X13 Yoga Gen 2
Hardware Maintenance Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ThinkPad X13 Yoga Gen 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lenovo ThinkPad X13 Yoga Gen 2

Summary of Contents for Lenovo ThinkPad X13 Yoga Gen 2

  • Page 1 X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 2 Appendix A “Notices” on page 93. Second Edition (May 2021) © Copyright Lenovo 2021. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

  • Page 3: Table Of Contents

    How to remove the system management 1080 Coin-cell battery ... . password ....© Copyright Lenovo 2021...
  • Page 4 1090 Speaker assembly ... 2030 Camera cable, privacy shutter, and camera board ....1100 Pen charger cable.

  • Page 5: About This Manual

    About this manual This manual contains service and reference information for ThinkPad X13 Yoga Gen 2, machine types (MT): 20W8 and 20W9. Use this manual along with the advanced diagnostic tests to troubleshoot problems. Important: • This manual is intended only for trained service technicians who are familiar with ThinkPad products. Use this manual along with the advanced diagnostic tests to troubleshoot problems effectively.
  • Page 6 X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 7: Chapter 1. Safety Information

    Do not use this type of mat to protect yourself from electrical shock. © Copyright Lenovo 2021...

  • Page 8: Safety Inspection Guide

    • Find the room emergency power-off (EPO) switch, disconnecting switch, or electrical outlet. If an electrical accident occurs, you can then operate the switch or unplug the power cord quickly. • Do not work alone under hazardous conditions or near equipment that has hazardous voltages. •...

  • Page 9: Handling Devices That Are Sensitive To Electrostatic Discharge

    0.1 ohm or less between the external ground pin and the frame ground. b. The power cord should be the authorized type specified for your computer. Go to: https://support.lenovo.com/partslookup c. Insulation must not be frayed or worn. 4. Check for cracked or bulging batteries.

  • Page 10: Grounding Requirements

    – When working on a double-insulated or battery-operated system, use an ESD common ground or reference point. You can use coax or connector-outside shells on these systems. – Use the round ground prong of the ac plug on ac-operated computers. Grounding requirements Electrical grounding of the computer is required for operator safety and correct system function.
  • Page 11 DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 12 X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 13 PERIGO PERIGO Chapter 1 Safety information...
  • Page 14 PERIGO PERIGO PERIGO PERIGO PERIGO X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 15 PERIGO DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 16 DANGER DANGER DANGER DANGER VORSICHT X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 17 VORSICHT VORSICHT VORSICHT VORSICHT Chapter 1 Safety information...
  • Page 18 VORSICHT VORSICHT VORSICHT X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 19 Chapter 1 Safety information...
  • Page 20 X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 21 Chapter 1 Safety information...
  • Page 22 X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 23 Chapter 1 Safety information...
  • Page 24 X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 25 Chapter 1 Safety information...
  • Page 26 X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 27: Chapter 2. Important Service Information

    UEFI BIOS downloads. Telephone numbers for Lenovo Support are available at: https://pcsupport.lenovo.com/supportphonelist • System Disassembly/Reassembly videos that show the FRU removals or replacements for the Lenovo- authorized service technicians are available in the following support site: https://www.lenovoservicetraining.com/ion/...

  • Page 28: Important Notice For Replacing A System Board

    Dynamic Configure To Order (CTO) This model provides the ability for a customer to configure a Lenovo solution from a web site, and have this configuration sent to fulfillment, where it is built and shipped directly to the customer. The machine label and eSupport will load these products as the 4-character MT, 4-character model and 2-character country code.

  • Page 29: Fru Identification

    FRU identification Use Lenovo eSupport to identify major FRUs, FRU part numbers, and FRU descriptions for a product at an MT - serial number level. Examples of major FRUs are hard disk drive, system board, and liquid crystal display (LCD).
  • Page 30 X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 31: Chapter 3. General Checkout

    • Plastic parts, latches, pins, or connectors that have been cracked or broken by excessive force • Damage caused by liquid spilled into the system • Damage caused by the improper insertion of a PC card or the installation of an incompatible card © Copyright Lenovo 2021...

  • Page 32: Checkout Guide

    Note: If you are unable to isolate and repair the problem yourself after running the program, save and print the log files created by the program. You need the log files when you speak to a Lenovo technical support representative.

  • Page 33: Uefi Diagnostic Program

    If the computer you are servicing is not installed with the UEFI diagnostic program, you can download a bootable diagnostic program from the Lenovo Support Web site. The bootable diagnostic program enables you to view system information and test some hardware devices in your computer, such as memory, storage devices, the LCD, and system board buses.

