Forms+Surfaces AXIS RECEPTACLE Attachment Instructions

AXIS RECEPTACLE
TM

MATERIALS INCLUDED

b
a
STEP BY STEP TO ATTACH TWO AXIS RECEPTACLES

Insert top attachment plate

• Each Axis Receptacle comes with one
attachment plate and four screws. To
attach two receptacles you will need two
attachment plates and eight screws.
• Insert top attachment plate (b) into
slot along the straight flat end of the
receptacle, below the lid.
• Align holes in top attachment plate with
holes in top receptacle frame.
T 800.451.0410 | www.forms-surfaces.com
© 2015 Forms+Surfaces® | All dimensions are nominal. Specifications and pricing subject to change without notice. For the most current version of this document, please refer to our website at www.forms-surfaces.com.

TOOLS NEEDED

philips head
screwdriver

Attach top attachment plate

• Insert 1/4"-20 x 1/2" Phillips bit pan
head screws (a) through receptacle
frame and top attachment plate to secure
top attachment plate to receptacle.
• Use Philips head screwdriver to tighten
screws until snug.
ATTACHMENT INSTRUCTIONS

Insert bottom attachment plate

• Insert bottom attachment plate (b) into
slot along the straight flat end of the
receptacle, below the body and above
the base.
• Align holes in bottom attachment plate
with holes in bottom receptacle frame.
page 1 of 2 | 09-17-15
