Fabdec DARI-KOOL GALA-KOOL Pro Installation And Operation Manual

Universal tank control standard version 2.5
Hide thumbs
Table of Contents

Advertisement

Quick Links

2020A
Part No: GPRO-MAN-V2.5-EN
Installation and Operation Manual
GALA-KOOL Pro Universal Tank Control
Standard version 2.5
Page 1
REV F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DARI-KOOL GALA-KOOL Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Fabdec DARI-KOOL GALA-KOOL Pro

  • Page 1 2020A Part No: GPRO-MAN-V2.5-EN Installation and Operation Manual GALA-KOOL Pro Universal Tank Control Standard version 2.5 Page 1 REV F...

  • Page 2: Table Of Contents

    Contents Introduction Function overview Page 4 Safety Electrical safety Page Intended use Page Wiring, screening, earthing Page 7 Electrical connection Connection diagram Page Technical data Technical data of control unit Page Fitting the sensor Page Operation Setting the date and time Page Operation in levels Page...
  • Page 3 Contents Other information Butterfly valve (manual or pneumatic) Page Safety switch for manual butterfly valve Page 75 Robot control Page .3.1 Cleaning release by robot Page Different variants for cooling start delay Page Compressor switch-on delay / pre-agitating Page 80 Emergency cooling / sensor failure Page Sensor correction procedure...

  • Page 4: Introduction

    1. Introduction 1.1 Function overview Gala-Kool Pro is a universal tank control unit which combines all the basic functions in one device: - milk cooling control - comprehensive cleaning control - an extended robot nterface - an extended tank monitor All basic functions can be selected and operated from the working level.
  • Page 5 1. Introduction Continuous stirring mode From OFF mode, the agitator can be switched on by pressing a button and then switched off again by pressing the OFF button. Parameter [C25] can be used to set the time after which the agitator is to switch off automatically.

  • Page 6: Safety

    2. Safety 2.1 Electrical safety The controller itself and the associated control circuits and load circuits must be pro- tected separately and in accordance with the local regulations. The separate protection of the control- and load circuit must be carried out according to local conditions! In order to prevent destruction of the relay or semiconductor relay outputs in the event of a short-circuit, the load circuit should be fused to the maximum permissible output...

  • Page 7: Intended Use

    2. Safety 2.2 Intended use These operating instructions contain important technical and safety information. Please read carefully before installation and before any work on or with the regulator. Universal tank controllers Gala-Kool Pro are designed to control wash systems, con- densing units, alarms etc.

  • Page 8: Electrical Connection

    3. Electrical connection 3.1 Connection diagram Electrical connections must be as shown in the diagram below. Use cable bushes. Make sure that cables cannot chafe. Observe relay current rating. In all cases use contactors for pump, compressor and heater. Do not feed digital inputs with external voltage! Use potential-free Default configuration The assignment of components to the relay outputs...

  • Page 9: Technical Data

    4. Technical Data 4.1 Technical data of control unit Operating voltage 230V AC +/-10%, 50/60 Hz Relay contact 1 relays max. switching current A AC1 - 250V AC x 1 A AC1 - 250V AC max. switching voltage 250V AC - 50..60 Hz Display 13 mm LED-Display, digits...

  • Page 10: Operation

    5. Operation 5.1 Setting the date and time In the event of a power cut, the date and time are retained for up to 5 days. After that they must be re-entered. When the power is connected ..there are two possible displays: 1.) Time is lost: 4 dashes are shown: The date and time must be re-entered.

  • Page 11: Operation In Levels

    5. Operation 5.2 Operation in levels Working level General cooling parameters C parameter code: C212 Extended cooling parameters P parameter code: D345 The working level is used for operation and control in every- General cleaning parameters n parameter code: B454 day operation.

  • Page 12: Button Functions

    5. Operation 5.2.1 Button functions „OFF“ button To change to a different mode, always first press the “OFF” button. active modes are closed down when the OFF button is pressed. Switch control unit to STAND-BY Close down cleaning mode or continuous stirring mode prematurely Acknowledge error Change to programming mode (hold down button for 3 seconds) „SET“...

  • Page 13: Meaning Of The Led's

    5. Operation 5.2.2 Meaning of the LED‘s LEDs in cooling mode LED "AGITATOR” during cooling mode Agitator is switched on LED "COMPRESSOR“ Compressor contactor is switched on Compressor contactor is switched off flashing Pause time compressor (pendulum protection) LED "T1” or „T2" T1 on Set target temperature for "T1"...