  • Page 34: Power System Checkout

    To check the ac power adapter, do the following: 1. Connect the computer to a power outlet and turn on the computer. 2. Start Lenovo Companion program or Lenovo Vantage, and then click Hardware Settings ➙ Power. The ac power adapter information is displayed.

  • Page 35: Checking The Coin-Cell Battery

    Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and provides no warranties for failures or damage arising out of their use. Move your pointer to the battery-status icon in the Windows notification area to check the battery status. The battery-status icon displays the percentage of battery power remaining and how long you can use your computer before you must charge the battery.
  • Page 36 X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 37: Chapter 4. Related Service Information

    Reset or restore Windows To reset or restore Windows, refer to the information below： • Use Lenovo recovery options. 1. Go to https://support.lenovo.com/HowToCreateLenovoRecovery 2. Follow the on-screen instructions. • Use Window recovery options.

  • Page 38: Supervisor Password

    If it has, it can be used for access to the storage drive. If no admin Nvme password is available, neither Lenovo nor Lenovo authorized service technicians provide any services to reset either the user or the admin Nvme password, or to recover data from the storage drive. The storage drive can be replaced for a scheduled fee.

  • Page 39: How To Remove The Nvme Password

    Nvme passwords, or to recover data from the storage drive. To put the system back to operational status, the only Lenovo and Lenovo-authorized service solution would be to replace the storage drive (HDD) or SSD with a scheduled fee.

  • Page 40: How To Remove The System Management Password

    How to remove the system management password To remove a system management password, do the following: If no supervisor password has been set, do the following to remove the system management password: 1. Turn off the computer and disconnect ac power. 2.

  • Page 41: Hibernation Mode

    • The ring indicator (RI) is signaled by a serial device or a PC Card device. • The time set on the resume timer elapses. Note: The computer does not accept any input immediately after it enters sleep mode. Wait a few seconds before taking any action to reenter operation mode.

  • Page 42: Numeric Error Codes

    Note: For a device not supported by diagnostic codes in the ThinkPad notebook computers, see the manual for that device. Numeric error codes Table 1. Numeric error codes Symptom or error FRU or action, in sequence 0177 System board Bad SVP data, stop POST task—The checksum of the supervisor password in the EEPROM is not correct.

  • Page 43: Error Messages

    Beep errors Lenovo SmartBeep technology enables you to decode beep errors with your smartphone when a black screen occurs with beeps from your computer. To decode the beep error with Lenovo SmartBeep technology, do the following:...
  • Page 44 The following section describes some beep errors and the corresponding solutions. Note: Do not attempt to service a product yourself unless instructed to do so by the Customer Support Center or product documentation. Only use a Lenovo-authorized service provider to repair your product. Error codes...

  • Page 45: No-Beep Symptoms

    If the LCD you are servicing has two or less visible defective pixels, it should not be considered faulty. However, if the LCD has three or more visible defective pixels, it will be deemed as defective by Lenovo and it should be replaced.

  • Page 46: Intermittent Problems

    1. Ensure that the computer is connected to ac power. Then, press the power button for about seven seconds to turn off the computer. 2. Press Fn, left Ctrl, and the power button at the same time. If the computer displays five solid colors in sequence across the entire screen, it indicates that the LCD functions normally.
  • Page 47 g. PC cards 4. Turn on the computer. 5. Determine whether the problem has been solved. 6. If the problem does not recur, reconnect the removed devices one at a time until you find the failing FRU. 7. If the problem remains, replace the following FRUs one at a time (do not replace a nondefective FRU): a.
  • Page 48 X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 49 © Copyright Lenovo 2021...

  • Page 50: Chapter 5. Use The Keyboard Shortcuts

    Chapter 5. Use the keyboard shortcuts The special keys on the keyboard help you work more easily and effectively. Invoke the special function printed as an icon on each key or standard function of F1–F12 function keys. FnLock indicator on: standard function FnLock indicator off: special function Enable / disable speakers Decrease volume...
  • Page 51 Scroll contents Send system request Enter sleep mode To wake up the computer, press Fn or the power button. Go to beginning Go to end Chapter 5 Use the keyboard shortcuts...
  • Page 52 X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 53: Chapter 6. Locations

    Locating computer controls and connectors This topic introduces the locations of the computer controls and connectors. Front view Webcam privacy shutter (Camera IR Camera*/Camera* cover) Microphone Touch screen Power button with or without fingerprint ® TrackPoint pointing stick reader © Copyright Lenovo 2021...
  • Page 54 ® USB-C (Thunderbolt™ 4) power Thunderbolt 4 connector (USB-C) connector Always on USB 3.2 connector Gen 1 HDMI™ connector Lenovo Integrated Pen Smart card reader Nano-SIM-card tray Audio connector Security-lock slot USB 3.2 connector Gen 1 * for selected models...

