- Page 1 GSM DIALER PX100D Installation and programming manual Firmware version: 1.17.2 Issue: GPRS transmitter configurator 1.3.63 version: Release date: 29.09.2016...
- Page 2 DECLARATION OF CONFORMITY EBS Ltd. Co. hereby declares that mentioned product conforms to all the applicable requirements of EU and Council Directive No.1999/5/EC of 9 March 1999. copy Conformity Declaration available http://www.ebs.pl/certyfikaty/ This crossed out dustbin symbol indicates that when the last user wishes to discard the product at the territory of European Union, it shall be utilized at an authorized and approved collection point.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ....................6 FUNCTIONAL AND TECHNICAL PARAMETERS ............7 ASSEMBLY AND WIRING ..................8 QUICK START PROCEDURE ................10 OPERATION ....................12 CONFIGURATION PROGRAM ................13 6.1. INITIAL REMARKS ..................13 6.2. COMPUTER – REQUIREMENTS ............... 13 6.3. - Page 4 7.3.1.1. NO/NC ..................25 7.3.1.2. Delay [ms] ..................25 7.3.1.3. Lock ..................... 26 7.3.2. Outputs configuration ................26 7.3.2.1. Activation mode and timing ............. 27 7.3.2.2. Conditions ..................27 7.3.2.3. Additional conditions ............... 27 7.3.3. Advanced outputs control............... 28 7.3.3.1. Output 1/Output 2/Output 3 ............
- Page 5 10.7. SIM CARD ERROR..................58 10.8. SYSTEM ERROR..................58 CHANGELOG ....................59 PX100D_Manual_en-1.17.2i10 Page 5 / 59...
-
Page 6: Introduction
GSM mobile phone network. Data transmission follows via voice channel of GSM connection (in ContactID or SIA standards), GPRS data connection or SMS. PX100D is extended version of PX100N with GSM dialling functionality added. -
Page 7: Functional And Technical Parameters
- 100mA, 1 relay output – optional Digital interface: RS232 (RxD, TxD, RTS, CTS lines) Outputs functionality: - loss of GSM signal, - full control over PX100D outputs via server or SMS commands Built-in power supply: Voltage supply: (allowable range: 16-20V signaling... -
Page 8: Assembly And Wiring
ASSEMBLY AND WIRING SWITCH Connections of wires shall be made with due care to prevent any faults or dead shorts. Places of connections shall be protected against weather conditions. According to the above figure terminals of transmitter shall be connected to: PX100D_Manual_en-1.17.2i10 Page 8 / 59... - Page 9 Terminal Connection description Two terminals for AC power supply (output from AC AC, AC transformer) +ACU Positive terminal of battery Device ground, common for other input and output Connection of monitoring sabotage switch (the second switch contact connected to COM terminal). Signal inputs.
-
Page 10: Quick Start Procedure
QUICK START PROCEDURE NOTE : Do not insert SIM card before the first programming of transmitter as it may block the card if PIN code is required for the card. This chapter is purposed for users that possess experience regarding GPRS data transmission systems and who work with OSM.2007 server. - Page 11 1111 █ SERVER=89.123.115.8 █ PORT=6780 █ APN=general.t-mobile.uk █ █ Where: █: space character PX100D_Manual_en-1.17.2i10 Page 11 / 59...