  • Page 14: Operation Modes

    5. Operation 5.2.3 Operation modes OFF mode The current time is displayed. The control unit is on stand-by mode LEDs are out All output relays are deactivated (Exceptions: robot, butterfly valve and tank monitor alarms may be active) The other operating modes can only be selected from OFF mode. It is not possi- ble to switch directly between the different modes.
  • Page 15 5. Operation The “Agitator” LED lights up The “Compressor” LED lights up only when the compressor is actually running. - it is not lit if the milk temperature is lower than the target value it flashes for the duration of the min pause time for the compressor [P71] The “T1”...

  • Page 16: Operation Of Working Level

    5. Operation 5.2.4 Operation of working level Milk collection Complete emptying of tank into collection tanker Ensure that the green LED of the tank monitor indicator is lit Press the OFF button To stir the milk for a short period: briefly press the AGITATOR button. After the desired stirring time, stop the agitator by pressing the OFF button.
  • Page 17 5. Operation 5.2.4 Operation of working level Cleaning mode Press the “WASH” button: (from OFF mode Cleaning proceeds automatically in line with your settings. Depending on the setting in [r97], the display indicates the current cleaning stage or the temperature. Exception: During the heating stages the current water temperature is displayed.

  • Page 18: Cleaning

    6. Cleaning 6.1 Cleaning methods (cooling tank-configurations) 6.1.1 Circulation cleaning with a beaker Cold water water Heater Hot water Cold water alcaline / valve valve or acid detergent Agitator Pump Drain valve Cleaning method for milk cooling tanks, where alkaline and acidic detergents are supplied either by a drawer or a fixed beaker.

  • Page 19: Displacement Cleaning With Feed Container, Dosing Pumps In Circulation Line

    6. Cleaning 6.1.3 Displacement cleaning with feed container, dosing pumps in circulation line. Cold water water Heater Hot water Cold water valve valve Agitator Pump Level 2 Feed = Metering pump container Level 1 for alcaline detergent = Metering pump for acid detergent Drain valve Cleaning method for milk cooling tanks, where hot and cold water are dosed level-...

  • Page 20: Cleaning Programme Diagram

    6. Cleaning 6.2 Cleaning programme diagram Cleaning cycle Clean. stg 0 Cleaning stage 1 Cleaning stage 2 Cleaning stage 3 Cleaning stage 4 Rinse out Pre-rinse 1 Pre-rinse 2 Main rinse 1 Intermediate rinse 1 Level 2 Level 2 Level 2 Level 2 Level 1 Level 1...
  • Page 21 6. Cleaning Cleaning stage Cleaning stage 5 Cleaning stage 6 Cleaning stage 7 Cleaning stage 8 Clean. stg 9 Main rinse 2 Intermediate rinse 2 Disinfection After-rinse Rinse out Level 2 Level 2 Level 2 Level 2 Level 1 Level 1 Level 1 Level 1 Explanation of the setting of alkaline / acid cleaning:...

  • Page 22: Explanation And Programming Of The Cleaning Process

    6. Cleaning 6.3 Explanation and programming of the cleaning process Cleaning methods In section 6.1, 4 cleaning methods for different cooling tank configurations are described. In the following all 4 methods are described, whereby the specific differ- ences are marked in colour. Displacement cleaning Circulation cleaning Circulation cleaning...
  • Page 23 6. Cleaning 6.3 Explanation and programming of the cleaning process In case of green An additional time can be defined in parameter [n15], in which the drain valve 1 have to be opens (agitator and cleaning pump continue to run) parameterized on „0“...
  • Page 24 6. Cleaning 6.3 Explanation and programming of the cleaning process Cleaning agent dosing: (see also explanation two pages before) In case of green Depending on the setting of the parameter [r20], detergent is injected at the end have to be parameterized on „0“...
  • Page 25 6. Cleaning 6.3 Explanation and programming of the cleaning process Cleaning stage 5: MAIN WASH 2 Parameter [r45] = 0 ‘Cleaning stage 5’ disabled Parameter [r45] = 1 ‘Cleaning stage 5’ execute one time In case of cleaning method 'green' – it is set in programme step [n30] how often the feed container is filled with water up to level 2 and water is pumped backup to level 1.
  • Page 26 6. Cleaning 6.3 Explanation and programming of the cleaning process In case of green Agitator and pump start to run. have to be Another option is to select an 'additonal water intake time' using [n63]. parameterized on „0“ The water circulates for the pre-set time [n64]. An additional time can be defined in parameter [n65], in which the drain valve opens (agitator and cleaning pump continue to run) Agitator and pump switch off.
  • Page 27 6. Cleaning 6.3 Explanation and programming of the cleaning process Cleaning stage 8: AFTER RINSE Parameter [r48] = 0 ‘Cleaning stage 8’ disabled Parameter [r48] = 1..5 ‘Cleaning stage 8’ execute x-times In case of cleaning method 'green' – it is set in programme step [n 0] how often the feed container is filled with water up to level 2 and water is pumped back up to level 1.

