All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the
date of purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are
notified in writing of such defect and the goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly
maintained and used in accordance with instructions. We shall not be responsible for any labor charges or any loss, injury or damages
whatsoever, including incidental or consequential damages. The sole and exclusive remedy shall be limited to the replacement of the
defective goods. Before installation and use, the purchaser shall determine the suitability of the product for his intended use and the
purchaser assumes all risk and liability whatever in connection therewith. Where permitted by law, the implied warranty of merchantability
is expressly excluded. If the products sold hereunder are "consumer products," the implied warranty of merchantability is limited to a
period of three years and shall be limited solely to the replacement of the defective goods. All weights stated in our catalogs and lists
are approximate and are not guaranteed.
NOTICE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT.
Zurn Smart Occupancy Light
Installation, Operation, Maintenance
and Parts Manual
Patented and Patents Pending
For Commercial and Institutional Use Only
Z-LIGHT-W1
LIMITED WARRANTY
Advertisement
Table of Contents
Summary of Contents for ZURN plumbSMART Z-LIGHT-W1
- Page 1 Zurn Smart Occupancy Light Installation, Operation, Maintenance and Parts Manual Patented and Patents Pending For Commercial and Institutional Use Only Z-LIGHT-W1 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov...
- Page 2 This Page Intentionally Left Blank...
-
Page 3: Fcc Guidelines For Human Exposure
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Zurn is not responsible for any radio or television interference caused by using other than specified or recommended cables and connectors or by unauthorized changes or modifications to this equipment. -
Page 4: Radiation Exposure Statement
INDUSTRY CANADA This device complies with RSS-247 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera- tion. -
Page 5: Recommended Tools
Zurn Smart Occupancy Light Part List Mounting Bracket Extension Pole (If ordered) Occupancy Light Recommended Tools 1/2”, 7/64” Drill Bits Screwdriver Hand Drill Applicable Screw Anchor For installing surface (Optional) #8 or M4 FV781 Rev. A 10/14/21 Page 1... -
Page 6: Prepare For Installation
Partition Floor * Zurn Smart Occupancy Light should be mounted at a max 8’6” feet above the floor, either directly to the ceiling or using a Zurn Smart Occupancy Light Mount - Extension Pole. FV781 Rev. A 10/14/21 Page 2... -
Page 7: Power Supply
Voltage drop in the overall run must not exceed 1V at max load. Do not exceed 6A (40 lights) of total load per supply. If using stranded wire, Zurn recommends using appropriately sized crimp-on ferrules at all terminations to ensure connection integrity and to prevent accidental short-circuit conditions. - Page 8 We will activate your plumbSMART™ account, set up your enterprise, and give you guidance on how to register each connected product as you install it. We will send a confirmation email with a link, or you can go to plumbsmart.zurn.com to log into your plumbSMART™ account for the first time.
- Page 9 Step 2 When installing the ceiling mount bracket, it is very 6” important to ensure that the arrow is pointing toward the Arrow inside of the stall, perpendicular to the stall door. In most Pointing cases, the arrow should be pointing directly towards the Perpendicular to water closet.
- Page 10 The ceiling mount bracket is now installed and it’s time to assemble the unit. If using a Zurn Smart Occupancy Light Mount - Extension Pole, feed the power cables though the extension tube until you see them visibly protruding out of the bottom extension cone.
- Page 11 Step 5 Connect the power block to the cables. The power block is located inside the top of the Zurn Smart +12v Occupancy Light. Both connections are linked so either side can +12v be used for a single light or both sides when daisy chaining the lights off a single power supply.
- Page 12 Step 6 Once the cables are secured into the power block, attach the light unit to the bottom of the light mount / extension pole or ceiling mount bracket. If using a light mount / extension pole, ensure that you are holding the extension tube when twisting on the light unit to prevent any misalignment from assembly.
- Page 13 Device will ask to reboot to apply settings. Select “Yes”. Follow on screen instructions: a. Navigate to https://plumbsmart.zurn.com/admin/displays on your computer, phone, or tablet. b. Enter the displays unique activation code. c. If activation takes longer than 2 minutes, reload the web page on your computer and get a new code from the display.
-
Page 14: Troubleshooting
Device mounted too high Zurn recommends the mounting surface of the light be at most 8’6” from the floor. Ensure device is installed at correct height. Device not communicating Device too far from gateway or another light Ensure device is within 60ft of another light or gateway. - Page 15 This Page Intentionally Left Blank...
- Page 16 ZURN INDUSTRIES, LLC W. Freshwater Way, Milwaukee, WI U.S.A. 53204 · Ph. 1-855-ONE-ZURN, Fax 919-775-3541 In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292 ZURN.COM Rev. A Date: 10/14/21 C.N. No. 143368 Prod.
