PELLET BOILER SM ECO 25 and 33 COMPACT FOR CENTRAL HEATING
Instructions for use, maintenance and installation
→ Pellet fuel from timber biomass biofuels →

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM ECO 25 and is the answer not in the manual?

Questions and answers

Summary of Contents for Romstal SM ECO 25

  • Page 1 PELLET BOILER SM ECO 25 and 33 COMPACT FOR CENTRAL HEATING Instructions for use, maintenance and installation → Pellet fuel from timber biomass biofuels →...
  • Page 2 INSTRUCTIONS FOR CONNECTING, OPERATION, AND MAINTENANCE OF THE STOVE Heating devices (in this manual they are called “stoves") by TERMAL INT LTD (in this manual titled producer) are assembled and tested in accordance with the safety and applicable measures, and regulations of the European Community. This manual is intended for users of the boilers, contractors who install the boilers, operators and workers for boiler maintenance that is shown on the front page of the manual.
  • Page 3: Table Of Contents

    2. THE PURPOSE OF THIS MANUAL ..................8 2.1 UPDATES ........................... 8 3. RESPONSOBILITIES OF THE MANUFACTURER ............... 8 3.1 GENERAL TERMS OF USE .................... 8 3.3 RESPONSOBILITIES OF THE INSTALLER..............9 4.INSTALATION – BOILER INSTALLATION ................ 10 4.1 INSTALLING THE BOILER .................... 10 4.2 THE SMOKE EXHAUST SYSTEM ................
  • Page 4 16.6. ELECTRICITY SCHEME .................... 44 16.7. Menu..........................45 16.8. ALARMING ........................48 17. SAFETY MEASURES ......................52 18. FAILURES - CAUSES – SOLUTIONS................. 53 19. INFORMATION ON DISPOSING (THROWING AWAY) AND DISMANTLING (PULLING APART) OF THE STOVE ..................55 20. THE DURATION OF GUARANTEED SERVICE ............... 55 20.1.
  • Page 5 1.TECHNICAL CHARACTERISTICS OF BOILER COMPACT 25: NAME VALUE UNIT Dimension 640 x 925 x 1475 Mass Thank capacity The door of the tank 530 x 320 Water capacity of the boiler Cleaning door 285 x 245 NAME VALUE UNIT Installation place 4.18 The height from the floor to axis of the flue terminal...
  • Page 6 COMPACT 33: NAME VALUE UNIT Dimension 720 x 950 x 1475 Mass Thank capacity The door of the tank 610 x 320 Water capacity of the boiler Cleaning door 260 x 200 NAME VALUE UNIT Installation place 4.22 The height from the floor to axis of the flue terminal The height from the floor to axis of the hot water 1145...
  • Page 7 Figure 1. Boiler SM ECO 33 compact...
  • Page 8: The Purpose Of This Manual

    2. THE PURPOSE OF THIS MANUAL The purpose of the instructions is to enable the user to take all the necessary measures in order to ensure safe and proper use of the stove. 2.1 UPDATES This manual reflects a work of art at the moment when the boiler was placed on the market. Therefore, producer does not take into account the boilers that are already on the market with the appropriate technical documentation and considers them as defective or inadequate after any kind of modification, adaptation or application of new technologies to newly produced machines.
  • Page 9: Responsobilities Of The Installer

    3.2 TRANSPORTING AND MOVING THE BOILER - HANDLING When moving the boiler, it is necessary to be careful and not allow the boiler to tilt forward. This is because the brunt of the stove is forward. During transportation of the stove, which has to be completely safe, make sure that the forklift has the load that is greater than the weight of the stove that it is supposed to lift.
  • Page 10: Instalation - Boiler Installation

    4.INSTALATION – BOILER INSTALLATION Responsibility for the work carried out at the place of connection is entirely on the user. Before one turns the boiler on, the installer must meet all legal standards of safety, as well as the following requirements: •...
  • Page 11: The Smoke Exhaust System