-
Page 12: Operation
OPERATION Default communication mode of PX100D device is voice channel over GSM network. A device can be also configured to maintain communication via GPRS network or SMS messages. Communication mode is configurable – see chapter 7. for more information. As a result the transmitter may be used only at the territory covered with mobile phone operator network. -
Page 13: Configuration Program
To install program an installation wizard shall be started that performs installation in default place C:\Program Files\EBS\. During installation process shortcuts on screen and Windows menu are created. If device is to be used for the first time it shall be programmed with the above program and after this procedure the SIM card may be inserted into the device. -
Page 14: File-> New
Main menu is available as icons on fast access bar: 6.3.1. File-> New Opens new set of parameters. Editing of configuration parameters is possible. Select type of device – PX100D. 6.3.2. File -> Open If file contains saved settings, they may be used to program next device. Firstly a catalogue where file has been saved shall be chosen and then name of file shall be provided. -
Page 15: File -> Save
6.3.3. File -> Save During programming many devices in different configurations, it is not necessary to have in mind each one as it may be saved on hard disc or floppy disk under any name and it may be loaded later on. This function save on disc any information from configuration wizard window. -
Page 16: Remote Connection
Click on [Add] button to confirm settings. Connections shall be saved (and inserted in table). From this time on program shall enable wires connection with device and reading, and saving of parameters in PX100N memory will be possible. 6.3.5.2. Remote connection As provided above the device and software makes for complete configuration with GPRS link or CSD channel. -
Page 17: File -> Automatic Device Settings Backup
Note : Remote configuration with CSD canal is possible if option of CSD data sending has been activated both for SIM card inserted into a device and SIM card installed in GSM modem. Beside, PX100D transmitter must enable to pick up data calls (see GSM modems authorized phones Programming with CSD is also possible if OSM.2007 system has been installed, and... -
Page 18: Operations -> Read
EEPROM module. There is also possibility to set correct time into LX device. Correct saving is confirmed with message on a screen. 6.3.10. Operations -> System events history „Events history” provides information about last events stored in PX100D device memory. See chapter 7.12 Events history PX100D_Manual_en-1.17.2i10... -
Page 19: Operations -> Device Monitor
6.3.11. Operations -> Device monitor “Device Monitor” provides real-time information on PX100D device state. See chapter 7.11 Device Monitor 6.3.12. Operations -> Restore default settings If operation “Read” finishes with error message (e.g. if access code is unknown) it is possible to come back to default settings by selecting “Restore default settings”. -
Page 20: Programmable Parameters
PROGRAMMABLE PARAMETERS Parameters available in configuration program are divided into groups: Access, Transmission, Inputs/Outputs, Monitoring, Restrictions, SMS Notifications, Link control, RS-232, Dialer and Firmware. Every from these groups will be described in detail in next part of this manual. 7.1. ACCESS 7.1.1. -
Page 21: Gprs Test Time
SMS mode after unsuccessful attempts Define number of reconnections to server. If during all reconnections fail the device will go into SMS mode. In this mode PX100D will try to make connection with server, according to interval defined in clause 7.1.3.3 7.1.1.4. -
Page 22: User Password
In this filed you determine how many times device will try to make connection to server. If connections fail, PX100D after execution of some connection will start procedure of connection to back up server. This option is active only if we define parameters of backup server. -
Page 23: Backup Server Parameters
7.1.4.4. Number of connection attempts In this field you determine how often device will try to make connection to backup server. If connections fail, PX100D after execution of some connection will back to procedure of connection to primary server. 7.1.4.5. -
Page 24: Restricted User's Service Code
PUK card only (with use of any GSM mobile phone). Factory setting of PIN in PX100D transmitter is 1111. 7.2. TRANSMISSION For the purpose of maximum security of transmission, data is encrypted with AES key. -
Page 25: Inputs/Outputs
7.3. INPUTS/OUTPUTS Transmitter has got 8 signal inputs and additional input for sabotage signal switch- key connection. Module is equipped with three outputs: indicating sabotage and an additional two. In/Out option enable programmable configuration so that transmitter operates pursuant to requirements of the user. All inputs of the device are 24 hour alarm inputs. -
Page 26: Lock
7.3.1.3. Lock With this option you can lock any input of module, and as a result condition changes on this input will be ignored and will not be reported to monitoring station. Lock may be persistent or temporary. In case of temporary lock – user can set lock time and number of input state changes after which lock occurs. -
Page 27: Activation Mode And Timing
7.3.2.1. Activation mode and timing Thanks to this option you may choose output operation mode. There are two operation modes available: o Bistable- connection follows for indefinite time- up to the moment of disconnection of power for module or remote command which switches output off, o Monostable- connection follows for time defined by user - every 100ms. -
Page 28: Advanced Outputs Control
Available network: input disturbance causes actuation of sabotage output if sending of information to server is possible. Note : Both outputs may be controlled by SMS commands. 7.3.3. Advanced outputs control The user is able to determine an alternative course of action to go over basic outputs configuration function described in 7.3.2 Outputs configuration. -
Page 29: Output 1/Output 2/Output 3
7.3.3.1. Output 1/Output 2/Output 3 These columns define which signals are to influence the status of a specific output. Possible choices are: o Do Nothing – output status will be not changed (default action) o Turn on output – output will be permanently turned on o Turn on output temporarily –... -
