Summary of Contents for Odyssey MAN3067
- Page 1 Smart Terminal Installation, Commissioning & Operation MAN3067...
-
Page 2: Table Of Contents
SMART TERMINAL INSTALLATION & COMMISSIONING Table of Contents Page No. Introduction ..........................3 Mechanical ..........................4 Mounting the Enclosure ....................4 2.1.1 Enclosure Details..................4 2.1.2 Fixing the Chassis to the Wall ..............4 2.1.3 Board Removal / Replacement ..............5 2.1.4 Removing the Knockouts ................ -
Page 3: Introduction
Controls have tactile and audible feedback of operation. All terminals cater for 2.5mm cables. SmartTerminal connects to the Odyssey Fire Alarm Control Panel (FACP) via the RS485 multidrop communication port. Generally it is designed to be used anywhere where the status of the FACP is required to be monitored by local personnel and limited control is required. -
Page 4: Mechanical
SMART TERMINAL INSTALLATION & COMMISSIONING Mechanical SmartTerminal is supplied in an ABS cabinet and consists of; The Main Card, with all controls and indicators mounted directly onto it 1 X Termination Board 2 X ABS door keys 2 X 003 Enable / Disable keys ... -
Page 5: Board Removal / Replacement
SMART TERMINAL INSTALLATION & COMMISSIONING 2.1.3 Board Removal / Replacement If a PCB has to be removed the following precautions should be observed; Removing the door will provide better access to the boards and will ensure the hinges are not accidentally stressed. -
Page 6: Removing The Knockouts
SMART TERMINAL INSTALLATION & COMMISSIONING 2.1.4 Removing the Knockouts The knock-outs should be removed with a sharp tap in the rim of the knock-out using a flat broad- bladed screwdriver. Note: Use of excessive force could damage the enclosure around the knock-out. ... -
Page 7: Installation & Cabling
SMART TERMINAL INSTALLATION & COMMISSIONING Installation & Cabling The SmartTerminal is then connected to the FACP as shown below. SHIELDED COMMS CABLE +24VDC SHIELD COMMS AUX OUT1 INPUTS RELAY 1 RELAY 2 RELAY 3 LOOP 1 LOOP 2 MONITORED O/PS AUX OUT2 RS485+ RS485-... -
Page 8: Setting The Address
SMART TERMINAL INSTALLATION & COMMISSIONING Setting the Address PRINTER LCD BL PARALLEL SERIAL BRD82ZICC4- 22/09/2009 N1236 BUZZER SILENCE FAULT BUZZER RN10 SW27 CONFIG RN11 RN12 DIAGNOSTIC / RESET CONFIG LED Main Control PCB BRD82ZICC SW28 COMMS RN14 RN13 RN15 RN16 RN19 PWR LINK PWR LINK RN20... -
Page 9: Setting The Smartterminal In Loopmaster
SMART TERMINAL INSTALLATION & COMMISSIONING Setting the SmartTerminal in LoopMaster This section assumes the engineer has experience in the use of LoopMaster and hence has an understanding of it operation. To commence the programming go to the “Tree View” within LoopMaster as shown below. - Page 10 SMART TERMINAL INSTALLATION & COMMISSIONING Figure 8 The SmartTerminal add on List View appears immediately below the SmartTerminal add on Details View and consists of a summary of all available SmartTerminal add ons assigned to the current panel. In the above, there are 2 add on SmartTerminal’s assigned to this panel, entitled ‘Panel Add- on 1’...
-
Page 11: Operation
SMART TERMINAL INSTALLATION & COMMISSIONING Operation The operation of SmartTerminal can be considered to be in one of three states, these are; 1. Power up - when the SmartTerminal is initialising 2. Normal - when the SmartTerminal address has been set and is communicating with the FACP, reporting normal / abnormal conditions and controlling the FACP via the front panel controls 3. -
Page 12: Controls And Indicators
SMART TERMINAL INSTALLATION & COMMISSIONING Controls and Indicators All controls, except for the Enable / Disable keyswitch, are of a momentary push button style. Figure 10: SmartTerminal Front Panel Layout KEYSWITCH Access levels There are two levels of access. Access level 1 only the previous and next front panel controls are operative. All other controls operate in access level two. - Page 13 SMART TERMINAL INSTALLATION & COMMISSIONING (Yellow) The LED is illuminated when the sounders have been silenced in response to a FIRE condition, indicating the resound function is active. Silence / Resound Press to silence the alarm devices (associated LED illuminated). Press again to re-enable the alarm devices (associated LED extinguished).
- Page 14 SMART TERMINAL INSTALLATION & COMMISSIONING (Red) The LED is illuminated when one or more devices are reporting a FIRE condition and are not disabled. Silence Buzzer Silences the panel buzzer. Buzzer is activated under the following conditions: Alarm condition ...
- Page 15 SMART TERMINAL INSTALLATION & COMMISSIONING (Yellow) The LED is illuminated when one or more zone detectors, loop devices or panel outputs are disabled. Evacuate Turns on all alarm devices (visual and aural) outputs and activates the Fire indicator. The SILENCE / RESOUND or RESET control shall turn off all alarm devices (visual and aural).
-
Page 16: Lcd Screen Format
SMART TERMINAL INSTALLATION & COMMISSIONING LCD Screen Format There are 3 events that can be reported and displayed by SmartTerminal. The types of event are; Fire Faults and Disables. The types of events are only associated with sensors and detectors hence faults associated with modules, loops O/C –... - Page 17 SMART TERMINAL INSTALLATION & COMMISSIONING Normal / Default: The format for reporting that everything is normal is: <DATE> <TIME> ACCESS LEVEL: 1 <USER DESCRIPTOR LINE 1> <USER DESCRIPTOR LINE 2> <SYSTEM STATUS> <DAY MODE-MAN I/O> The screen is only displayed when there are no alarms, fault or disables on the panel. The default screen is only displayed when there are no device alarms, device faults or device disables present on the system.
-
Page 18: Specifications
SMART TERMINAL INSTALLATION & COMMISSIONING Specifications MECHANICAL Dimensions ABS Cabinet BX05: (mm) 195mm (H) x 345mm (W) x 50mm (D) Dimensions ABS Cabinet BX1: (mm) 300mm (H) x 360mm (W) x 100mm (D) ENVIROMENTAL Temperature: -5ºC to + 55ºC Humidity: 25% to 75% non condensing INPUT POWER Operating Voltage (nominal):... -
Page 19: Trouble Shooting Chart
SMART TERMINAL INSTALLATION & COMMISSIONING Trouble Shooting Chart Problem Solution Normal Supply LED not illuminated Check supply voltage it should be set to 27.2VDC. Nominal fault voltages are - Low = (<18VDC) High = (> 28VDC ) FACP Earth Fault LED illuminated Check all input and output cabling and wiring assemblies for short to ground FACP System Fault LED illuminated... - Page 20 SMART TERMINAL INSTALLATION & COMMISSIONING UNCONTROLLED DOCUMENT...
