- Page 1 Version 1.0 Revision Date: Jul.22.2019 User’s Manual ROC285B series 19” 1U Rack-mount Intel® Q370 Rugged System www.perfectron.com...
-
Page 2: Safety Information
Safety information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device. -
Page 3: Electrical Safety Operation Safety Statement Revision History
Revision History Revision Date (yyyy/mm/dd) Changes V1.0 2019/9/23 Initial release Packing list □ 19” 1U Rack-mount Intel® Q370 Fanless Rugged System □ Accessories Item Description Q’ty Driver CD Bracket Ear Screw for fixing Bracket Ear M4 L:7.8mm If any of the above items is damaged or missing, please contact your local distributor. Ordering information Description Model Number... -
Page 4: Table Of Contents
Table Contents SAFETY INFORMATION ............................. 1 ............................... 1 LECTRICAL SAFETY ............................... 1 PERATION SAFETY ................................. 1 TATEMENT REVISION HISTORY ..............................2 PACKING LIST ................................2 ORDERING INFORMATION ............................2 TABLE CONTENTS ..............................3 CHAPTER 1: PRODUCT INTRODUCTION ........................4 1.1 K ................................ -
Page 5: Chapter 1: Product Introduction
Chapter 1: Product Introduction 1.1 Key Features System CPU Type Intel® 14nm Coffee Lake-S Processor (Desktop) socket (LGA1151) Core™ i7-8700T 2.4 GHz (12M Cache, 25W) Core™ i5-8500T 2.1 GHz (9M Cache, 25W) Core™ i3-8100T 3.1 GHz (6M Cache, 25W) Chipset Intel®... -
Page 6: Front Panel Components
1.2 Front Panel Components Power Button w/LED USB 2.0 x 2 2.5” HDD tray x 2 HDD LED 1.3 Rear Panel Components COM1: RS232 USB 3.1 x 4 DisplayPort x 3 LAN1 (Intel® I210) LAN2 (Intel® I219LM) Audio jack (Mic-in, Line-out) PCIex16 Expansion Slot IEC C14 Inlet, 90V to 264V AC-in... -
Page 7: Mechanical Dimensions
1.4 Mechanical Dimensions... -
Page 8: Chapter 2: Jumpers And Connectors
Chapter 2: Jumpers and Connectors 2.1 Connector & LED Pin Definitions LAN1 and LAN2 LED AUDIO: LINE-OUT/MIC-IN Pin Definition Line-out Mic-in COM1: RS232 Pin RS-232 DCD- DTR- DSR- RTS- CTS- PWR (5V) -
Page 9: Chapter 3: Getting Started
3.1 2.5" Easy Swap SSD installation ROC285B series supports two 2.5" Easy Swap SSD • Use Tri-angle security key to open keylock and pull out the 2.5” HDD tray. -
Page 10: Chapter 4: Ami Bios Utility
Chapter 4: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 4.1 Starting To enter the setup screens, perform the following steps: Turn on the computer and press the <Del> key immediately. ... -
Page 11: Main
4.3 Main The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. System Date Use this function to change the system date. Select System Date using the Up and Down <Arrow> keys. Enter the new values through the keyboard. -
Page 12: Advanced
4.4 Advanced The Advanced Menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference. Setting incorrect field values may cause the system to malfunction. -
Page 13: Cpu Configuration
4.4.2 CPU Configuration... -
Page 14: Acpi Setting
4.4.3 ACPI Setting 4.4.4 Smart Setting... -
Page 15: F81866 Super Io Configuration
4.4.5 F81866 Super IO Configuration... -
Page 16: Hardware Monitor
4.4.6 Hardware Monitor 4.4.6.1 Smart Fan Mode Configuration... -
Page 17: Platform Function
4.4.7 Platform Function... -
Page 18: Serial Consolr Redirection
4.4.8 Serial Consolr Redirection... -
Page 19: Nvme Configuration
4.4.9 NVMe Configuration 4.4.10 USB Configuration... -
Page 20: Csm Configuration
4.4.11 CSM Configuration 4.4.12 SATA Configuration... -
Page 21: Chipset Menu
4.5 Chipset Menu 4.5.1 System Agent (SA) Configuration... - Page 22 4.5.1.1 Graphics Configuration 4.5.1.2 PEG Port Configuration...
- Page 23 4.5.1.3 GT-Power Management Control...
-
Page 24: Pch-Io Configuration
4.5.2 PCH-IO Configuration... - Page 25 4.5.2.1 PCI Express Configuration...
- Page 26 4.5.2.2 USB configuration...
- Page 27 4.5.2.3 HD Audio Configuration...
-
Page 28: Security Menu
4.6 Security Menu Use the Security Menu to establish system passwords Administrator Password Set administrator password. User Password Set user Password. -
Page 29: Boot Menu
4.7 Boot Menu This section is used to configure the boot features. Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Bootup NumLock State Select the keyboard NumLock state Quiet Boot Enables or disables quiet boot option... -
Page 30: Save & Exit
4.8 Save & Exit This screen provides functions for handling changes made to the BIOS settings and the exiting of the Setup program. Save Changes and Exit Exit system setup after saving the changes Discard Changes and Exit Exit system setup without saving changes Restore Defaults Restore/Load default values for all the setup options...