Page 30: Sms On / Sms Off
7.4.2. SMS On / SMS Off In this column you define signals that may be reported at monitoring station with SMS messages – when there is no connection with server over GPRS. There is possibility to send information on alarms (input state change from rest to action status) and on returns of input state from action to rest (normalization). -
Page 31: Sleep When The Battery Voltage Less Than
7.4.5. Sleep when the battery voltage less than If you check an option “Sleep when the battery voltage less than” battery voltage threshold field becomes available. The threshold is used when the transmitter goes into Sleep mode. Due to the characteristics of the battery Sleep mode ensures reliable operation of the device when the battery is the only source of power at the time. -
Page 32: Restrictions
7.5. RESTRICTIONS 7.5.1. SMS Authorized phones User may restrict remote access to the device (via SMS) for determined phone numbers. A list of numbers (up to 5 numbers) determines which numbers are allowed to connect with transmitter. Available options: Deny all: means no available telephone communication. ... -
Page 33: Gsm Modems Authorized Phones
7.5.2. GSM modems authorized phones For connections on CSD channel the user may limit remote access to device from GSM modems. Only numbers on the list (up to 5) allow for communication with transmitter. Available options: Deny all: means no available telephone communication. ... -
Page 34: Sms Notifications
SMS event s sent to server SMS events sent to user Answers to commends Limitation are defined by providing two values: SMS maximum number: determines maximum number of sent SMS messages per time unit (see SMS counter reset). This option protects user against sending too much of SMS messages e.g. -
Page 35: Events
Position cursor on line with phone number and click on “Remove” button to remove number from table. Click on “Remove all” button to remove all numbers from table. 7.6.2. Events This tab is to configure and edit SMS messages to be sent to listed phone numbers. may define SMS text message with reference to any event from the list (Tamper: Activation, Restore;... -
Page 36: Sms User Tests
Note: o The total number of characters for all SMS messages shall not exceed 2000 o Mark any mistake and delete by pressing [Del] button o You may copy one text and paste to other field. 7.6.3. SMS user tests SMS user tests sent to specified phone numbers are carried out independently of the operating mode of the device (GPRS / SMS / GRPS &... -
Page 37: Status
7.6.4. Status The device provides for remote enquiry about the status. Edit in this field message text that is to be sent to the user as a reply to command regarding status checking. Telephone numbers authorized to send enquiry about status are defined in option Restrictions >Authorized SMS phones. -
Page 38: Sms Forward
7.6.5. SMS Forward The device is able to forward received SMS messages according to the specified rules. This function may be helpful when GSM operator sends messages with account state to SIM card installed within device. In this window you may provide up to 5 rules. -
Page 39: Link Control
7.7. LINK CONTROL These options enable automatic action of device if communication with monitoring station was broken up. It relates to situations when device lost connection to GSM network or if GPRS transmission is impossible. 7.7.1. Activate this function (mark [Turn On] field) to get access to parameters determining action of device if outside GSM network. -
Page 40: Gprs
7.7.2. GPRS Activate this function to (mark [Turn On] field) to get access to parameters determining action of device if GPRS connections is lost. Define time limit after which transmitter shall reconnect to network. Enter time limit in field [Reset after] and provide this value in minutes. Next define action that the device shall perform. -
Page 41: Rs-232
7.8. RS-232 7.8.1. Serial port settings The device has been equipped with RS-232 serial port to enable obtaining additional information. To make use of this link it is required to define its parameters. For this purpose select parameters from the below table: Parameter Value Baud rate (bits/sec) -
Page 42: Advanced Port Options
7.8.3.1. Disable data receiving This option allow for lock of data received from device connected to RS-232 port of transmitter. It is used in case of failure or situation when PX100D is being used to control the device. 7.8.3.2. Disable data sending This option allow for lock of data sending to device connected to RS-232 port of transmitter. -
Page 43: Dialer
7.9.1. General options These options allows configuration of Dialer of PX100D device. It is possible to completely turn off Dialler or to enable communications with one or two receiving stations. Communication parameters can be defined with following options: ... -
Page 44: Events For The First/Second Station" Tabs
7.9.2. “Events for the first/second station” tabs These tabs allows configuration of events codes in ContactID or SIA protocols. Codes can be generated automatically after entering account number. PX100D_Manual_en-1.17.2i10 Page 44 / 59... -
Page 45: Firmware
7.10. FIRMWARE The device is equipped with built in bootloader that allow for updating and change of firmware. During programming all information is displayed in respect of carried out operation. Follow the following procedure: a) Launch configuration program b) Open “Firmware” option of configuration wizard c) Open file with new firmware (click [Open] button to locate where file is). -
Page 46: Device Monitor
7.11. Device Monitor “Device Monitor” provides real-time information on PX100D device state. To use this function PX100D must be connected to PC computer with LX-DATA cable (using DEBUG plug). Correct RS232 port must be chosen in “Port” field. “Device monitor”... -
Page 47: Events History
„Events history” provides information about last events stored in PX100D device memory. PX100D dialer is able to save 192kB of data, which is about 8000 events. It is possible to read the history of both using a GPRS connection and RS232. - Page 48 PX100D_Manual_en-1.17.2i10 Page 48 / 59...
