AUTO - SCANNING WITH DIGITAL CONTROL

LCD COLOR MEDICAL MONITOR

AMVX2408

Operation Manual

For future reference, record the serial number of your display

monitor in the space below :

Serial Number

The serial number is located on the back of the monitor

Table of Contents

Need help?

Do you have a question about the AMVX2408 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ampronix AMVX2408

Page 1 AUTO - SCANNING WITH DIGITAL CONTROL LCD COLOR MEDICAL MONITOR AMVX2408 Operation Manual For future reference, record the serial number of your display monitor in the space below : Serial Number The serial number is located on the back of the monitor...
Page 3 Ampronix 2007 All other trademarks are the property of their reference owners. This document is subject to change without notice. Ampronix provides this information as reference only. Reference to other vendor’s products does not imply any recommendation or endorsement. Revision Control...
Page 4: Table Of Contents
Safety Precaution..................Cleaning Your Monitor.................. Power Management Function..............Preset Modes....................Video Signals....................PIP / POP / PBP function................DDC......................Installation....................Connecting the Power Cord..............User Function / Messages................. OSD Section....................Troubleshooting..................Specification of (AMVX2408)..............Classification....................Electromagnetic Compatibility..............Dimension Drawing (mm)................Connectors....................
Page 5: Product Description And Intended Use
Please check the following items are present when you unpack the box, and save the packing materials in case you will need to ship or transport the monitor in future. • AMVX2408 LCD Monitor and two video cables (1) HD15 VGA cable* (1) DVI-D cable* •...
Page 6: Warnings And Cautions
Federal law (United States of America) restricts this device to use by, or on order of a physician. The Ampronix AMVX2408 monitor has been tested under UL 60601-1 standard and UL listed for Medical application. Ampronix reserves the right to make improvements in the product(s) described herein.
Page 7 AMVX2408 5 Warnings 1. Read the operating manual thoroughly and be familiar with its contents prior to using this equipment. 2. Carefully unpack the unit and check if any damage occurred during shipment. 3. Should any solid object or liquid fall into the panel, unplug the unit and have it checked by qualified personnel before operating it any further.
Page 8 Cautions 1. The AC Adapter must be plugged into a Grounded power outlet. 2. Use only the proprietary AMVX2408 power supply for the AMVX2408 monitor. Make a proper connection by ensuring that the shrink tubing completely secures the connection between the DC power cord and the extension cord.
Page 9: Symbol Explanations
AMVX2408 7 Symbol Definitions...
Page 10: Eu Declaration Of Conformity For Medical Applications
For a copy of the Declaration of Conformity document, please contact Ampronix and request for AMVX2408 DOC. Prepare for Unpack Before you unpack your monitor, prepare a suitable workspace. You...
Page 11: Safety Precaution
AMVX2408 9 SAFETY PRECAUTION · Avoid placing the monitor, or any other heavy object, on the power cord to prevent fire or electrical shock from damage to the power cord. · Do not expose the monitor to rain, excessive moisture, or dust to avoid fire or shock hazard.
Page 12: Power Management Function
1 seconds On and 1 second Off. The screen is displayed after the vertical and horizontal sync signals are restored. Power Management System The AMVX2408 Medical Monitor power management proposal. Provides four phases of power-saving modes by detecting the horizontal sync signal as shown in the table below.
Page 13: Preset Modes
AMVX2408 11 PRESET MODES...
Page 14: Video Signals
12 User’s Guide Video Signals...
Page 15: Pip / Pop / Pbp Function
AMVX2408 13 PIP / POP / PBP function The following combination options are available to you:...
Page 16: Ddc
14 User’s Guide To make your installation easier, the monitor is able to Plug and Play with your system if your system also supports DDC protocol. The DDC (Display Data Channel) is a communication protocol through which the monitor automatically informs the host system about its capabilities, for example, supported resolutions and corresponding timing.