  • Page 28: Service Functions For Testing The Cleaning Cycle

    6. Cleaning Service functions for testing the cleaning cycle Start cleaning with the desired cleaning stage (0 to 8) Set the desired cleaning stage (0 to 8) in parameter [r92]. Press CLEANING button : A cleaning cycle starts with the selected cleaning stage and then runs through to the end.
  • Page 29 Page 29...

  • Page 30: Tank Monitor And General Fault Handling

    7. Tank monitor and general fault handling 7.1 Description of tank monitor operation During the entire cooling and cleaning process, the built-in tank monitor keeps check on the correct operation of all processes , in order to guarantee the perfect state of the milk.
  • Page 31 7. Tank monitor and general fault handling Optical presentation of alarms No alarm Each alarm has its own display code Informative and critical alarms are also indicated by LED as follows: active informative alarm Informative alarm (Green permanently again after RESET) active critical alarm Critical alarm critical alarm after RESET...
  • Page 32 7. Tank monitor and general fault handling Tank monitor: Milk collection YES or NO Examples of use of tank monitor. CAUTION: Do not simply cancel a tank monitor alarm. It is essential to investigate and remedy the cause, in order to avoid a harmful effect on the milk.
  • Page 33 7. Tank monitor and general fault handling Critical + informative alarm - Milk must not be taken out. Green = flashing critical + informative alarm = flashing (press RESET button) after RESET Green = flashing critical + informative alarm = on (press RESET button) after second RESET Green = off...
  • Page 34 7. Tank monitor and general fault handling Critical alarm - Milk quality may be compromised Green = off critical alarm = flashing (press RESET button) after RESET Green = off critical alarm = on The driver goes to the Gala-Kool Pro and checks the tank monitor.

  • Page 35: Tank Monitor: Handling Multiple Faults

    7. Tank monitor and general fault handling 7.3 Tank monitor: Handling multiple faults For every alarm - whether informative (green) or critical (red) – an error code blinks in the display. If several faults occur simultaneously, the code for the most recently occurring fault blinks in the display.

  • Page 36: Listing Fault Codes And Their Description

    Minimum acting time = [H31] F15 Agitator fault in cooling mode (milk not stirred) Alarm functions only if optional “ Fabdec agitator monitor” is installed and parameters set [A71]. Alarm occurs after the cooling mode is started, if a backpressure by the milk has not been detected on the stirrer within the time [H40].

  • Page 37: Informative Tank Monitor Alarms (Green)

    7. Tank monitor and general fault handling Informative tank monitor alarms (green) F20 Cooling time exceeded for first milking Alarm is triggered if the temperature set in parameter [h20] is not reached within the time set in parameter [h21]. The time starts when cooling of the first milking starts. F22 Cooling mode switched off At the milking time [h41-h43] entered, the cooling was not switched on.

  • Page 38: System Alarms Cleaning

    7. Tank monitor and general fault handling 7.5.3 System alarms - clean When a washing cycle has been completed successfully, this is indicated by the green LED “OK”. A new mode can then be started. If a fault occurs during a washing cycle: the cycle is interrupted, the red LED “Fault”...
  • Page 39 7. Tank monitor and general fault handling F43 Manual interruption of cleaning - washing stops - outlet valve is opened for time [n100] (during the emptying phase the display alternates between F43 and AbL) - the red LED “FAULT” then flashes, with error code F43 Washing was stopped manually using the OFF button.