  • Page 55: Locating Frus And Crus

    CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You can find a list of CRUs for your product in this Hardware Maintenance Manual. An electronic version of this manual can be found at https:// support.lenovo.com...

  • Page 56: Major Frus

    Major FRUs Note: Depending on the computer model, your computer might look different from the illustration above. X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 57 Miscellaneous parts (See “Miscellaneous parts” on page 54.) Power cord ac power adapter for selected models Note: The Lenovo factory recovery USB key is used to restore the Microsoft Windows operating system. They might not come with the computer, and a user might order them from https://pcsupport.lenovo.com/ , though additional shipping and handling fees might apply.

  • Page 58: Lcd Frus

    LCD FRUs X13 Yoga Gen 2 Hardware Maintenance Manual...
  • Page 59 Note: Depending on the computer model, your computer might look different from the illustration above. Table 6. LCD FRUs FRU descriptions Self-service Optional- service CRU LCD panel assembly Strip cover Hinges Human presence sensor module Antenna kits Sensor board LED cable ThinkShutter assembly Camera board LCD rear-cover assembly...

  • Page 60: Miscellaneous Parts

    • Spec Connector and cable guide This section provides information for Lenovo authorized service technicians to help identify connectors and cables for replacement purpose. To view each FRU and the exploded illustration of the computer, see “Major FRUs” on page 50 and “LCD FRUs ” on page 52.
  • Page 61 Item Connector (location) Internal cable required Cable connection Sensor board connector Sensor board cable Connect one end of the sensor board cable (internal) to the LCD panel assembly and the other end to this connector. Wireless-WAN card slot Insert the wireless-WAN card into this slot. (internal) Fingerprint reader connector Fingerprint-reader cable...

  • Page 62: Looking Up Fru Information

    Internal cable required Cable connection Nano-SIM card slot (external) Insert a nano-SIM card into this slot. Looking up FRU information For detailed FRU information, including part numbers, descriptions, and substitution part numbers, go to: https://support.lenovo.com/partslookup X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 63: Chapter 7. Fru Replacement Notices

    CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You can find a list of CRUs for your product in this Hardware Maintenance Manual. An electronic version of this manual can be found at .

  • Page 64: Sensor Calibration

    • They are harder to tighten. Do the following when you service this machine: • Keep the screw kit in your tool bag. For the part number of the screw kit, go to https://support.lenovo.com/ partslookup • It is recommended to use new screws.

  • Page 65: Retaining Serial Numbers

    3. Type WindowsCalibrationTool.exe –calibrate a –minimal –updateiss –primaryonly to create a Update.bat file as shown. Then, copy the file to the same folder of the Windows Sensor Calibration Tool. 4. Run the Update.bat file as Administrator. 5. Lay down the computer with the LCD panel facing up as shown and then follow the on-screen instructions to start the calibration process.

  • Page 66: Retaining The Uuid

    Maintenance Key. Note: Only an authorized Lenovo service technician can access the above Web site. 3. Restart the computer. 4. When the logo screen is displayed, press Esc. The ThinkPad Config Information Update Utility interface is displayed.
  • Page 67 6. Type y under Change UUID. OK? [Y/N], then press Enter. A new UUID is created and written. If a valid UUID already exists, it is not overwritten. Chapter 7 FRU replacement notices...
  • Page 68 X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 69: Chapter 8. Removing Or Replacing A Fru

    CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You can find a list of CRUs for your product in this Hardware Maintenance Manual. An electronic version of this manual is available for downloading at https:// support.lenovo.com...

  • Page 70: Before Servicing The Computer

    Attention: The system board is sensitive to, and can be damaged by, electrostatic discharge (ESD). Before touching it, establish personal grounding by touching a ground point with one hand or by using an electrostatic discharge strap. Before servicing the computer Carefully read this topic before servicing the computer.

  • Page 71: 1020 Nano-Sim-Card Tray (For Selected Models)

    1020 Nano-SIM-card tray (for selected models) Removal steps of the nano-SIM-card tray 1030 Base cover assembly For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 • “1020 Nano-SIM-card tray (for selected models)” on page 65 Removal steps of the base cover assembly Chapter 8 Removing or replacing a FRU...
  • Page 72 Applying labels to the base cover assembly The following illustration and table show the label areas and what labels are applied in each area. Taiwan / India GEO label Serial number label Asset tag* China non CECP GEO label China CECP label Asset tag* IMEI label Country label...

