2
C
CD-ROM
5.
Install HDD to Driver Bracket
1. Attach HDD underneath the Drive Bracket
2. Tighten HDD with screws "B" (x4)
4.
Install CD-ROM to Driver Bracket
C
1
1. Slide in CD-ROM to Drive Bracket
2. Tighten CD-ROM with screws "C"
B
B
B
B
HDD
1 1
Travla Series
Model : C134
2" x 7" x 10" (HxWxL)
QUICK START
USER GUIDE
2 2
Index
2) Remove Drive Bracket from
motherboard
3) Install (0.8") memory
4) Install CD-ROM to Drive Bracket
5) Install Hard Drive to Drive Bracket
Advertisement
Table of Contents
Summary of Contents for Travla C134
- Page 1 3) Install (0.8") memory 4) Install CD-ROM to Drive Bracket Travla Series 5) Install Hard Drive to Drive Bracket Model : C134 2" x 7" x 10" (HxWxL) QUICK START USER GUIDE CD-ROM 1. Slide in CD-ROM to Drive Bracket 2.
- Page 2 Front Panel Screw Idenfication Guide Remove Drive Bracket from MB Drive Bracket Power Switch Power LED USB 2.0 HDD LED Microphone Speaker A. M3 (8mm) socket screw B. M3 (5mm) screw IEEE 1394 C. CD-ROM screw D. Thumb screw E. Hex washer screw I/O Gaskets I/O gasket for EPIA-M CD-ROM...
