LCD Projection TV
SERVICE MANUAL
CHASSIS : MB-03CA
MODEL : RT-44/48/52SZ50LP
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
website:http://biz.LGservice.com
e-mail:http://www.LGEservice.com/techsup.html