    ATTENTION! If the ejection path of smoke creates such a bad draft, of a bad flow of air (many curves, improper completion of the ejection of smoke, constriction, etc.) discharge of smoke can be bad, or in a situation like this smoke discharging is not as good as it could be. The smoke ejection system from the boiler operates under negative pressure in the stove chamber and with mild pressure from the smoke drain pipe.
  • Page 12 A) The top of the chimney is resistant to wind B) Chimney dimensions are not limited; important is that chimney does not have more then 15 Pa draft C) Gasket /Sealed D) Inspection hole - for control Flue pipes that are in poor shape, or are made out of inappropriate materials (asbestos cement, galvanized sheet, etc.
  • Page 13 SYSTEM TYPE DIAMETER mm SYSTEM MARK Pipe length less than 5 m acceptable Pipe length more than 5 m required To be installed in places above 1,200 meters above sea recommended level Table 1 Figure 2. Figure 3. When using the connecting pipe between the boiler and the flue drain hole, be sure to use a connector (as shown in Figure 4a), with the clean-out cover (cap) next to the boiler.
  • Page 14 Figure 4a. Cleaning elements Ideal vacuum primarily depends on the absence of barriers such as narrowing and/or corner connectors. It is recommended that the knees are 30°, 45 °, and 90 °. Knee at 90 ° shall be three-fold (Figure 4b). In any case, it is necessary to ensure that the initial part of the vertical flue pipe has the length of at least 1.5 m.
  • Page 15: Insulation And The Diameter Of The Opening (Hole) On The Roof (Or In The Wall)

    INSULATION AND THE DIAMETER OF THE OPENING (HOLE) ON THE ROOF (OR IN THE WALL) Once you determine the position of the boiler, it is necessary to make a hole through which a smoke pipe must pass. This varies depending on the type of installation, diameter of the exhaust gas pipe (see Table 1) and the type of wall or roof for the tube to pass.
  • Page 16 1. Armature 80> 120 2. A pipe fitting with curve Ø120 Figure 8. 1. A pipe fitting with curve 2. Cleaning direction 3. Opening, a window for servicing / inspection 4. Cleaning direction 5. A pipe fitting with curve – T- pipe connection 6.
  • Page 17 Diameter of the smoke exhaust pipe (mm) Insulation thickness D.80 D.120 Diameters of the opening (holes) to be made (mm) The walls are made of wood, or in any case, flammable, or parts that are flammable. Concrete wall or a roof A wall or a brick roof Table 2: Insulation thickness for the part of the system that passes through the wall or roof Above all it is necessary to provide the PERFECT AIRFLOW (draft) in pipes for smoke exhaustion that...
  • Page 18: Commbustion Air Supply

    4.4 COMMBUSTION AIR SUPPLY The air required for combustion, which is taken from the environment, must be supplied by a single ventilation grill mounted on the outer wall of the room. This will ensure better combustion and thus lower consumption of pellets. It is not recommended to have outside air drawn directly from the tube, as it will reduce the efficiency of combustion.
  • Page 19: Connecting The Power

    4.5 CONNECTING THE POWER These stoves are connected to electricity. Our stoves have electrical cables that are suitable for medium temperature. If you need to replace the power cord (if it is damaged, for example) then consult with our authorized technical staff. Before you plug in the electric stove note the following: - That the characteristics of electrical systems correspond to the information that is specified in the data on the identification plate on the boiler.
  • Page 20: Warning Safety Measures For Staff

    The stove operates with a combustion chamber, which is in the negative pressure. Therefore, make sure that the smoke is well thermally insulated. When the stove is turned on for the first time then, due to the stabilization process a small amount of paint (not harmful to health) that covers the stove vaporizes.
  • Page 21: Warning Safety Measures For The User

