Summary of Contents for BTI Wireless CP880
- Page 1 CP880+CR650 CP880+CR650 User Manual...
-
Page 2: Table Of Contents
CP880+CR650 Index CHAPTER 1: Introduction ........................4 1 Introduction to Outdoor CPE with Router ................4 2 Application Diagram ....................... 4 CHAPTER 2: Product Overview ......................5 1 Important Note for Using This Router ..................5 2 Packing List ..........................5 3.1 Panel of router ...................... - Page 3 CP880+CR650 5.6 IPv6 ..........................57 5.7 System ........................58 FAQs ..............................71 FCC Regulations: ..........................72 FCC RF Radiation Exposure Statement .................... 72...
-
Page 4: Chapter 1: Introduction
CHAPTER 1: Introduction 1 Introduction to Outdoor CPE with Router Congratulations on your purchase of the CP880+CR650 (Outdoor 4G/LTE Router). It includes two parts, an indoor unit and an outdoor unit. ODU can provide strong accessibility to the LTE network, and has been designed to meet industrial-grade IP67 dustproof and waterproof standard. -
Page 5: Chapter 2: Product Overview
Service Provider or have it repaired at a qualified service center. 2, Do not plug and unplug SIM card when device is power on. 3, It is mandatory to earth ground the CP880+CR650. Improper grounding not only could damage the unit but also all equipments connected to it. -
Page 6: Panel Of Router
CP880+CR650 3 Device Description 3.1 Panel of router Router LED indicator operation 3.2 Panel of ODU ODU LED indicator operation... - Page 7 CP880+CR650...
-
Page 8: Install Sim Cards
CP880+CR650 CHAPTER 3: Hardware Installation Please make sure that you are familiar with all accident prevention and Safety procedures necessary for working at height and with electricity before start to install the device. DO NOT install the ODU during a lightning storm. -
Page 9: Mount The Odu
CP880+CR650 Step 1 CAT5e cable to thread through the cable glands. Step 2 Connect the end of the CAT5e Ethernet cable to the PoE port of the ODU. Step 3 Wring the cable glands into ODU and seal tightly. Make sure you have inserted the SIM card into the ODU. -
Page 10: Attach The Stainless-Steel Clamp To The Enclosure
CP880+CR650 Step 3: 3.1: Insert B at the back end of C 3.2: keep B close to C 3.3: then tighten A 1, Care must be taken to prevent damage to the entry threads when organizing and installing cable glands 2, Don’t install cable glands while the circuits are live. -
Page 11: Wall Or Pole Mounting
CP880+CR650 3.3 Wall or Pole Mounting Mounting on Wall (The built-in antenna is not recommended for wall hanging type, preferred to use Pole mounting method, it can be convenient to adjust the direction of the antenna.) When the ODU terminal is hanging on the wall, the specific mounting as follows: When install ODU on the wall, fixed four screws spacing is 68mm on wall, then the terminal equipment aligns the screws. -
Page 12: Choose Location
CP880+CR650 4 Choose Location The ODU can be mounted on an antenna pole or mast or on a wall using the supplied mounting bracket. Choose a mounting point that is sturdy enough to hold the ODU, even during high winds. -
Page 13: Connect The Router
CP880+CR650 5 Connect the Router Place a CAT5e Ethernet cable (not included) from the location of your intended Router to the desired PC location. If you intend to use cable clamps or other methods to secure the cable, do not tighten them until... -
Page 14: Chapter 4: Software Features
CP880+CR650 CHAPTER 4: Software Features 1 Getting Started 1.1 Welcome to the CPE In this document, the LTE (Long Term Evolution) CPE (customer premises equipment) will be replaced by the CPE. Carefully read the following safety symbols to help you use your CPE safely... -
Page 15: Login The Web Management Page
CP880+CR650 1.3 Login the Web Management Page Launch web browser to login the web management page to configure and manage the CPE. The following procedure describes how to use a computer running Windows XP and Internet Explorer 7.0 to log in to the web management page of the CPE. - Page 16 CP880+CR650 To ensure your data safety, it is recommended that you turn on the firewall, and conserve your login and FTP password carefully.
-
Page 17: Overview
CP880+CR650 2 Overview 2.1 Viewing Current Connection To view the current connection, perform the following steps: Choose Overview; In the Current Connection area, view the connection status, such as DL/UL Data Rate and Online time. As shown in Figure 2-1. -
Page 18: Viewing Lte Status
CP880+CR650 2.3 Viewing LTE Status To view the LTE network status, perform the following steps: Choose Overview; In the LTE Status area, view the information about Connect status, Mode, Cell ID, Signal quality and so on. As shown in Figure 2-3. -
Page 19: Statistics
CP880+CR650 3 Statistics 3.1 Viewing CPU Usage To view the CPU usage, perform the following steps: Choose Statistics; In the CPU Usage area, view the CPU usage information, such as Current CPU usage, Max CPU usage, Min CPU usage. As shown in Figure 3-1.
