- Page 1 Galaxy IMA G4100/G2100 N x E1/T1 to Ethernet Gateway User Manual REV. 1.1 April 02, 2003 Yoda Communications Inc.
- Page 2 1. Introduction 5. Front Panel LED Indicators Galaxy 4100 is a broadband Ethernet gateway that converts electrical and protocol There are 10 LED indicators for G4100 to indicate operation status. conversion between data from 4 x E1/T1 to Ethernet 10 BaseT interface. Galaxy 4100 supports E1/T1 framed modes with different line codes plus line build-out (LBO) capability.
- Page 3 DSX-1 533~655 Ft. 120 Ohms Note: “X” means can be set either on or off. 100 Ohms 100 Ohms Yoda Communications, Inc. Headquarters 2F, No. 3-1, Industry East Road IX, Science Based Industrial Park Hsin Chu, 300, Taiwan Tel +886-3-5632323...
