Atomic Ion XL Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
General
1
information
Driving
2
Interior device
3
Maintenance
4
and service
When there is
5
trouble...
Vehicle
6
specification
Key, Door lock, Rear view mirror etc. equipment
Driving, Parking and Driving safety
Air conditioner and audio system，and other devices to
improve driving comfort ability
Information about washing vehicle, self-maintenance，maintenance
Procedures you should take when vehicle needs towing, flat tire or
accident occurs
Whole vehicle specification
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ion XL Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Atomic Ion XL Series

  • Page 1 Contents General Key, Door lock, Rear view mirror etc. equipment information Driving Driving, Parking and Driving safety Interior device Air conditioner and audio system，and other devices to improve driving comfort ability Maintenance Information about washing vehicle, self-maintenance，maintenance and service When there is Procedures you should take when vehicle needs towing, flat tire or trouble…...

  • Page 2: Table Of Contents

    Contents General information Driving Key information 1-1. Driving procedures 2-1. ………………….….……18 ….….……42 Starting the vehicle ….….……43 Driving the vehicle Central control lock 1-2. Stopping and Parking .….……47 …………19 Central control lock ……….….……49 Ignition switch …………….….……51 Shift lever 1-3. Open, Close and Lock the Doors …….….……52 Turn signal lever ………………………22...
  • Page 3 Driving information 2-5. Maintenance and Service ……68 Preparation before driving ……………69 Driving procedures ……………70 Goods and luggage Maintenance and Service 4-1. Winter driving tips .……………71 Clean and protect vehicle ……74 Long time no use vehicle …………………98 appearance Clean and protect vehicle ……………………100 interior ……102...
  • Page 4 When there is trouble… Vehicle Specification Important information 5-1. Specification 6-1. …128 If vehicle needs towing ………144 Vehicle identification …132 If the vehicle is abnormal ………………145 Technical data Emergency measures 5-2. Loading instruction 6-2. …………149 If warning light comes on or Loading instruction …………………133 buzzer on...
  • Page 5 Note ■ When purchasing the parts, you need to provide the Traction motor number, in order to verify the parts. ■ Traction motor number you can find in following position： □ Acceptance certificate； □ Adhere to pillar plate front frame of left door, open left front door, you can see it;...
  • Page 6 Exterior...
  • Page 7 Exterior...
  • Page 8 Interior...
  • Page 9 Interior...
  • Page 10 Interior...
  • Page 11 Interior...
  • Page 12 Reference information User’s manual Thanks for choosing the products of our company. Before you drive，please read this manual carefully. You can get important tips and maintenance info. from this manual. It may offer you with safety driving, traffic safety information, and how to keep the vehicle in good condition.
  • Page 13 Vehicle accessory, parts and refitment Do not alter your vehicle, altering will affect the performance of the vehicle as a whole, especially safety and durability, even worse it may break the law. The vehicle failure or performance reduced due to altering the vehicle or battery damages do not belong to warrant coverage.
  • Page 14 Warning ■General cautions when driving Drive in sober state：Strictly prohibits driving the vehicle after drinking alcohol or some medicine which may affect your control ability. Alcohol and some medicine may delay your reaction time, affect your judgment and coordination ability, thus may cause injures to driver or other people. Cautious driving：You must drive cautiously to prevent accidents.
  • Page 15 Symbols used in this user’s manual Warning and caution Warning When you ignore such warning, it may cause people injuries. These symbols stand for that which cannot be done or prohibit to do in order to reduce the possibility of injury. Caution When you ignore such symbols, it may cause the vehicle or device damage.

  • Page 17: Key Information

    General information Key information 1-1. Open and close power windows 1-5. ………………….….……18 ……………34 Power windows Central control lock 1-2. Charging 1-6. …………19 Central control lock ……………….……36 Charging Open, Close and Lock Doors 1-3. ……………………22 Side door Correct driving position 1-7. ………………………24 Tailgate Correct driving position...

  • Page 18: Key

    1-1. Key information This vehicle equipped with remote controlled key Caution ■ Do not leave the key in vehicle ● Lock the door ● Keep the Key with you...

  • Page 19: Central Control Lock

    1-2. Central controlled lock Central controlled lock ■Remote-control key button ： Press the “Locking” button on the remote control key ● Lock button to lock side doors and tailgate at distance. When locking, turning light flashes once, if the doors lock. If the doors unlock, turning light would flash three times.
  • Page 20 1-2. Central controlled lock ■Picking lock warning When the ignition switch is off and doors are locked, Opening the doors with force, the turning light would flash 10 times and horn beeps 10 times. Press the "locking " button to release the warning. ■Remote control key shielding When the ignition switch turns on, remote control locking &...
  • Page 21 1-2. Central controlled lock ■Low-voltage detect and shutdown the output Unable to lock or unlock the doors with the remote key, the turning light doesn’t light, the horn doesn’t sound and the lock mechanism doesn’t move after pressing the button when Central control lock controller service voltage under 9.5V.

  • Page 22: Side Door

    1-3. Open, close and lock the door Side door The side doors can be opened or locked via remote control key、manual operation or automatic way. ■Remote control mode You can use unlock key, lock key on remote-control key to unlock and lock side door.
  • Page 23 1-3. Open, close and lock the door ■Automatic mode Side doors unlock automatically when turning ignition switch off after parking. When the vehicle speed is over 20km/h, the doors will be locked automatically. Warning ■ Avoiding the accident You must obey the following when driving; otherwise, the passenger may be thrown out due to sudden opening of the side doors, causing serious injury even death.