Page 17: Connecting The Power Cord
AMVX2408 15 CONNECTING the POWER CORD * Check first to make sure that the power cord you use is the correct type required for your area. * This monitor has an universal AC adapter that allows operation in either AC 100 - 240 V ac voltage area. No user-adjustment is required.
Page 18: User Function / Messages
16 User’s Guide User Functions / Messages Key Name and Function Power LED : Lights up to indicate the power is turned ON. Power Switch : To power ON or OFF the monitor. Rotary switch : With the OSD menu activated, increases the value of the selected (Ture Right) parameter or moves rightward in OSD menu.
Page 19: Osd Section
AMVX2408 17 OSD Section Main Menu Chromatic Adjust Color Temp, Gamma Visual Adjust Brightness, Contrast, Phase, Chroma, Sharpness-H, Sharpness-V Setting Adjust Scale Mode, Mirror, Freeze Frame, Zoom / Pan, PIP / POP, PBP Advanced Adjust OSD Position Control, Screen Control, DPMS, Auto...
Page 20 18 User’s Guide OSD Section Chromatic Color Temp Change the color temperature - D65, D93, S1, S2, S3, S4 Gamma Change the gamma value - 1.8, 1.9, 2.0, 2.1, 2.1S, 2.2, 2.3, 2.4, 2.4S, S0, Radio graph Exit Exit the menu Visual Brightness Adjust the brightness of panel (Range 0 - 100)
Page 21 AMVX2408 19 OSD Section Setting Scale Mode Change the scale mode - Fill all, Vertical - fill, Horizontal - fill, One to One, Center - fill, Fill aspect ratio Mirror Off / On mirror image Freeze Frame Off / On freeze frame...
Page 22 20 User’s Guide OSD Section Sub menu of PIP Mode PIP Mode ON / Off Source PIP sub screen source - SDI1,2, C-Video, S-Video, Component, VGA, DVI Position PIP sub screen position - Top L, Top R, Bottom L, Bottom R Size PIP sub screen size - Small, Medium, Large Blending...
Page 23 AMVX2408 21 OSD Section Advanced OSD Position Change the OSD menu - Position, Background, Control OSD time out, Language Screen Control Control and adjust H and V position, Freqency, Phase Noise Reduction, Motion Offset DPMS Change the DPMS Auto Source...
Page 24 22 User’s Guide OSD Section Sub menu of OSD Control H-position Adjust OSD H - position (Range 0 - 100) V-position Adjust OSD V - position (Range 0 - 100) Back ground Adjust transparency of OSD back ground (Range 0 - 100) OSD Time out Adjust OSD time out - 5s, 10s, 15s, 20s, 1m, 2m Language...
Page 25 AMVX2408 23 OSD Section Information Custom Entry Change the user or monitor’s name Display the serial number Run Time Display the total run time Input Format Display the current input resolution and vertical frequency Exit Exit the menu...
Page 26: Troubleshooting
24 User’s Guide TROUBLESHOOTING Before sending your LCD monitor for servicing, please check the troubleshooting list below to see if you can self-diagnose the problem. · · · · · · · l l i t , t f · l l u ·...
Page 27: Specification Of (Amvx2408)
AMVX2408 25 SPECIFICATION " < - i t ( ° , ) l ° & " " ° ° ° ° ° ° ° ° & " " " t l i ** All contents are subject to change without notice.
Page 28: Classification
51LJ Medical Equipment E215822 This monitor is intended for use in Health Care Facilities model AMVX2408 Equipment is not suitable for use in the presence of flammable anesthetic mixture with air or with oxygen or nitrous oxide. No user serviceable parts inside, ask qualified personnel when accessing inside.
Page 29: Electromagnetic Compatibility
AMVX2408, as this may result in increased electromagnetic emissions or decreased immunity to such emissions. Warning If the AMVX2408 is used adjacent to or stacked with other equipment, observe and verify normal operation of the AMVX2408 in the configuration in which it will be used prior to using it in a surgical procedure.
Page 30 28 User’s Guide < > < > < > < > Manufacturer’s declaration - electromagnetic immunity t t i t t i t t i m . ) t t i t t i t t i i t i...
Page 31 AMVX2408 29...
Page 32: Dimension Drawing (Mm)
30 User’s Guide Dimension Drawing (mm)
Page 33: Connectors
AMVX2408 31 Connectors DC Input Connector Jack Power Input Video Input 24 pin DVI-I connector. DDWG or equivalent connector. 15 pin VGA connector. S - Video connector. C - Video connector.
