Acorn T700 Operational Instructions

130 pcb controller
Hide thumbs

Advertisement

Table of Contents

Last Update 01.01.2018
130 PCB CONTROLLER
T700
Operational Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T700 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acorn T700

  • Page 1 Last Update 01.01.2018 130 PCB CONTROLLER T700 Operational Instructions...
  • Page 2 Step 1 Setting the Hand of the Powered Swivel Step 2 Setting the Remote Control Type Step 3 Setting the Auto Hinge Step 4 Saving the Settings SETTING THE HINGE pg 12 Wiring the Hinge Control Box Pairing the Hinge Control Box to the T700 PCB...
  • Page 3 T700 PCB Powered Options Wiring Diagram T700 PCB Connectors Wiring Diagram T700 Seat Powered Swivel Wiring Diagram T700 PCB Rail Wiring Diagram T700 Rail to Hinge Control Box Diagram T700 Hinge Control Box Wiring Diagram FAULT CODES pg 23 Normal Operation...

  • Page 4: Power Supply (Psu)

    15 ACV transformer. CHARGING SYSTEM The T700 uses 2x 12V / 7Ah Lead-Acid batteries. Once the stairlift is parked on a charge point, the T700 charging system will re-charge the batteries, until reaching its maximum capacity. Acorn Stairlifts User Manual...

  • Page 5: Hibernation Mode

    REMOTE CONTROL OPERATION The T700 operates using Infrared (IR). This is selected using the “Setting Mode” menu. • Infrared This technology requires line of sight with the stairlift to operate correctly.

  • Page 6: Volume Control

    T700 - CONTROLLER INFORMATION VOLUME CONTROL The T700 features 3 volume settings. FAULT CODES The T700 PCB comes with Unified fault code system for easier diagnosis. POWERED SWIVEL OPTION The T700 has the powered swivel operating circuit integrated. No extra PCBs are required in the carriage when using this option.
  • Page 7 T700 - CONTROLLER INFORMATION POWERED FOOTREST OPTION The T700 has the powered footrest operating circuit integrated. No extra PCBs are required in the carriage when using this option. Powered Footrest Operation: At the top or bottom of the stairs, after the stairlift comes to a stop, use the buttons located along both sides of the seat to lower or raise the footrest as required.
  • Page 8 Release and press the remote again if a journey to the bottom is required. MANUAL HINGE OPTION - AUTO PARKING FUNCTION When a manual hinge is used with the T700 system, it will require the addition of a limit ramp to assist parking the lift. Operation: •...

  • Page 9: Setting Mode

    SETTING MODE ACCESSING SETTING MODE Accessing to “Setting Mode” is required to: 1. Select RH or LH installation 2. Select IR or RF remote operation 3. Select Auto Hinge or complete setting process To access “Setting Mode”: Position the lift away from the charge point Turn the Key Off Turn the Key Off...
  • Page 10 SETTING MODE STEP 1 - SETTING THE HAND OF THE POWERED SWIVEL Up call for RH Down Call for LH The lift will display RH or LH, continue to step 2 STEP 2 - SETTING THE REMOTE CONTROL TYPE With RH or LH showing on the display, use the arm toggle to select the remote control type.

  • Page 11: Step 4 - Saving The Settings

    SETTING MODE STEP 3 - SETTING THE AUTO HINGE / MANUAL HINGE With showing on the display, use the arm toggle to select if the lift has or not an Auto Hinge section. Down call Up call to to select select Auto Manual Hinge...
  • Page 12 Red wire to the battery. Connect the hinge control box to the main supply socket in the wall. PAIRING THE HINGE CONTROL BOX TO THE T700 PCB Position the lift away from the charge point Turn the Key Off...
  • Page 13 SETTING THE AUTO HINGE The lift will clear P9 automatically Press the Black Button and hold until LED 3 fl ash rapidly CHANGES / ALTERATIONS CHANGING THE VOLUME ON BEEPER Position the lift away from the Turn the charge point Key Off Press the UP Press...
  • Page 14 CHANGES / ALTERATIONS ACCEPTING ANOTHER REMOTE Position the lift on the Turn the charge point Key Off Press and hold Press the DOWN the down button cover safety edge (E4) remote CLEARING REMOTES AND THE HINGE ADDRESS Position the lift on the Turn the charge point Key Off...
  • Page 15 DOWN footplate edges (E1 E2) for 4 seconds. READING THE BATTERY VOLTAGE, SOFTWARE VERSION AND SERIAL NUMBER OF THE T700 PCB The display will relay diagnostics in the following order: 1. Higher battery voltage 4. U2 software version 2. Lower battery voltage 5.
  • Page 16 T700 PCB WIRING DIAGRAMS T700 PCB STANDARD WIRING DIAGRAM...
  • Page 17 T700 PCB WIRING DIAGRAMS T700 PCB POWERED OPTIONS WIRING DIAGRAM...
  • Page 18 T700 PCB WIRING DIAGRAMS T700 PCB CONNECTORS WIRING DIAGRAM...
  • Page 19 T700 PCB WIRING DIAGRAMS T700 SEAT POWERED SWIVEL WIRING DIAGRAM...
  • Page 20 T700 PCB WIRING DIAGRAMS T700 PCB RAIL WIRING DIAGRAM...
  • Page 21 T700 PCB WIRING DIAGRAMS T700 HINGE RAIL TO HINGE CONTROL BOX DIAGRAM...
  • Page 22 T700 PCB WIRING DIAGRAMS T700 HINGE CONTROL BOX WIRING DIAGRAM...

  • Page 23: Fault Codes

    FAULT CODES NORMAL OPERATION Feature T700 A130 Lift ready to use (beeping as no charger present) Lift moving up (arm) Lift moving down (arm) Lift moving up (remote) Lift moving down (remote) Lift waiting for auto hinge to operate AT CHARGING POINTS...
  • Page 24 FAULT CODES ERROR REPORTS Feature T700 A130 Safety edge activated (footrest down/under plate) Check for obstructions or footrest wire connections. Safety edge activated (footrest up) Check for obstructions or footrest wire connections. Safety edge activated (cover down) Check for obstructions or wire connections.
  • Page 25 Hand wind lift up to reset OSG (see hand winding instructions in the user manual). HARDWARE ERRORS Feature T700 A130 Safety grounded to chassis (SW1 safety circuit) One or more switches from the SW1 safety circuit is grounded to chassis.
