Perception Triumph 13 footrest kit Manual

Kit to fit OrigiNZ footrests to a Triumph 13

This kit should contain the following:
2x footrest rails with pedals attached
4x M5 x 25 screws
You will also require some tools to fit this kit:
• Drill with 5mm drill bit
• Phillips screwdriver
Please read these instructions carefully before fitting!

Step 1 - Position for OrigiNZ footrest rails

In the footwell of the Triumph 13, above the moulded in footrests are flat recessed
areas designed for fitting the OrigiNZ footrest rails. Each footrest rail has two fixing
points, one at either end. The fixing point closest to the kayak seat is marked in each
of these areas by a small 2mm dimple. These marks are 215mm along from the seating
end of the recess and 14mm down from the top edge of the recess.
If there is not a marked dimple in exactly this place then you will need to mark this
position. The height of this position is extremely important, too low and the footrest
pedal will catch when adjusting, too high and the washer will not fit on the back of the
fixing screw. The position of the rail along the recess is the optimal distance allowing
easy access through the front oval hatch to place washers and nuts to secure the rails.
If you wish to change this position, make sure you will be able to reach the rear of
each screw before drilling any holes.
www.perception.co.uk
4x M5 washers
4x M5 nylon insert nuts
• 8mm spanner