    6.1 WARNING SAFETY MEASURES FOR THE USER The place where the boiler is to be set up, called the mounting place, must be prepared by local, national, and European regulations. The boiler is a “heating machine" and while it is on it has outer surfaces that are very hot or that achieve very high temperatures.
  • Page 22 Use a drum shaped vacuum cleaner that can facilitate cleaning the boiler. The vacuum cleaner must have a filter that will prevent the sucked dust to go back into the room where the boiler is located. Before you get started with routine maintenance, including cleaning, take the following precautions: •...
  • Page 23 Figure 15. Burner guidance removal The manufacturer does not assume any responsibility for damage caused by third parties. 2. The hole for inserting the heating element to burn fuel 1. For the best operation of the stove, all holes must be free of ash Figure 16a.
  • Page 24 Figure 16b. Compact 33 The ash container should be vacuumed or emptied if it is full... Figure 17. Ash container Figure 18. Vacuum the dust bin Make sure the boiler and the ash are cold. Upper ash container must be cleaned every or every other day, by vacuuming or by simple throwing the ashes away.
  • Page 25 They need to be cleaned manually with a special key for every 150-180 kg of spent pellets (two full tank of pellet). First use the key to lift up small round lids with openings, two of them, that are located on the cover of the stove at the top.
  • Page 26 7.2 CLEANING AND MAINTENANCE (for employees who do maintenance) FLUES - CHIMNEY should be cleaned every six months or after burning two tons of pellets. Make sure the stove and the ash are cold. The smoke channel (chimney) is resistant to wind and has to be checked and cleaned every year, best at the beginning of the heating season.
  • Page 27: Special Maintenance

    7.3 SPECIAL MAINTENANCE Your boiler is a heat generator that uses pellets as solid biofuel. This is why you should do special maintenance once a year. This is best done at the beginning of the heating season. The purpose of the special maintenance is to ensure proper and efficient operation of the boiler. 8.
  • Page 28: Storing The Pellet

    9.1 STORING THE PELLET The pellets must be kept in a dry place that is not very cold. Cold and moist pellets (at the temperature of around 5 C) reduce the thermal power of the fuel and require additional cleaning of the boiler. THE PELLETS MUST NOT BE KEPT CLOSE TO THE BOILER.
  • Page 29 IMPORTANT: Connecting the stove on a hydraulic installation can be done exclusively by qualified technicians, who can do this in accordance with applicable regulations of the country in which the installation is done. Producer disclaims all liability in case of a material or bodily harm, in the event of failure, poor functioning, if the above recommendations are not followed.
  • Page 30: Pressure And Return Pipe

    Figure 22. 11. PRESSURE AND RETURN PIPE Outputs of the pressure and return pipes on the boiler are 1'' and you cannot reduce them or taper to the first bifurcation. Use a 1’’ steel pipe or a copper pipe with the outside diameter of Ø28mm or greater. When installing, strictly observe the slopes of pipes as they need to be at 0.5% (5mm.
  • Page 31: Components Of The Heating System

    12. BUILT-IN COMPONENT OF THE BOILER Note: If the boiler and the pump have been idle for a long time (a month, for example), the pipe shaft can stick to the base, it may not move the water, or it can burn out. If when starting the boiler when the water in the boiler heats up the water pump does not start, if the radiators do not heat up when the set temperature is reached, if you do not hear the murmur of water (moving), or if the boiler temperature rises and radiators are not warming, remove the left lateral side as indicated in the previous paragraph, and get to the pump.
  • Page 32: Automatic Air Valve (Is Part Of Installation Not A Part Of Boiler)

    12.1 AUTOMATIC AiR VALVE Figure 23. The cap valve must be loose, not tight, so that the air can come out of the boiler and installations smoothly. The boiler must be full with water without air. With the first charging system in the boiler and every year before the start of the heating season all air from the system needs to be removed.
  • Page 33: Installing And Igniting

    13. INSTALLING AND IGNITING Before boiler start up, the system must be filled with water and free from air bubbles. Chimney must be connected as described in previous chapters. System must be filled with cold water up to the pressure between 1 to 1.5bar (cold water pressure). The boiler has internal pressure valve protection that opens at 3 bars.
  • Page 34: Filling With Woden Granules

    15. FILLING WITH WODEN GRANULES Refuelling is done on the upper side of the boiler by opening the lid. Put the wooden granules in the tank. Its load capacity when it is empty is about six 15 kg bags, a total of 90kg of pellets. -compact 33; five 15 kg bags, a total of 75 kg of pellets –...
  • Page 35: Description And Mode Of Operation Of The Control System

    16. DESCRIPTION AND MODE OF OPERATION OF THE CONTROL SYSTEM 16.1 DESCRIPTION OF THE TOUCH BUTTON DISPLAY Boiler power choice Weekly timer Temperature IR Sensor Fuel quality choice Alarm service Time Alarm cleaning Settings Alarm fuel Left/Right Buttons for menu choice ON / OFF Button Enter/Confirm button for menu confirmation Cancel/back button for menu exit...
  • Page 37 Power Fuel Time Settings Temperature Figure 28...
  • Page 38: Use And Regulation Control