  • Page 24: Tailgate

    1-3. Open, close and lock the door Tailgate You can use smart key, door central control switch to unlock the tailgate, and you can use back door switch open the tailgate; When the tailgate is closed, the tailgate is locked via the remote control key and the door central control switch.
  • Page 25 1-3. Open, close and lock the door ■Closing the Tailgate Close the tailgate and press the tailgate to close it. Warning ■ Cautions while driving Keep the tailgate closed and locked to prevent the contents from being thrown out.

  • Page 26: Adjustable Parts（Seats，Rear View Mirror

    1-4. Adjustable Parts（Seat、rear view mirror） Front row seat □ Seat position adjusting lever Lift up the seat position adjusting lever, move the seat forward and backward. □ Seatbacks angle adjusting lever Lift up seatbacks angle adjusting lever, adjust the angle of seatback to proper position, then release seatbacks angle adjusting lever.

  • Page 27: Safety Belt

    1-4. Adjustable Parts（Seat、rear view mirror） Safety belt Before driving, make sure that all passengers fastened safety belt. ■Correct use of the safety belt ●Extend the shoulder belt so that it comes fully over the shoulder but does not come into contact with the neck or slide off the shoulder.
  • Page 28 1-4. Adjustable Parts（Seat、rear view mirror） ■ Pregnant women Obey medical advice and wear the seat belt in the proper way. Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occupants. Extend the shoulder belt completely over the shoulder and position the belt across the chest.
  • Page 29 1-4. Adjustable Parts （Seat, Rear view mirror） Warning Observe the following precautions to reduce the risk of injury in the event of sudden braking or an accident. Failing to do so may cause death or severe injury. ■Wearing a seat belt ●Ensure that all passengers wear a seat belt.
  • Page 30 1-4. Adjustable Parts （Seat, Rear view mirror） Warning ■Cautions for children in the vehicle If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt.

  • Page 31: Interior Rear View Mirror

    1-4. Adjustable parts（Seat, Rear view mirror） Interior rear view mirror Adjust the angle of interior mirror manually. Warning ■ Caution while driving Do not adjust the position of the mirror while driving. Otherwise it may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.

  • Page 32: External Rear View Mirror

    1-4. Adjustable parts（Seat, Rear view mirror） External rear view mirror ■ Adjust exterior rearview mirror Before driving, seat yourself in the cab, adjust two exterior mirrors to proper position manually. Adjust the mirror manually. ■ Folding rearview mirror Push inward to fold rearview mirror when you meet a special road condition.
  • Page 33 1-4. Adjustable parts (Seat, Rear view mirror) Warning ■ Observe the following precautions while driving. Otherwise it may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●Do not adjust the mirrors while driving. ●Do not drive with the mirrors folded back.

  • Page 34: Open And Close Powered Windows

    1-5. Open and close powered windows Powered window Using the following button to open, close, lock the powered window. ■Passenger side powered window button □ 1 Open window □ 2 Close window ■Driver side powered window button The driver can operate the power window lift and lock operation of all the windows.

  • Page 35: Open And Close Power Windows

    1-5. Open and close powered windows Powered window can be operated in the following state: Ignition switch is in ON position. Warning ■ Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.

  • Page 36: Charging

    1-6. Charging Charging ■ Preparation before charging □ Turn off ignition switch, shift to neutral, step down parking pedal, remove the key. □ Inspect the charging device, meter and tools if it is less or in trouble, you should have it repaired. □...
  • Page 37 1-6.Charging ■ Charging □ Open charging port lid. □ Open the charging port protective cap. □ Insert charging plug properly and lock it. □ Charge the vehicle, charging indicator in meters lights： Red light lit：In charging； Green light lit：The battery is full. For 220V charging voltage type：...
  • Page 38 1-6. Charging ■ Closing charging port cover After charging, close the charging port protective cap and the charging port lid. Warning ■ Complete charging time is：8-10h for lead acid battery, 5-8h for Li-ion battery. ■ Recommend install air switch of 20A, 25A. ■...

  • Page 39: Correct Driving Position

    1-7. Correct driving position Correct driving position Drive in a good posture as follows: □ 1 Sit upright and well back in the seat. □ 2 Adjust the position of the seat forward or backward to ensure the pedals can be reached and easily depressed to the extent required.
  • Page 40 1-7. Correct driving position Warning ■ While driving ● Do not adjust the position of the driver's seat while driving. Otherwise you will lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passengers.

  • Page 41: Driving

    Driving 2-1. Driving procedures 2-4. Using other system Starting vehicle……….….……42 Danger warning flasher switch Driving vehicle……….….……43 ………………………….65 Stopping and Parking..….……47 Reversing image………………66 Ignition switch……….….……49 Shift lever…………….….……51 2-5. Driving information Turn signal lever….….….……52 Preparation before drive...……68 Parking brake……….….……53 Driving procedures..….………69 Goods and luggage.…..………70 2-2.

  • Page 42: Driving Procedures

    2-1. Driving procedures Starting vehicle Step□ 1 Check that the parking brake is set. Step□ 2 Check that the shift lever or shift knob is set in N. Step□ 3 Sit on driver seat, firmly depress the brake pedal. Step□ 4 Open emergency switch （Only for lead acid battery vehicle）...

