StarTech.com ATXPOW450PRO Instruction Manual page 3

4
Product Specifications
Dimensions
Weight
Input Voltage
Output Power
Connectors
MTBF
Safety Approvals
AC INPUT
DC OUTPUT:
5.9 x 3.35 x 5.87 inches (150 x 85 x 149mm)
ATXPOW450PRO: 4.6 lbs (2.08 kg)
ATXPOWR450GB: 5.41 lbs (2.45 kg)
115/230V
450W
8 x 4-pin-LP4-female
3 x small-internal-power
1 x 20-pin-ATX-motherboard-adapter
1 x 4-pin extended ATX power 12V plug and Aux
plug for Pentium 4
60,000 Hours
TUV, UL, CSA, CE, FCC, CB
Voltage 115V~ Current 10A
Voltage 230V~ Current 5A
Frequency 50~60Hz
+3.3V(30A)
+5V(45A)
+12V(15A)
-5V(1A)
-12V(1A)
+5V(2.5A)
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1
