by pressing the momentary switch for 2 seconds: EQUATOR MSR1280 Sequence of lighting Custom Color... - Page 8 If the multi-color light is used only with one of the fixed color of lighting the synchronization is not necessary. DMX512 control The built-in ASTEL protocol enables the network connection to control the lights with the standard DMX512 protocol by using optional MXU01 or MXU03 interfaces.
-
Page 9: Appearance
Lens angle 60° Optical window High-grade polycarbonate glass Luminous flux 1.900 lm White color temperature 6.000 - 10.000 K ASTEL protocol default address Operating temperature -10°C - +50°C Casing Aluminium bronze (AB2) or stainless steel (SAE316L) Protection IP 68 Dimensions... -
Page 10: Warranty
WARRANTY 1. The equipment manufactured by ASTEL d.o.o. is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY according to IEC Guide 22 and EN 45014 Manufacturer's Name: ASTEL, Podjetje za projektiranje, proizvodnjo in trgovino, d.o.o. Manufacturer's Address: Dutovlje 138 6221 Dutovlje Slovenija declares that the products 1. Underwater Light EQUATOR MSR1280 Item, Product Name and Model Number:... - Page 12 ASTEL d.o.o., Dutovlje 138, 6221 Dutovlje, Slovenia Tel: +386 5 7310771, +386 5 7310772 Fax:+386 5 7310789 info@astel-marine.com E-mail: www.astel-marine.com Web:...