-
Page 49: Device Programming
DEVICE PROGRAMMING Programming device possible with “GPRS transmitters configurator” configuration program described in chapter 5. To program the device establish connection with a device. Depending on connection mode there are two ways for programming. 8.1. LOCAL PROGRAMING To program a device locally follow the procedure: a) Connect PROG joint (on printed circuit) with COM computer port by way of service wire, defined in option ->... -
Page 50: The First Programming Of Device
In second case according to description in chapter 6.3.5.2 –GPRS Link , it is required to define remote link on grounds of OSM.2007 parameters. As OSM.2007 collects (and transmits) information exclusively from devices saved in data base, the first operation during remote programming is proper registration of the device. This procedure has been described in OSM.2007 Operation Manual. -
Page 51: Receiving Of Sms Message
RECEIVING OF SMS MESSAGE GPRS module receives specially prepared SMS. If received SMS is not correct it will be automatically cancelled and device will not operate any action. As mentioned above the device may operate in two modes: with a new encoded protocol ... - Page 52 UN=un APN user name. Parameter should be obtained from mobile network operator. If APN user name contain space sign put it with “” e.g. “my user name”. PW=pw APN password. Parameter should be obtained from mobile network operator. If APN password contain space sign put it with “”...
-
Page 53: Old Protocol
Samples of commands and device reaction: Parameters setting: 1111 █ APN=general.t-mobile.uk █ SERVER=89.112.43.78 █ PORT=6670 █ SMS=500445566 SMSPERIOD=25 █ Parameters verification: Inquiry: 1111 █ GETCFG Answer: 89.112.43.78:6670,general.t-mobile.uk ██ Inquiry: 1111 █ GETPARAM=SMS Answer:: 500445566 9.2. OLD PROTOCOL The following format of message is acceptable allowing to send some commends with one SMS (every command shall be separated with SPACE): SERVICE CODE COMMAND... - Page 54 IN5_OFF 5 input unlock IN6_OFF 6 input unlock IN7_OFF 7 input unlock IN8_OFF 8 input unlock INA_OFF All inputs unlock (with no impact on sabotage input) KILL GSM modem reset In PX protocol output OUT3 can not be switch remotely. PX100D_Manual_en-1.17.2i10 Page 54 / 59...
-
Page 55: Led Diodes Indication
Logging to GSM 10.2. GSM RANGE GSM network signal level is indicating on LED diodes after pressing button on PX100D device PCB. Signal level is showing until releasing button. According to drawing signal level is indicated in following manner: ... -
Page 56: Data Transmission
When there is no GSM network coverage only red LED will be on. No GSM network coverage indication 10.3. DATA TRANSMISSION During data transmission a green diode indicates data transmitting. Additionally, two yellow LEDs are indicating type and state of transmission. LED Diodes Description Green... -
Page 57: Device Buffer Indication
In case of ContactID transmission, each LED blink means reception of Kissoff signal. 10.4. DEVICE BUFFER INDICATION PX100D is indicating state of events buffer when there is no outgoing transmission. Pending event indication for Monitoring Station #2 Pending event indication for Monitoring Station #1: (if used): - LED turn on –... -
Page 58: Firmware Updating
10.6. FIRMWARE UPDATING During programming bootlader operating is indicated. If error follows during updating there is bootloader in device and another programming of device is possible. LED Diodes Description Green No program in device (1/sec) Software updating Received firmware 10 sec decoding 10.7. - Page 59 11. CHANGELOG Date / Version Description 23.12.2008 / 0.1 First release (ver. 0.1) 15.01.2009 / 0.5 GPRS transmitters configurator update 11.03.2009 / 0.6 Device state signaling description update 01.04.2009 / 1.10i7 Updated list of commands 25.11.2009 / 1.11i8 Firmware update and GPRS configurator update 05.02.2010 / 1.11i9 User SMS tests, reading history via GPRS, battery voltage threshold for Sleep mode...