  • Page 43: Driving The Vehicle

    2-1. Driving procedures Driving vehicle Step□ 1 Step down braking pedal, Set shift lever to appropriate position（R： Reversing, D：Forward, S：Sports（more strong than D） ） ； □ 2 Release braking pedal, release the parking handle slowly, depress Step accelerating pedal slight to let vehicle go steadily. ■Starting on a steep uphill Step□...
  • Page 44 2-1. Driving procedures Warning ■ When driving the vehicle ● Vehicle should drive at even speed to ensure longest continuous mileages. Driver can adjust speed according to vehicle condition and loads. ● Do not turn ignition switch off while driving Power steering system and power braking assistant system won’t work, if you turn ignition switch off ●...
  • Page 45 2-1. Driving procedures Warning ● Do not set the shift lever or shift knob to R or N position while driving. If you set the shift lever or shift knob to D to R or R to D while driving, the vehicle may stop gradually.
  • Page 46 2-1. Driving procedures Warning ■ If you hear a squealing or scraping noise while driving Please contact your local dealer as soon as possible for inspection and replacement of the braking disk. It is dangerous to drive the vehicle when the wear limits of the brake pads and/or that of the brake discs are exceeded ■...

  • Page 47: Stopping And Parking

    2-1. Driving procedures Stopping and parking vehicle Step□ 1 Depress the braking pedal while shift lever or shift knob set to D or S position. Step□ 2 Set shift lever or shift knob to N. Step□ 3 Step down parking pedal. Step□...
  • Page 48 2-1. Driving procedures Warning ■ When parking, the shift lever or shift knob must be set to N position. ■ When vehicle is stopped on a slope, depress the braking pedal and the parking pedal to avoid moving forward and backward, to prevent from accidents. ■...

  • Page 49: Ignition Switch

    2-1. Driving procedures Ignition switch ■Change ignition switch mode □ 1 LOCK When the key is in this position, Vehicle power is off, Steering wheel locked, the key can be removed. When the key is removed, shift lever or shift knob should be in N. □...
  • Page 50 2-1. Driving procedures ■Ignition key cannot be turned When starting, ignition switch may seem stuck in the LOCK position. To free it, turn the key while turning the steering wheel slightly in either direction. Warning ■ Do not place your foot on the accelerator while starting. When driving off, depress the accelerator slowly, do not depress quickly Otherwise may cause an accident resulting in death or serious injury ■...

  • Page 51: Shift Lever

    2-1. Driving procedures Gearshift ■ Shift knob ■Shift lever ■Gear usage Gear Function Sport mode Normal driving，forward gear Neutral Reverse Caution ■ When gear shifting, stop the vehicle steadily.（You can Set the shift lever from S to D While driving.） Ensuring the motor life, the controller is designed with a protective function, D or R can only be shifted to while the vehicle is steadily parked.

  • Page 52: Turn Signal Lever

    2-1. Driving procedures Turn signal lever □ 1 Turn right □ 2 Turn left ■Turn signals can be operated when Ignition switch is at ACC、ON position. When turn signal switch is on, turn signal light flashes while turn signal indicator on meter panel is flashing and there is a buzz sound. ■If the indicators flash faster than usual If the indicators flash faster than usual or not flash, Check that it’s not a light bulb.

  • Page 53: Parking Brake

    2-1. Driving procedures Parking brake ■Parking pedal Step down braking pedal, after the vehicle stopped step down parking pedal with left foot to apply the parking brake. Parking brake indicator comes on at this time. To release the parking brake, just step down the parking pedal again.

  • Page 54: Instrument Panel

    2-2. Instrument panel Gauges and meters The following gauges, meters and LCD illuminate when the ignition switch is in the ACC, ON position. □ 1 Speedometer Displays the vehicle instantaneous speed. □ 2 Battery electricity meter Displays the level of the battery, the last bar red lights flash will remind of recharging in times.
  • Page 55 2-2. Instrument panel □ 4 Function button When the ignition switch is in the ACC, ON position： ■Press short function button to switch between ODO and TRIP mode. ■Reset Trip meter： When in TRIP mode, press for 3~5 s and release to reset the trip meter.

  • Page 56: Indicators And Warning Lights

    2-2. Instrument panel Indicators and warning light The indicator and warning lights on the instrument panel inform the driver of the status of the vehicle’s various systems. ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems.
  • Page 57 2-2. Instrument panel Position light indicator：Position light, taillight, license light is on, this indicator is on. If you turn off the ignition switch, the position light is still on, there is a warning sound when the door of driver side opens to remind the driver to turn position light switch off, otherwise, the small battery may loss electricity.
  • Page 58 2-2. Instrument panel 表盘 ■ Warning lights Warning lights inform the driver of malfunctions in any vehicle’s systems. Open door warning light：Displays the state of left door, right door and tailgate, if one door is open or not fully closed, corresponding door display is opened.
  • Page 59 2-2. Instrument panel Motor overheat warning indicator：When the temperature of the motor comes to a certain value, it comes on. Charging system warning light：Indicates a malfunction in the vehicle’s charging system. Have the vehicle inspected by your Local dealer immediately. Battery trouble indicator ：...