  • Page 40: System Alarms Cooling

    - Compressor overheated / faulty F54 Agitator monitoring Alarm is only possible, if the " Fabdec stirring unit monitoring" is installed and parameterized [A71] and activated in parameter [P24]! Alarm occurs if the stirring unit monitoring detects one of the following stirring unit errors: - no stirring unit activity, although stirrer was switched on.

  • Page 41: System Alarms External Sensors

    7. Tank monitor and general fault handling 7.5.5 System alarms - external sensors F60 Agitator monitoring fault - no communication with the agitator monitoring module, or - only for module 003: Phase error, or - only for module 003: phase twisted when connected See also section 9.22 F61 SMS module fault - no communication with GSM-SMS-Modul...

  • Page 42: Setting Of Parameters

    8. Setting of parameters 8.1 Change and save parameter values Gala-Kool Pro is configured in 10 different parameter levels. To change parameters in one of the lower levels, enter the corresponding 'level code' CODE Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters...
  • Page 43 8. Setting of parameters Display parameter value Use the arrow keys to select the desired parameter. Press the "SET" button: The parameter value is displayed Change parameter value Use the arrow keys to select the desired parameter. Hold down the "SET" button and use the arrow buttons to set the desired value.

  • Page 44: Level "General Cooling Parameters

    8. Setting of parameters 8.2 Level “General cooling parameters” (c parameters) Working level for normal daily operation c parameters General cooling parameters code: C212 Code: C212 Extended cooling parameters code: D345 General cleaning parameters code: B454 Switch to level Extended cleaning parameters code: C567 “General cooling parameters”...
  • Page 45 8. Setting of parameters Range Default Maximum continuous stirring period 0 .. 999 min. in mode ‚continuous stirring‘ Setting of maximum continuous stirring period. indefinite stirring (to end, the OFF button must be pressed 1..999: max. stirring period in minutes Sensor correction adjustment Range Default...

  • Page 46: Level "Extended Cooling Parameters

    8. Setting of parameters 8.3 Level “Extended cooling parameters” (P parameters) Working level for normal daily operation General cooling parameters code: C212 P parameters Extended cooling parameters code: D345 Code: D345 General cleaning parameters code: B454 Extended cleaning parameters code: C567 Switch to level Service parameter s code: EA03...
  • Page 47 8. Setting of parameters 8.3 Level “Extended cooling parameters” (P parameters) Drawing off milk through pneum. butterfly valve in cooling mode Range Default Milk removal options 0 .. 2 (hidden if A40 = 0 or 1 ) deactivated – not possible to open manually Button function Opens the butterfly valve directly, for as long as the button is held down.
  • Page 48 8. Setting of parameters 8.3 Level “Extended cooling parameters” (P parameters) Milk-volume-dependent cooling start delay Range Default (Cooling power reduction in case of robot operation) Compressor Cleaning* Cooling mode* * Settings in [P61] 6: START Cooling mode > [P55] minutes = alarm 7: START Cleaning mode For the parameterization Capacity of the milk pump in litres / minute...
  • Page 49 8. Setting of parameters 8.3 Level “Extended cooling parameters” (P parameters) Variations of the cooling start delay 0 .. See section .4 for the deactivated (without cooling start delay) setting of cooling start simple cooling start delay parameters Interval cooling boosts (power reduction by cycles) Interval cooling boosts after switch-on delay Start cooling according to number of boosts of milk pump Interval cooling boosts according to number of impulses milk pump...
  • Page 50 8. Setting of parameters 8.3 Level “Extended cooling parameters” (P parameters) Time delay 2nd cooling level 1..999 min From the end of cooling start delay Time delay 3rd cooling level 1..999 min From activation of 2nd cooling level Switch on delay 2...25 sec (compressor simultaneous start protection) Settings for target temperature switchover T1 / T2...

  • Page 51: Level "General Cleaning Parameters

    8. Setting of parameters 8.4 Level “General cleaning parameters” (n parameters) Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters code: D345 n parameters General cleaning parameters code: B454 Code: B454 Extended cleaning parameters code: C567 Service parameter s code: EA03 Switch to level...
  • Page 52 8. Setting of parameters Running times cleaning stage 4 (intermediate rinse) - hidden, if [r44] = 0 Water intake by feed container (displacement cleaning) 0 .. 6 Water intake by level 1 0 .. 1 Water intake by time 0 .. 999 sec. Additional water intake time + circulation 0 ..
  • Page 53 8. Setting of parameters Runtime abort for all cleaning stages n100 Drain time after cleaning has been aborted 0 .. 999 sec. Dosing time settings n101 Dosing time alkaline detergent 0 .. 999 sec. n102 Dosing time acid detergent 0 .. 999 sec. n103 Dosing time disinfection (hidden if r47 = 0) 0 ..