    16.2. Use and regulation control Boiler is switched off Starting of the boiler is done in such a way that the button is touched and kept for 3 sec to occurrence indication “ON” on the display After which boiler goes into automatic mode “AUTO”.
  • Page 39 16.3. Modulation By touching ENTER the value of The display begins to flashes, the keys perform regulating power burners from 1 to 5 and confirm by touching ENTER key. The value of AUTO enables automatic control of power burners as needed, which at the same time we as the manufacturer recommends.
  • Page 40 If you want to check or set boiler temperature, press the Enter key and the display begins to flashes. Then use buttons to change values and input new temperature. Be sure to confirm the value with the ENTER key. Next pressing RIGHT arrives at an indication for you to choose the type of pellet.
  • Page 41: Turning The Boiler Off And On

    After setting the date values, touch again button RIGHT and you will see a option for year, also flashing. Use buttons to choose value of the year. Once again touch RIGHT button and you will see a value days of the week.Touch the to input day of the week:...
  • Page 42: Setting Up The Time-Controlled Program

    16.5. SETTING UP THE TIME-CONTROLLED PROGRAM The process of adjustment is particularly important for every segment of the regulation of the fireplace/boiler, and any incorrect settings can lead to a malfunction of the stove, the simplest example would be wrong adjustment of dates or time, which automatically associates the programmed work time and burning of stove.
  • Page 43 If you want to program the time of boiler operation, or its switching on and off after the work program set to ON, then touch the and you will see to program C3. After that by touching menu button ENTER button to open the submenu (P1) –...
  • Page 44: Electricity Scheme

    16.6. ELECTRICITY SCHEME Figure 30: Electricity scheme...
  • Page 45: Menu

    16.7. Menu The last menu on the main screen, with the navigate key RIGHT SETUP. The display when you open this menu writes OFF, This symbol indicates that all the menus and buttons on the control unit are unlocked. In this menu there are two levels of protection of keys on the control unit, or blockage of using regulation to children and people who are unable to manage the operations of the boiler.
  • Page 46 Switching the value with buttons changing the display mode. For example, switching to a value of 1, on stand by the regime display randomly showing temperature and time. When it switch to OFF, the display retains to the set menu, so for example AUTO, temperature or time.
  • Page 48: Alarming

    16.8. ALARMING SITUATION...
  • Page 52: Safety Measures

    17. SAFETY MEASURES The boiler is equipped with the following safety devices: - FLUE GASES TEMPERATURE SENSOR Checks the temperature of flue gases that allow the boiler to be turned ON or stop the ignition if the flue gas temperature drops down below the programmed value. - BOILER CONTACT THERMOSTAT When the temperature goes over the set safety value the stove will turn off immediately.
  • Page 53: Failures - Causes - Solutions

    18. FAILURES - CAUSES – SOLUTIONS PROBLEMS POSSIBLE CAUSES SOLUTIONS Wooden granules 1. The wooden granules tank is 1. Fill the tank are not put into empty. 2. Empty the tank and unblock the spiral - the firebox, in the 2.
  • Page 54 5. The spark plug is damaged. Wooden granules 1. Lack of air for combustion. 1. Clean the combustion chamber and check are settling in the if all the openings are clear. Do the standard 2. Wet or inadequate wooden combustion cleaning of the combustion chamber and the granules.
  • Page 55: Information On Disposing (Throwing Away) And Dismantling (Pulling Apart) Of The Stove

    19. INFORMATION ON DISPOSING (THROWING AWAY) AND DISMANTLING (PULLING APART) OF THE STOVE Dismantling and throwing away, or disposing of an old used stove is the sole responsibility of the owner. The owner of the boiler must abide by the regulations in his/her country related to the safety and environment protection.
  • Page 56: Warranty Terms And Conditions

    20.1. WARRANTY TERMS AND CONDITIONS Product warranty is valid within the legally defined deadline. The warranty does not apply to the glass or to the physical damage caused after purchase. THE MANUFACTURER RESERVES ALL RIGHTS TO CHANGES. The appliance will, within the warranty period, only function correctly when used in accordance with the instructions for connection and use.
