Specifications - Skyvue NXG-4970-FS Owner's Manual

Specifications

Model: NXG-4970-FS
Shown in white w/optional 20 watt speaker bar.
Specifications
LED Screen High Bright LED Panel
Resolution 1920 x 1080
Response Time 12 ms
Contrast Ratio 1,300 : 1
Power Requirements AC 120V, 60HZ
Power Consumption 120W without speaker bar
140W with 20 watt speaker bar
Receving System ATSC/NTSC
Television Weight 96lbs. without speaker bar
103lbs. with 20 watt speaker bar
Inputs
Ant/Cable F type analog (VHF/UHF/CATV)
(Digital Air/Cable)
Componet Componet In Pr (Cr), Pa(Ca), Y
RS-232C 9 pin D-sub male connector
USB Input Photo / Music Modes
Audio In Audio in 3.5 mm jack
Audio Out Audio out 3.5 mm jack
Audio Output Coaxial SPDIF Audio Out
VGA/PC In Analog RGB (PC) In
(15 pin mini D-sub female connector)
HDMI1 HDMI
HDMI2 HDMI (MHL)
HDMI3 HDMI
AV In Video(Y), Audio L (W), Audio R (R)
• All NXG Series are equipped with an external air flow system
allowing filtered air to assist in keeping vital components cool.
• 2 Year Parts and Labor Warranty applies to all SkyVue NXG Series
Outdoor Televisions.
1) Satin Black, 2) White, 3) Dark Brown,
46
4) Slate Gra y, 5) Sandstone , 6) Mint Green , 7) Hunter Green , 8) Terra Coppe r, 9) Pa tr iot Blue
SkyV ue TV , 2218 Dawson Drive, Chester, SC, 29706
www.skyvue.com
87 7. 47 5.98 83
Among SkyVue Outdoor TVs new lineup of smart TVs is the
NXG-4970-FS. This 49" class model provides customers with
tremendous value when compared to other mid-sized screen
televisions. SkyVue's sunlight readable full HD 1080p 700 nit
LED technology delivers the most natural and Vibrant picture
quality available.
Protected by an all aluminum powder coated housing, the
NexGen 700 nit Series is the preferred choice when seeking
maximum protection and premium clarity for your outdoor
television in full sunlight.
43.95
Television Dimensions without speaker bar:
43.95"W x 25.45"H x 5.00"D
Television Dimensions with speaker bar:
43.95"W x 28.57"H x 5.00"D
(Optional table stand adds a minimal of 1.25" to height of television.)
• Internal Cooling System keeps the unit cool and dry in
temperatures up to 140º degrees F.
• Internal Thermostatically-Controlled Heater protects TV
temperatures as slow as -24º degrees F.
• Innovative Water-tight Cabl,e Entry System with pass-through
design keeps cables dry and allows for easy hook-ups.
• Anti-Glare/UV Coated screen, increases contrast and protects
the LED screen from Sun's harmful rays.
• Weatherproof remote control included.
Available in nine designer colors.
1 2
5 6
5.00
3 4
7 8
All Rights Reserved. SkyVue
9
®