  • Page 54: Level "Extended Cleaning Parameters

    8. Setting of parameters 8.5 Level “Extended cleaning parameters” (r parameters) Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters code: D345 r parameters General cleaning parameters code: B454 Extended cleaning parameters code: C567 Code: C567 Service parameter s code: EA03 General tank monitor parameters...
  • Page 55 8. Setting of parameters Settings to start cleaning (see section .3.1) Cleaning enable via digital input (Default 0) 0: deactivated 1: activated Short wash configuration Range Default Activation of short program via button 1 .. 8 0: deactivated 1: 1x Pre-wash 1 (Rinse 1) 2: 1x Pre-wash 2 (Rinse 2) 3: 1x After-wash (Rinse 8) 4: 1x After-wash (Rinse 9)
  • Page 56 8. Setting of parameters 8.5 Level “Extended cleaning parameters” (r parameters) Number of passes of seperate cleaning stages Range Default Number of passes clean. stage 0: Rinse out 0 .. 5 Number of passes clean. stage 1: Pre-rinse 1 0 .. 5 Number of passes clean.
  • Page 57 8. Setting of parameters 8.5 Level “Extended cleaning parameters” (r parameters) Settings cleaning breaks Activation of break in cleaning programme (Default 0) Selection 1, 2, 3: If the digital input is to be used 0: deactivated to terminate the pause, the 1: activated, finish of break only with button or digital input function 15 must additionally 2: activated, finish of break after time [r72] or button or digital input...
  • Page 58 8. Setting of parameters Page 58...

  • Page 59: Level "Service Parameters

    8. Setting of parameters 8.6 Level “Service parameters” (E parameters) Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters code: D345 General cleaning parameters code: B454 E parameters Extended cleaning parameters code: C567 Service parameter s code: EA03 Code: EA03 General tank monitor parameters...

  • Page 60: Level "General Tank Monitor Parameters

    8. Setting of parameters 8.7 Level “General tank monitor parameters” (h parameters) Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters code: D345 General cleaning parameters code: B454 Extended cleaning parameters code: C567 h parameters Service parameter s code: EA03 General tank monitor parameters...
  • Page 61 8. Setting of parameters Setting milk times to monitor „cooling activated” Range Default This function triggers an alarm if cooling has not been activated at the entered milk times. This is to prevent to forget the activation of the cooling in case of the first milking after the cleaning.

  • Page 62: Level "Extended Tank Monitor Parameters

    8. Setting of parameters 8.8 Level “Extended tank monitor parameters” (H parameters) Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters code: D345 General cleaning parameters code: B454 Extended cleaning parameters code: C567 Service parameter s code: EA03 H parameters General tank monitor parameters...
  • Page 63 8. Setting of parameters Tank monitor activation H90 Activation delay (see section 9.19) 0 .. 300 min. 0 = deactivated Parameter level lock H98 Password protection 0 .. FFFF H99 Password protection 0 .. FFFF Information on password protection: The level "extended tank monitor parameters" can additionally be protected with another password.

  • Page 64: Level „Alarm -> Event Assignment

    8. Setting of parameters Level “Alarm - Event assignment” (F parameters) Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters code: D345 General cleaning parameters code: B454 Extended cleaning parameters code: C567 Service parameter s code: EA03 General tank monitor parameters code: 4711...
  • Page 65 8. Setting of parameters Setting Default Fault configuration..high milk temperature (level 1) 12 .. 13 Critical ... high milk temperature (level 2) 12 .. 13 tank monitor alarm ... high milk temperature (level 3) 12 .. 13 (always red LED) ...