  • Page 73: 1040 Built-In Battery

    • “1030 Base cover assembly” on page 65 Important notices for replacing a built-in battery Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and provides no warranties for failures or damage arising out of their use.

  • Page 74: 1060 Wireless-Wan Card (For Selected Models)

    Removal steps of the I/O bracket Step Screw (quantity) Color Torque M2 × L5 mm, flat-head (2) Black 0.181 Nm (1.85 kgf-cm) 1060 Wireless-WAN card (for selected models) For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 •...

  • Page 75: 1070 M.2 Solid-State Drive

    If your computer is installed with a hybrid solid-state drive (with Intel Optane memory), go to https:// to know the details on how to replace it. support.lenovo.com/docs/tg_ssd Removal procedure Type one: Step...

  • Page 76: 1080 Coin-Cell Battery

    Type two: Torque Step Screw (quantity) Color M2 × L2 mm, large flat (2) Silver 0.181 Nm (1.85 kgf-cm) 1080 Coin-cell battery For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 • “1020 Nano-SIM-card tray (for selected models)” on page 65 •...

  • Page 77: 1090 Speaker Assembly

    Removal steps of the coin-cell battery When installing: Ensure that the coin-cell battery connector is attached firmly. 1090 Speaker assembly For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 • “1020 Nano-SIM-card tray (for selected models)” on page 65 •...

  • Page 78: 1100 Pen Charger Cable

    1100 Pen charger cable For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 • “1020 Nano-SIM-card tray (for selected models)” on page 65 • “1030 Base cover assembly” on page 65 • “1040 Built-in battery” on page 67 Removal steps of the pen charger cable Step Screw (quantity)
  • Page 79 • “1020 Nano-SIM-card tray (for selected models)” on page 65 • “1030 Base cover assembly” on page 65 • “1060 Wireless-WAN card (for selected models)” on page 68 Removal steps of the thermal fan assembly Note: Loosen the screws in ascending alphabetical order ( ) as shown.

  • Page 80: 1120 Nfc Card And Nfc Cable (For Selected Models)

    1120 NFC card and NFC cable (for selected models) For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 • “1020 Nano-SIM-card tray (for selected models)” on page 65 • “1030 Base cover assembly” on page 65 •...
  • Page 81 Removal steps of the smart-card reader and the smart-card-reader cable Step Screw (quantity) Color Torque 0.181 Nm M2 × L2.5 mm, thin head (3) Silver (1.85 kgf-cm) M2 × L3 mm, flat-head, nylon-coated (2) Black 0.181 Nm (1.85 kgf-cm) Chapter 8 Removing or replacing a FRU...

  • Page 82: 1140 Wireless-Wan Antenna Kit

    1140 Wireless-WAN antenna kit For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 • “1020 Nano-SIM-card tray (for selected models)” on page 65 • “1030 Base cover assembly” on page 65 • “1040 Built-in battery” on page 67 •...

  • Page 83: 1150 Trackpad And Trackpad Cable

    Wireless-WAN antenna location Wireless-WAN auxiliary antenna* Wireless-WAN main antenna* * for selected models 1150 Trackpad and trackpad cable For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 • “1020 Nano-SIM-card tray (for selected models)” on page 65 •...

  • Page 84: 1160 System Board

    Step Screw (quantity) Color Torque M2 × L2 mm, flat-head, nylon-coated (7) Silver 0.181 Nm (1.85 kgf-cm) 1160 System board Note: If you replace the system board, remember to make the sensor calibration. For details, see “Sensor calibration” on page 58. Important notices for handling the system board When handling the system board, read the following: •...
  • Page 85 For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 • “1020 Nano-SIM-card tray (for selected models)” on page 65 • “1030 Base cover assembly” on page 65 • “1040 Built-in battery” on page 67 •...

  • Page 86: 1170 Lcd Unit

    When installing: Ensure that all the connectors are attached firmly to the system board. If you install a new system board, paste the thermal pad in the M.2 solid-state drive slot as shown. 1170 LCD unit For access, remove these FRUs in order: •...
  • Page 87 Removal steps of the LCD unit Torque Step Screw (quantity) Color M2 × L4 mm, flat-head (2) Black 0.181 Nm (1.85 kgf-cm) Chapter 8 Removing or replacing a FRU...