  • Page 60: Headlight Switch

    2-3. Operating light and windshield wiper Headlight Switch The headlights can be operated manually. □ OFF All lights turn off. □ Position light, taillight and license light turns on. □ 3 Turn on headlights low beam light, position light is on. In this position, low-beam light is on, push operating lever downward, and High-beam light is on.
  • Page 61 2-3 Operating light and windshield wiper Cautions ■Do not leave the lights on too long when not driving the vehicle to avoid the vehicle out of power. ■While raining or washing the vehicle, the headlight lens may be foggy, This is like the phenomenon of fog on the glass in wet weather, it is not a function problem, the heat from the light can dismiss the fog on the lens.

  • Page 62: Fog Light Switch

    2-3. Operating light and windshield wiper Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. Fog light can be turned on only when the headlights switch is in the on position. □...

  • Page 63: Windshield Wiper And Washer

    2-3. Operating light and windshield wiper Windshield wiper and washer Windshield wipers and washer has five positions: MIST-OFF-INT-LO-HI □ 1 MIST: Wiper and washer works once, when released it resets automatically. (Each operation interval is more than 6 s). □ 2 OFF: Windshield wipers and washer is not working. □...
  • Page 64 2-3. Operating light and windshield wiper ■ The windshield wiper and washer can be operated when Ignition switch is at position. ■ If no windshield washer fluid sprays Check that if the washer nozzles are blocked and if there is washer fluid in the windshield washer fluid reservoir.

  • Page 65: Using Other System

    2-4. Using other system Danger warning flasher switch While emergency occurred, you must stop or park, this switch must be pushed to inform other drivers. At this time, all turn signal lights are flashing with buzzer beeps. Caution ■ Stop under emergency situation, please drive the vehicle off the driving pathway.

  • Page 66: Reversing Image

    2-4. Using other system Reversing image When reversing，reversing image displays on central control display to reflect the image state behind the vehicle. Reversing image is only an assistance to the driver operation. Reverse camera is installed on the rear bumper above the rear license plate.
  • Page 67 2-4. Using other system Cautions ■Reversing camera cannot replace the judgment of the driver. While reversing the vehicle, you need to watch through the back view mirror not only the reversing camera, but also the interior and exterior rear view mirrors of the vehicle.

  • Page 68: Driving Information

    2-5. Driving information Preparations before driving ■ ； For driving safety, you must check Seat and seat belts ■ Check tread pattern of tire and its wear, check to see whether there is stone, nail, glass or other sharp object, whether there is bumps, scratch, abnormal wear etc.

  • Page 69: Driving Procedures

    2-5. Driving information Driving procedures Although the vehicle is equipped with safety devices, and you drive safely, but that cannot protect you from accident or injures. If you pay attention to the following aspects, protection could be better for you and others. ■...

  • Page 70: Goods And Luggage

    2-5. Driving information Goods and luggage Stow cargo and luggage in the luggage compartment whenever possible. Be sure all items are secured in place. Be careful to keep the vehicle level. Placing the weight as far forward as possible helps maintain vehicle balance. For better power economy, do not carry unnecessary weight.

  • Page 71: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropriate to the prevailing weather conditions. ■ Pre-winter preparations ●Use washer fluids that are appropriate to the prevailing outside temperatures ●...
  • Page 72 2-5. Driving information Selection of snow chains When installing snow chain, please use correct size of snow chain. Regulations regarding the use of tire chains vary according to location and type of road. Install the chains on rear tires. Retighten the chains after driving ten meters.
  • Page 73 2-5. Driving information Warning ■ Driving with snow chains Observe the following precautions to reduce the risk of accidents. Failing to do so may result in the vehicle being unable to be driven safely and may cause death or serious injury. ●...

  • Page 74: Long Time No Use Vehicle

    2-5. Driving information Long times no use vehicle If you store your vehicle when not using it for a long time, please store it as follows ■ Place it in a dry ventilated area. ■ Apply the parking brake. ■ Battery cannot store for long time, charge it full once per month at least, otherwise battery life could be seriously effected, even worse, battery may become useless.

  • Page 75: Interior Device

    Interior device 3-1. Using air conditioner system Air conditioning system………76 3-2. Using audio speaker system Central control display。………81 Using FM………………………91 3-3. Using Storing device Storage list...…..…..……93 3-4. Other internal device Cigarette lighter...…...…………94 Interior illuminating light..……96...

  • Page 76: Air Conditioning System

    3-1. Using air conditioner system Air conditioning system ■ Switches integrated in Central control panel...
  • Page 77 3-1. Using air conditioner system ■ Fan speed selecting knob position Control the air flow of the Air conditioner and Heater, there are 4 positions， respectively 0 position, 1 position, 2 position, 3 position. 0 position A/C won’t work, 1 position A/C starts to work, 2 position, 3 position air flow becomes stronger and stronger.
  • Page 78 3-1. Using air conditioner system ■ A/C switch When you turn on fan speed selector and mode switch is in cooling mode, press A/C button, compressor starts to work, cooling air comes out from outlet; Cooling indicator is on at same time. Vehicle with no air conditioning system, A/C button won’t work.
  • Page 79 3-1. Using air conditioner system ■ Cooling operation □ Turn fan speed selector from 0 position to 1 position, 2 position, 3 position； □ Turn mode knob left 90 degrees to cooling position； □ Press A\C button down, air conditioner is working； ■...
  • Page 80 3-1. Using air conditioner system ■ Adjust outlet It can guide the air flow to left side, right side, upside or downside. Warning ■ To prevent air conditioning from damage ● When turning on, first turn on fan speed selector dial, then select cooling or heating.