  • Page 66: Level "Configuration

    8. Setting of parameters 8.10 Level “Configuration” (A parameters) Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters code: D345 General cleaning parameters code: B454 Extended cleaning parameters code: C567 Service parameter s code: EA03 General tank monitor parameters code: 4711 Extended tank monitor parameters...
  • Page 67 8. Setting of parameters 9 10 13 14 16 17 18 19 20 21 Assignment of output functions to relays K1 to K13 deactivated 13: cleaning active alarm tank monitor * 14: alarm in general * The relay functions for robot stop 15: drain valve 2 assignment 1 and 14...
  • Page 68 8. Setting of parameters 8.10 Level “Configuration” (A parameters) Assignment of output functions to digital inputs 1 to 8 0: deactivated 1: safety switch (manual butterfly valve) 2: remote start cooling 3: dry protection heating 4: thermal protection pump 5: water pressure switch 6: thermal protection compressor 7: cleaning release robot 8: milk pump impulse 1...
  • Page 69 8. Setting of parameters 8.10 Level “Configuration” (A parameters) Output signal configuration robot Default A40 Robot operation / control pneum. butterfly valve 0: without robot and without pneumatic butterfly valve 1: only with robot 2: only butterfly valve control (pneumatic) 3: robots and pneum.
  • Page 70 8. Setting of parameters 8.10 Level “Configuration” (A parameters) Configuration external modules Range Default A71 Configuration stirring unit monitoring 0 .. look also section 9.22 0: deactivated 5: Clear bands (after deletin of the band , the number of agitators must be readjusted) Agitator monitoring module ESVAW-002-A with two agitator switch-on-relays that are integrated in the module 6: one agitator...
  • Page 71 8. Setting of parameters 8.10 Level “Configuration” (A parameters) Automatic change of daylight saving time Range Default A78 Automatic change of daylight saving time 0 .. 3 0: deactivated 1: Western European time zone (change at 1:00) 2: Central European time zone (change at 2:00) 3: Eastern European time zone (change at 3:00) Test parameter for the agitator rating Range...
  • Page 72 8. Setting of parameters 8.11 Level “I / O test parameters” (o. parameters) Working level for normal daily operation General cooling parameters code: C212 Extended cooling parameters code: D345 General cleaning parameters code: B454 Extended cleaning parameters code: C567 Service parameter s code: EA03 General tank monitor parameters code: 4711...
  • Page 73 8. Setting of parameters Test digital inputs All inputs [o.21 to o.28] can be selected via the arrow keys and tested as follows: Select the desired parameters with the arrow keys. Press the SET key briefly: '0' or '1' appears in the display (depending on the current switching state of the respective component).

  • Page 74: Other Information

    9. Other Information 9.1 Butterfly valve (manual or pneumatic) manual In the case of a manual butterfly valve, the position of the lever (open / closed) can be monitored via an optional safety switch. See also section . 9 2 pneumatic In the case of a pneumatic butterfly valve, this must be set in parameter [A40].

  • Page 75: Safety Switch For Manual Butterfly Valve

    9. Other Information Safety switch for manual butterfly valve The safety switch monitors the correct position of the lever on the tank outlet. The function of the safety switch is configured in parameter [r10]. Parameter [r10] is not available if a pneumatic butterfly valve is configured in [A40] Fault indication The “butterfly valve”...

  • Page 76: Robot Control

    9. Other Information Robot control Gala-Kool Pro offers two possibilities of controlling a connected robot: - via the button “Robot Stop” - via the signal “ Clean ing active” For both functions, the appropriate parameter settings must be done beforehand. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Signal “Robot-Stop”...

  • Page 77: Cleaning Release By Robot

    9. Other Information 9.3.1 Cleaning release by robot r27 Cleaning release via digital input deactivated activated Explanation Setting the parameter [r27] to 'active' is only useful for robot operation. If the cleaning button is pressed after the tank has been emptied by the truck driver, it may be that the robot is not ready for the cleaning process, depending on the configu- ration of the connected robot.

  • Page 78: Different Variants For Cooling Start Delay

    9. Other Information 9.4 Different variants for cooling start delay The control can be programmed to delay the start of the compressor after the cool- Cooling start delay s i ing mode has been triggered, to prevent a slight freezing of milk in the tank. This set usin parameters delay takes place only in case of first milking after the cleaning.
  • Page 79 9. Other Information Information on cooling start versions 6 and 7 Compressor Cleaning* Cooling mode* * Settings in [P61] 6: START Cooling mode > [P55] minutes = alarm 7: START Cleaning mode Both settings "6" and "7" are used for volume-dependent switching on of the compres- sor in order to prevent the milk from freezing during robot operation when the cooling mode starts.

