- Page 1 OPERATING INSTRUCTIONS TX-43D302B COLOUR TELEVISION WITH REMOTE CONTROL...
-
Page 2: Table Of Contents
Contents Safety Information ..........2 Markings on the Product.........2 Maintenance ............4 Display panel, Cabinet, Pedestal......4 Mains plug ..............4 Assembling / Removing the pedestal .....4 When using the wall-hanging bracket.....5 Environmental Information........5 Features ..............5 Accessories Included..........6 Standby Notifications ..........6 TV Control Switch & Operation.......6 Inserting the Batteries into the Remote ....6 Connect Power ............6 Antenna Connection ..........6... -
Page 3: Safety Information
• Do not place any heat sources such as electric Safety Information heaters, radiators, etc. near the TV set. • Do not place the TV on the floor and inclined CAUTION surfaces. RISK OF ELECTRIC SHOCK • To avoid danger of suffocation, keep plastic bags DO NOT OPEN out of the reach of the babies, children and domestic animals. - Page 4 WARNING WALL MOUNTING WARNINGS Do not ingest the battery, Chemical Burn Hazard This product or the accessories supplied with the • Read the instructions before mounting your TV product may contain a coin/button cell battery. If on the wall. the coin/button cell battery is swallowed, it can •...
-
Page 5: Maintenance
Maintenance Assembling / Removing the pedestal First, remove the mains plug from the mains Preparations socket. Take out the pedestal(s) and the TV from the packing Display panel, Cabinet, Pedestal case and put the TV onto a work table with the screen panel down on the clean and soft cloth (blanket, etc.) Regular care: •... -
Page 6: When Using The Wall-Hanging Bracket
When using the wall-hanging bracket Environmental Information Please contact your local Panasonic dealer to This television is designed to be environment friendly. purchase the recommended wall-hanging bracket. To reduce energy consumption, you can follow these steps: Holes for wall-hanging bracket installation;... -
Page 7: Accessories Included
• PC input appear on the screen. Scroll through the available sources by pushing the button up or down. • Game Mode (Optional) To turn the TV off: Press the middle of the button • Ethernet (LAN) for interactive services available on down and hold it down for a few seconds, the TV will digital channels turn into standby mode. -
Page 8: Notification
HDMI Licensing LLC in the Declaration of Conformity (DoC) United States and other countries. “Hereby, Panasonic Corporation declares that this TV is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” If you want to get a copy of the original DoC of this Manufactured under license from Dolby Laboratories. -
Page 9: Specification
Notice for DVB / Data broadcasting Specification • This TV is designed to meet the standards (as of PAL BG/DK/II’ August, 2013) of DVB-T / T2 (MPEG2 and MPEG4- TV Broadcasting SECAM BG/DK AVC(H.264)) digital terrestrial services and DVB-C (MPEG2 and MPEG4-AVC(H.264)) digital cable VHF (BAND I/III) - UHF Receiving Channels services. -
Page 10: Remote Control
Remote Control 1. Standby: Switches On / Off the TV 2. Text: Displays teletext (where available), press again to superimpose the teletext over a normal broadcast picture (mix) 3. Menu: Displays TV menu 4. Media player: Opens the media player screen 5. -
Page 11: Connections
Connections Connector Type Cables Device NOTE: When connecting a device via the YPbPr or Side Scart AV input, you must use the Connection connection cables to enable (back) connection. For Side AV input you should use the supplied cable. See the illustrations on the left side. -
Page 12: Switching On/Off
channels of it will be listed on the top of the Channel Switching On/Off List. When finished, press OK to continue. To Switch the TV On You can activate Store Mode option at this point. Connect the power cord to a power source such as a This option will configure your TV’s settings for store wall socket (220-240V AC, 50 Hz). -
Page 13: Media Player Menu
Media Player Menu CEC and CEC RC Passthrough You can play photo, music and movie files stored This function allows to control the CEC-enabled on a USB disk by connecting it to your TV. Connect devices, that are connected through HDMI ports by a USB disk to one of the USB inputs located on the using the remote control of the TV. -
Page 14: Tv Menu Contents
TV Menu Contents Picture Menu Contents You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Cinema, Game(optional), Sports, Dynamic and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen. - Page 15 Sound Menu Contents Volume Adjusts the volume level. Equalizer Selects the equalizer mode. Custom settings can be made only when in User mode. Balance Adjusts whether the sound comes from the left or right speaker. Sets headphone volume. Headphone Please ensure before using headphones that the headphone volume is set to a low level, to prevent damage to your hearing.