  • Page 81: Using Audio Speaker System

    3-2. Using audio speaker system Central control display ■Panel button function □ 1 Power switch/Volume knob After ignition switch turns on, press this button more than 2 seconds under shutdown state to turn on, press this button more than 2 seconds under working state to turn off；...
  • Page 82 3-2. Using audio speaker system □ Main interface switching button Press this button to return to main interface in any mode. □ Mobile blue-tooth mic. □ Reset button When there is a mess code or other abnormal (e.g. there is no response while pressing the key）...
  • Page 83 3-2. Using audio speaker system ■Basic operation □ 1 Launcher interface When in other interface, touch this icon to return launcher interface; Audio icon, slight touch to adjust the volume of the sound; Day/night icon, automatically changes according to the open and close of the headlight；...
  • Page 84 3-2. Using audio speaker system □ 2 Radio interface Auto scan and store strong signal station，click on X icon on scanning window to stop while scanning. Stored stations store in six rectangle box automatically, click responding rectangle box listen to responding station. If you want to save the station not in storing list，through tuning, click and hold a rectangle box to save it to replace previous station.
  • Page 85 3-2. Using audio speaker system □ 3 Multimedia playing（USB） In main interface click on music/video icon entering multimedia play interface. If no responding device connected, the system prompts no USB device detected, cannot enter playing interface. The system can play WMA / ASX/AVI/DIVX/MOV/3GP/MPG/MP4/ASF etc.
  • Page 86 3-2 Using audio speaker system □ Bluetooth function（phone/music） This system provides the Bluetooth hands free communication function, if your mobile phone is equipped with Bluetooth function, it may build point to point connection with the system，you can dial, receive the phone via the display, play the music on your phone via Bluetooth.
  • Page 87 3-2. Using audio speaker system Open dial page □ 5 Mobile interconnect Baidu CarLife Interface Carlife for Android system：Android mobile download and install “Baidu Carlife”，connect with the system via a USB data cable，mobile needs to start “Developer option/Start USB Adjusting”，After connected click “Carlife” icon on main page to enter mobile interconnect，with audio wake up button to realise human machine dialogue.
  • Page 88 3-2. Using audio speaker system Click this icon to enter music player. CarPlay Mainpage CarPlay for Apple phone： （Apple system）Use mobile data line connected with the system ， click “CarPlay” icon on main page ， enter mobile interconnect, with Wake-up audio button to realise human machine dialogue function.
  • Page 89 3-2. Using audio speaker system ■ The map and music used when mobile interconnecting, is the APP application actually installed in mobile phone, the customer should confirm whether his mobile has the map and music APP installed. ■ “Carlife” Copyright belong to Baidu Carlife. “CarPlay” Copyright belong to CarPlay company.
  • Page 90 Click “Setting” Icon to enter system setting page. System setting has 8 function items, it is ： General setting/Display setting/Sound effect/Date set/Region setting/Language setting/Background paper/System information, Click each function to enter responding page, some settings need passwords to enter.

  • Page 91: Using Audio Speaker System

    3-2. Using audio speaker system General setting: Include touch button sound start/close setting, screen touch sound start/close setting, prohibit video playing while driving setting and mobile interconnect auto start setting, recommend start “prohibit video playing while driving setting” set to ensure driving safety. Display setting: Click “...
  • Page 92 3-2. Using audio speaker system FM radio Panel button function □ 1 Volume/Sound effect setting Turn left and right to control the volume. Press once to enter sound effect setting mode，use volume knob to adjust and select, no operation in 5 seconds，the system will exit setting automatically.
  • Page 93 3-2. Using audio speaker system Under player mode, Play/Pause. □ Under FM mode，play preset No. 2 station； Under player mode, play previous song 10 s and jump to next song. □ Under FM mode，play preset No.3 station； Under player mode, play single song repeatedly or all songs。 □...

  • Page 94: Storage Device List

    □ Reset button 3-3. Using storage device When audio system Freezes up, press this button to restart the machine, all date sets default. Storage device list □ 1 Glove box □ 2 Cup holder □ 3 Glove box Warning ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders.

  • Page 95: Other Internal Device

    3-4. Other internal device ■ Put the cap on before stowing a bottle. Do not place open bottles in the cup holders, or glasses and paper cups containing liquid. The contents may spill and glasses may break. Cigarette lighter Push the cigarette lighter inward, after it is ready, the cigarette light can click back.
  • Page 96 3-4. Other internal device Cautions ■ Push the cigarette lighter into initial position after using, Do not pull the cigarette lighter out while not using. The socket can be blocked by foreign materials to cause short circuits. ■ Do not touch heating element or lighter shell to avoid burning, only the handle can be touched.

  • Page 97: Interior Illumination Light

    3-4. Other internal device Interior illumination light □ ON： Turn on Interior illumination light. □ DOOR（Door control mode） ：The light comes on if any door opened (Incl. Tailgate). After all doors closed, the light goes off 3-4s delay. □ Interior illumination light. OFF：Turn off...
  • Page 98 Warning ■ When the vehicle is driving in the dark, do not turn on the interior illumination light, otherwise it will reduce the visibility in the dark and cause collision.