  • Page 80: Compressor Switch-On Delay / Pre-Agitating

    9. Other Information 9.5 Compressor switch-on delay / pre-agitating (Only useful when using a robot) If the milk cooling tank is filled by a robot, filling from below takes place via the tank outlet. For some tank types, the temperature sensor is positioned very close to the tank outlet.

  • Page 81: Function Second Temperature Sensor

    9. Other Information 9.8 Function second temperature sensor The second temperature sensor (F 2) may have two different tasks or functions. To act as a monitoring sensor (redundancy) for the first sensor. An adjustable difference between the two measured values gives rise to an alarm. To regulate the heating temperature / holding temperature during washing.

  • Page 82: Heating Control

    9. Other Information 9.11 Heating control Clean. stage 0 Cleaning stage 1 Cleaning stage 2 Cleaning stage 3 Cleaning stage 4 Rinse out Pre-rinse 1 Pre-rinse 2 Main rinse 1 Intermediate rinse 1 Heater Gala-Kool Pro distinguishes between two heating phases: - Heating-up phase - programme step "H“...

  • Page 83: Air In The Cleaning Pump -> Automatic Venting

    9. Other Information 9.13 Air in the cleaning pump -> automatic venting If there is air in the washing line when the washing pump starts, it is impossible for the pump to circulate the washing water. The remedy: short switch-on and switch-off impulses when the pump starts can remove air bubbles.

  • Page 84: Level Control Setting

    9. Other Information 9.14 Level control setting The level control is pre-set in the factory to “average” water quality. Depending on the hardness of the local water supply, sensitivity can be adjusted as follows: Setting under the I / O test parameters:: In the level “I/O test parameters”...

  • Page 85: Detergent Injection Position

    9. Other Information Detergent injection position Parameter [r20] is used to determine whether the detergent is added in programme stage D1 or D2 or in the feed container Note: When filling the pre-hopper [r20 =0] the detergent is added when water is taken for the second time.

  • Page 86: Setting Of A Break In The Cleaning Programme

    9. Other Information 9.17 Setting of a break in the cleaning programme During the automatic cleaning programme it is possible to add a break after a cleaning cycle. °C Example: Setting a break after the pre-cleaning until sufficient quantities of warm water from the heat recovery for the main cleaning cycle is available.

  • Page 87: Activation Delay Tank Monitor

    9. Other Information 9.19 Activation delay tank monitor [H90] The activation delay of the tank monitor is required to test the operation modes during the commissioning without activating false alarms. Activation Delay is activated by the start of the Gala-Kool Pro and suppresses all errors from F1 to F38 for a pre-set time (with the exception of F30).

  • Page 88: 20 . Procedure Following Power Failure

    If in cooling mode a power outage lasts longer than the time set in [H20], fault code (F6) flashes, followed by an alarm “DO NOT LOAD”. Installation: Only the suitable original Fabdec -power pack may be connected. Connect the power pack to terminals 40 41...

  • Page 89: 22 . Agitator Monitoring Module (Optional)

    9. Other Information .22 Agitator monitoring module (optionally) For different applications different agitator monitoring modules are available: ESVAW-002-A agitator monitoring module ESVAW-002-A is used to monitor max. 2 agitator motors in milk cooling tanks. The agitator motors can be switched on or off directly via the module via the integrated relays.

  • Page 90: General Measures When Using Electronic Control Systems

    9. Other Information General measures when using electronic control systems So that even complicated regulatory tasks can be presented to the user in a manner which is clear and simple and ensures high measurement accuracy, today's electronic control systems make increasing use of microprocessors. However, the benefits of these systems are countered by the disadvantage that increased measurement accu- racy is accompanied by sensitivity to interference.
  • Page 91 9. Other Information General measures when using electronic control systems If specific interference sources cannot be avoided they should at least be kept at a distance from the regulator system. Capacitive and inductive couplings can cause crosstalk between high-voltage lines and parallel low-voltage and sensor lines. This distorts measured values and signals and can disrupt the entire regulatory process.
  • Page 92 9. Other Information General measures when using electronic control systems Semiconductor switches such as thyristors or triacs also produce interference voltages. They occur as a result of non-linear characteristics and finite ignition voltages. These components must be protected against excessive voltages, for which mainly varistors, RC combinations or choke coils are used.