- Page 16 Setup Menu Contents Conditional Access Controls conditional access modules when available. Language You may set a different language depending on the broadcaster and the country. Enter correct password to change parental settings. You can easily adjust Menu Lock, Maturity Lock, Child Lock or Guidance in this menu. You can also set a new PIN or change the Default CICAM PIN using the related options.
- Page 17 Installation Menu Contents Automatic Displays automatic tuning options. Digital Aerial: Searches and stores aerial DVB stations. channel scan Digital Cable: Searches and stores cable DVB stations. Analogue: Searches and stores analogue stations. (Retune) Manual This feature can be used for direct broadcast entry. channel scan Network Searches for the linked channels in the broadcast system.
-
Page 18: General Tv Operation
selection) during the First Time Installation use the PIN that General TV Operation you have defined. Using the Channel List Some options may not be available depending on the country The TV sorts all stored stations in the Channel List. selection in the First Time Installation. -
Page 19: Teletext Services
Select Channel: Using this option, you can switch to Troubleshooting & Tips the selected channel. Tv will not turn on Set Timer on Event / Delete Timer on Event: After you have selected an event in the EPG menu, press the Make sure the power cord is plugged in securely to OK button. -
Page 20: Pc Input Typical Display Modes
PC Input Typical Display Modes AV and HDMI Signal Compatibility The following table is an illustration of some of the Source Supported Signals Available typical video display modes. Your TV may not support all resolutions. SECAM Index Resolution Frequency NTSC4.43 640x350 85Hz (SCART) -
Page 21: Supported Video File Formats For Usb Mode
Supported Video File Formats for USB Mode Extension Video Codec SPEC (Resolution) & Bit Rate .dat, vob MPEG1/2 1080P@30fps - 40 Mbps MPEG1/2, .mpg, .mpeg MPEG4 MPEG1/2, H.264, H.264: 1080Px2@30fps - 62.5 Mbps, 1080P@60fps - 62.5 Mbps MVC: .ts, .trp, .tp AVS, MVC 1080P@30fps - 62.5 Mbps Other: 1080P@30fps - 40Mbps .mp4, .mov,... -
Page 22: Supported Audio File Formats For Usb Mode
Supported Audio File Formats for USB Mode Extension Audio Codec Bit Rate Sample rate MPEG1/2 Layer1 32Kbps ~ 448Kbps .mp3, MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3 8Kbps ~ 320Kbps MPEG1/2 Layer1 32Kbps ~ 448Kbps MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3... -
Page 23: Supported Subtitle File Formats For Usb Mode
Extension Audio Codec Bit Rate Sample rate MPEG1/2 Layer1 32Kbps ~ 448Kbps MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3 8Kbps ~ 320Kbps .wav LPCM 64Kbps ~ 1.5Mbps 8KHz ~ 48KHz IMA-ADPCM, 384Kbps 8KHz ~ 48KHz MS-ADPCM G711 A/mu-law 64Kbps ~ 128Kbps 8KHz MPEG1/2 Layer3... -
Page 24: Supported Dvi Resolutions
Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information. 72Hz 75Hz 56Hz 60Hz 66Hz 70Hz 640x400 þ 640x480 þ þ þ... -
Page 25: Important Instruction
Important Instruction For your own safety read following instruction carefully before attempting to connect this unit to the mains supply. MAINS (AC) OPERATION The wires in the mains lead are coloured in accordance with the following code : GREEN & FUSE YELLOW (Earth) - Page 26 Product fiche Supplier Panasonic Corporation TX-43D302B Model ID Energy efficiency class 108 cm / 43 inches Visible screen size (diagonal) 37 W On mode average power consumption 54 kWh Annual energy consumption *1 0,5 W Standby power consumption *2 Off mode power consumption...