  • Page 99: Maintenance And Service

    Maintenance and Service Maintenance and Service 4-1. 4-2.Do-it-yourself maintenance Clean and protect vehicle Do-it-yourself ………………98 appearance maintenance…………………104 Clean and protect vehicle ……………………106 Floor Jack ……………………100 interior …..………107 Front panel cover ……102 Anti corrosion measures ………………….………110 Tire ……103 Scheduled maintenance Tire inflation pressure .………112 ………………………114 Wheels...

  • Page 100: Clean And Protect Vehicle Appearance

    4-1. Maintenance and Service Clean and protect vehicle appearance Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and under side of the vehicle to remove any dirt and dust. Wash the vehicle body using a sponge or soft cloth, such as a chamois.
  • Page 101 4-1. Maintenance and Service ■ To prevent deterioration and body corrosion ● Wash the vehicle immediately in the following cases: After driving near the sea coast After driving on salted roads If you see coal tar or tree sap on the paints surface If you see dead insects or insect droppings on the paint After driving in an area contaminated with soot, oily smoke, mine dust, iron powder or chemical substances...

  • Page 102: Clean And Protect Vehicle Interior

    4-1. Maintenance and Service Clean and protect vehicle interior Remove dirt and dust on interior feature, plastic parts and seats using a vacuum cleaner and soft brushes. Wipe dirty surfaces of ethylene plastic parts and leather with a soft cloth dampened with alkalescent diluted detergent, Wipe the surface with a dry, soft cloth to remove any remaining moisture.
  • Page 103 4-1. Maintenance and Service Warning ■ Interior water-proof Be careful not to splash or spill liquid into the vehicle. Do not get any wiring in the vehicle interior wet. Otherwise it will cause electric malfunction or fire. Caution ■Cleaning detergents Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent.

  • Page 104: Anti Corrosion Measures

    4-1. Maintenance and Service Anti-corrosion measures ■ Common factors of vehicle rust □ Wet dirt, dust or odds left on the panel, hole and other part position. □ Scratch caused by gravel or slight accident on paint layer. ■ Environmental factors affected by rusting □...

  • Page 105: Scheduled Maintenance

    Maintenance and Service 4-1. Scheduled maintenance To ensure safe and economical driving, day-to-day care and regular maintenance is essential. We recommend the following maintenance. ■Check and adjust the vehicle according to “Maintenance manual”. Interval of scheduled maintenance, may determine according to the reads of Odometer or vehicle used times，take first arrived one as reference.

  • Page 106: Do-It-Yourself Maintenance

    4-2. Do-it-yourself Maintenance Do-it-yourself maintenance Lots of items are easy, so they can be maintained by self, what you need is some mechanical repairing knowledge and some basic tools. The following service items must be maintained on a regular basis, unless specified: □...
  • Page 107 4-2. Do-it-yourself Maintenance □ Accelerator pedal Make sure that the pedal works properly and check for free play. □ Brake Check the vehicle to see whether it runs bias when braking, braking pad wears much. □ Braking pedal Check the pedal to see whether it works well, its free play is normal, and make sure that there should be reserve stroke when the pedal is full step down.

  • Page 108: Floor Jack

    4-2. Do-it-yourself Maintenance Floor jack When raising your vehicle with a floor jack, position the jack correctly. Improper placement may damage your vehicle or cause injury. Warning ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or serious injury.

  • Page 109: Front Panel Cover

    4-2. Do-it-yourself Maintenance Front panel cover ■ Remove the front compartment lid □ 1 Pull front panel cover lock lever outward, the lock unlocked. □ 2 P ush front panel cover up and raise it slightly and pull backward to remove it. Warning ■...
  • Page 110 4-2. Do-it-yourself Maintenance ■ Inspection Fill washer liquid Washer liquid function is to improve the visibility of your vision. Check the liquid level through fluid box. Washer liquid composition: clean water of hardness less than 205g/1000kg in normal temperature. In lower temperature （-18℃±3℃） ： methanol of 50% concentration liquid.
  • Page 111 4-2. Do-it-yourself Maintenance Adding brake fluid Turn on ignition switch, when the brake fluid warning indicator is on in dashboard, inform you that brake fluid is too low, check the brake fluid level in reservoir to see whether it is between the MAX and MIN lines on the reservoir.

  • Page 112: Tire

    4-2. Do-it-yourself Maintenance Tire Replace tires in accordance with maintenance schedules and tread wear. ■ Checking tires □ New tread □ Tread wear indicator □ Worn tread ■ Tires should be replaced if ： ● You have tire damage such as cuts, splits, cracks deep enough to expose the fabric or bulges indicating internal damage.
  • Page 113 4-2. Do-it-yourself Maintenance Warning ■ When inspecting or replacing tires Observe the following precautions to prevent accidents. ● Do not mix tires of different makes, models, tread patterns or tread wear. ● Do not use tire sizes other than those recommended by our company. ●...

  • Page 114: Tire Inflation Pressure

    4-2. Do-it-yourself Maintenance Tire inflation pressure Tires must keep proper inflation pressure. Check once per month at least. We recommend to perform the check once per two weeks. ■ Driving with incorrect tire inflation pressure may result in the following: ●...
  • Page 115 4-2. Do-it-yourself Maintenance Warning ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...