  • Page 88: 1180 Fingerprint-Reader Cable And Power Button Card With Fingerprint Reader

    When installing: Ensure that you attach the connectors firmly. Attention: When you route the cables, ensure that they are not subject to any tension. Tension could cause the cables to be damaged by the cable guides, or a wire to be broken. 1180 Fingerprint-reader cable and power button card with fingerprint reader For access, remove these FRUs:...

  • Page 89: 1190 Keyboard Assembly

    Removal steps of the power button card with fingerprint reader Step Screw (quantity) Color Torque M2 × L3 mm, thin head (1) Black 0.181 Nm (1.85 kgf-cm) 1190 Keyboard assembly For access, remove these FRUs in order: • “1010 ThinkPad Pen Pro” on page 64 •...

  • Page 90: 2010 Strip Bezel

    2010 Strip bezel Removal steps of the strip bezel 2020 LCD panel assembly For access, remove this FRU: • “2010 Strip bezel” on page 84 Removal steps of the LCD panel assembly X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 91: 2030 Camera Cable, Privacy Shutter, And Camera Board

    Step Screw (quantity) Color Torque M2 × L3 mm, thin head (1) Black 0.181 Nm (1.85 kgf-cm) 2030 Camera cable, privacy shutter, and camera board For access, remove these FRUs: • “2010 Strip bezel” on page 84 • “2020 LCD panel assembly” on page 84 Removal steps of the camera cable, privacy shutter, and camera board When installing: Ensure that the connectors are attached firmly.

  • Page 92: 2040 Sensor Board

    2040 Sensor board For access, remove these FRUs: Note: If you replace the sensor board, remember to make the sensor calibration. For details, see “Sensor calibration” on page 58. • “2010 Strip bezel” on page 84 • “2020 LCD panel assembly” on page 84 Removal steps of the sensor board Depending on the type of sensor board, the removal steps might be different from the following illustrations.

  • Page 93: 2060 Hinges

    Removal steps of the LED cable 2060 Hinges For access, remove these FRUs in order: • “1170 LCD unit” on page 80 • “2010 Strip bezel” on page 84 • “2020 LCD panel assembly” on page 84 Removal steps of the hinges Step Screw (quantity) Color...

  • Page 94: 2070 Camera Board And Sensor Board Cable

    2070 Camera board and sensor board cable For access, remove these FRUs in order: • “1170 LCD unit” on page 80 • “2010 Strip bezel” on page 84 • “2020 LCD panel assembly” on page 84 Removal steps of the camera board and sensor board cable 2080 Human presence sensor module For access, remove these FRUs: Note: If you replace the sensor board, remember to make the sensor calibration.

  • Page 95: 2090 Lcd Cable

    Removal steps of the human presence sensor module 2090 LCD cable For access, remove these FRUs in order: • “1170 LCD unit” on page 80 • “2010 Strip bezel” on page 84 • “2020 LCD panel assembly” on page 84 Removal steps of the LCD cable 2100 Wireless-LAN antenna kit For access, remove these FRUs in order:...
  • Page 96 Removal steps of the wireless antenna kit X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 97: 2110 Lcd Rear Cover Assembly

    Wireless-LAN antenna location Wireless-LAN main antenna Wireless-LAN auxiliary antenna When installing: Attention: When you route the cables, ensure that they are not subject to any tension. Tension could cause the cables to be damaged by the cable guides, or a wire to be broken. 2110 LCD rear cover assembly For access, remove these FRUs in order: •...
  • Page 98 X13 Yoga Gen 2 Hardware Maintenance Manual...

  • Page 99: Appendix A. Notices

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
  • Page 100 Trademarks LENOVO, LENOVO logo, THINKPAD, THINKPAD logo and TRACKPOINT are trademarks of Lenovo. Microsoft and Windows are trademarks of the Microsoft group of companies. Intel and Optane are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. The terms HDMI and HDMI High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 101: Appendix B. Abbreviation And Acronym Table

    HDMI high-definition multimedia interface integrated circuits ICCID integrate circuit card identity International Standardization Organization local area network liquid crystal display media access control machine type machine type and model personal computer Platform Controller Hub © Copyright Lenovo 2021...
  • Page 102 Abbreviation Term POST power-on self-test random-access memory radio frequency RFID radio-frequency identification ring indicator registered jack SATA Serial Advanced Technology Attachment subscriber identity module supervisor password TFTs thin-film transistors UEFI Unified Extensible Firmware Interface Universal Serial Bus UUID universally unique identifier video graphics array VRAM video random-access memory...
  • Page 104 Part Number: SP40T80100_01 Printed in (1P) P/N: SP40T80100_01...
  • Page 105 *1PSP40T80100_01*...