  • Page 116: Wheels

    4-2. Do-it-yourself Maintenance Wheels If a wheel is bent, cracked or heavily corroded, it should be replaced. Otherwise, the tire may separate from the wheel or cause loss of handling control. ■Wheel selection When replacing wheels, care should be taken to ensure that they are equivalent to those removed in load capacity, diameter, rim width, and offset.

  • Page 117: Air Conditioner Service And Maintenance

    4-2. Do-it-yourself Maintenance Air conditioner service and maintenance If air flow from the vents decreases, please check the refrigerates to see whether it is enough in time, Methods for refilling the refrigerates： Step□ Remove the front panel，watch the peep hole. Step□...

  • Page 118: Inspect And Replace Fuse

    4-2. Do-it-yourself Maintenance Inspect and replace fuse In the cab at the front of the passenger seat, pull out cup-holder, the fuse box can be seen. There are various types of fuses in the fuse box, Check fuses according to mark position on the box to see whether the fuse is good.
  • Page 119 4-2. Do-it-yourself Maintenance ■ Fuse layout and amperage ratings Fuse (12V circuit) Ampere Circuit Outboard power source, power doors and Main fuse windows, gear shifter, braking assist Steering assist enable signal Steering assist Controller Controller power source ABS assist enable signal High-beam, Dip-beam, fog light Headlight Braking light, gear shifter...
  • Page 120 4-2. Do-it-yourself Maintenance ■ After a fuse is replaced ● If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. ● If the replaced fuse blows again, have the vehicle inspected by your Local dealer.

  • Page 121: Bulb

    4-2. Do-it-yourself Maintenance Bulbs You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If the bulb replacement seems difficult to perform, contact your Local dealer. ■Instruction Turn on all light switches to check whether it works or not. If the light does not work, generally speaking it is caused by broken fuse or bad bulb.

  • Page 122: Bulb

    4-2. Do-it-yourself Maintenance ■ General rule □ Make sure the light is off before replacing, check the contact part to see whether it is oxidized or not. □ Replace the bad bulb with one of the same type and power rating. □...
  • Page 123 4-2. Do-it-yourself Maintenance Warning ■ Replacing light bulbs Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. Replacement of higher watts than original bulb is not allowed. ■ To prevent damage or fire Make sure bulbs are fully seated and locked.

  • Page 124: Battery Maintenance

    4-2. Do-it-yourself Maintenance Lead acid battery maintenance □ Surface of battery, pole post and connect bolt, connect wire should be clean and dry. □ Connection of the battery must be good. Check the battery connection wire to see whether it is firm and nut whether it is loose to prevent from causing electric spark during driving to burn the pole terminal.
  • Page 125 4-2. Do-it-yourself Maintenance Warning ■ Battery replacement You must go to your dealer for battery replacement by qualified technician. Replacing the battery yourself is not allowed. Otherwise it will cause electrical parts damage, even worse it may cause serious safety accident. ■...

  • Page 126: Li-Ion Battery Maintenance

    4-2. Do-it-yourself Maintenance Li-ion battery maintenance and service □ Periodically charge the battery to full with the charging device to keep the battery in best state. (Recommend charging the battery fully at least once a week) □ If you do not drive the vehicle in a long time, you must charge it once a month in slow mode, otherwise the battery may be over-discharged, causing the performance to be reduced.

  • Page 127: Traction Motor Maintenance

    4-2. Do-it-yourself Maintenance Traction motor maintenance Remove the silt and its attachments from the motor housing to facilitate heat dissipation.

  • Page 128: Rear Bridge Maintenance

    4-2. Do-it-yourself Maintenance Rear bridge maintenance □ Remove the mud and dust on the rear bridge breathing plug often. □ Check the filling hole bolt and drain bolt often, if there is leakage, please tighten in time or replace the gasket. □...

  • Page 129: Important Information

    When there is trouble 5-1. Important information 5-3. .Common electrics trouble and If need towing the vehicle……128 it check procedures If the vehicle is abnormal..…132 Common electrics trouble and it check procedures....…137 5-2. Emergency measures If warning light comes on or 5-4.

  • Page 130: If Vehicle Needs Towing

    5-1. Important information If vehicle needs towing If towing is necessary, we recommend having your vehicle towed by your Local dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Incorrect towing would be dangerous. Use a safety chain system for all towing and abide by all state/provincial and local laws.
  • Page 131 5-1. Important information ■ Towing angle When using hook to tow the vehicle, Keep the towing angle less than 15°. Larger towing angle could damage the vehicle, even worse make the vehicle turn over, towing the vehicle out from sand, snow and mud, keep the towing cable straight, do not form the side angle with towing hook.
  • Page 132 5-1. Important information Towing with transporting vehicle ■ Correct towing manners Manner □ The vehicle must transport with four wheels off ground. Set the parking brake firmly. Manner □ The vehicle must transport with four wheels off ground. Manner □ Towing the vehicle with front wheel lifted, set gear shifter to N, release the parking brake.
  • Page 133 5-1. Important information Caution ■ Never tow this vehicle from the rear with the all wheels on the ground, This may cause serious damage to the motor and transmission. ■ When the vehicle has trouble, if there is distinct resistance to push the vehicle, do not push with force, this may damage the motor.

  • Page 134: If The Vehicle Is Abnormal

    5-1. Important information If the vehicle is abnormal If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your local dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle （Water dripping from the air conditioning after using is normal.) ●...

  • Page 135: Emergency Measures

    5-2. Emergency measures If warning light comes on or Buzzer on…… Calmly perform the following actions if any of the warning lights turn on or flash. If a light turns on or flashes, but then turns off, this does not necessarily indicate a malfunction in the system.
  • Page 136 5-2. Emergency measures Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning light Warning light/Details Correction procedure Door not fully closed warning light Check and ensure that Indicates that a door is not fully all doors are closed.

  • Page 137: If Tire Is Blown

    5-2. Emergency measures If tire is blown If the tire is blown, must be mended or replaced. ■ Before jacking up the vehicle ●Stop the vehicle on a hard, flat surface where it is not a main road. ● Set the parking brake. ●...

  • Page 138: If Vehicle Gets Trapped

    5-2. Emergency measures If vehicle gets trapped Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Step□ Turn ignition switch off. Set the parking brake and put shifting knob or shift lever in N position. Step□...

  • Page 139: Common Electrics Trouble And It Check Procedures

    5-3. Common electric trouble and check. Common electric trouble and its check procedures Troubles Handling procedures Check “emergency button” to see whether it raised or not （For lead acid battery type） Check “small battery” to see whether its voltage is less than 12V or not.
  • Page 140 5-3. Common electric trouble and check Troubles Handling procedures Check “A/C（30A）” fuse whether it is blown or not Check outlet to see if air is flowing A/C not work Check the mode switch is at cooling position Check A/C button is pressed down and A/C indicator in meters is always on Check “Wiper（20A）”...
  • Page 141 5-3. Common electric trouble and check Troubles Handling procedures Check “Headlamp (20A）” fuse whether it is blown or not Check headlight relay to see whether it is damaged or not Headlamp not Check left hand switch to see if it’s in work position, Indicator is on or not...
  • Page 142 5-3. Common electric trouble and check Troubles Handling procedures Check “Horn （15A） ” fuse to see whether it is blown or not Check steering wheel conductive disk to see whether it is well contact with combine switch horn post. Horn not work Check horn control relay to see whether it is damaged.
  • Page 143 5-4. Cautions for electric repairing Cautions for electric repairing 1、Assemble or dismantle the parts in accordance to parts assembling sequence, ensure the tightening torque meets the requirement. Electrical part wire post tighten torque list as following： Tighten Name Bolt spec. Note （Nm）...

  • Page 144: Cautions For Electric Repair

    5-4. Cautions for electric repairing 6. Replace the electrical parts with genuine parts please, if need to replace with other makes, replacing parts load power do not exceed the original parts load power (such as Bulb, horn, cigarette lighter, buzzer)； 7.

  • Page 145: Specification

    Vehicle specification 6-1. Specification VIN………..……………….144 Technical data…...…………145 6-2. Loading instruction Loading instruction………149...
  • Page 146 6-1. Specification Vehicle identification ■ Vehicle identification number（VIN ） Vehicle identification number (VIN) is a solely 17 digit number to identify the vehicle. This VIN is not only stamped on Statutory plate, but also punched on the support beam of front part , Remove the front panel cover ,you can see it.
  • Page 147 6-1. Specification Technical data 4.5kw Lead acid battery type Item Data Item Data Rated Power Dimensions(mm) 2990×1438×1585 4.5/3000 （kw/rpm） (L×W×H) Wheelbase Nominal 2047 (mm) voltage Fr.／Rr. wheel 1230 Motor type PMSM track (mm) Min. ground clearance Insulating (Without load) level (mm) Min.
  • Page 148 6-1. Specification Technical data 4.5kw Li-ion battery type Item Data Item Data Dimensions(mm) Rated Power（kw/rpm） 2990×1438×1585 4.5/3000 (L×W×H) Wheelbase 2047 Nominal voltage (mm) Fr.／Rr. wheel track 1230 Motor type PMSM (mm) Min. ground clearance Insulating level (Without load) (mm) Min. turning radius Total capacity of 4500 64V 120Ah...
  • Page 149 6-1. Specification Technical data 6.0kw Li-ion battery type Item Data Item Data Rated Power Dimensions(mm) 2990×1438×1585 6.0/3000 （kw/rpm） (L×W×H) Wheelbase 2047 Nominal voltage (mm) Fr.／Rr. wheel track 1230 Motor type PMSM (mm) Min. ground clearance (Without load) Insulating level (mm) Min.
  • Page 150 6-1. Specification Caution ■ With one of the following situations , it will lead to changes in the vehicle's maximum continuous mileage. ●Terrain: Driving on flat terrain will increase range. Driving on hilly-road or unpaved road will reduce range. ●Speed and individual driving style: Driving at a steady speed (30km/h) will increase range, Frequent starting, braking, acceleration and deceleration will reduce range.
  • Page 151 6-2. Loading instruction Loading instruction □ When loading, fixes the whole vehicle with a frame, forklifts the vehicle to the transporting trucks and fixes it firmly to ensure transport safety. □ When unloading, forklifts the vehicle down, remove the frame and send back to the factory for reuse.

This manual is also suitable for:

S200

Table of Contents
