FANOX EMM-5 Instruction Manual

Electrical multifunction meter

Advertisement

Quick Links

INSTRUCTION MANUAL
IM441-EU-F v0.4
EMM-5
GENERALITY
These digital multimeters series allow to monitor all the electrical parameters
present on a distribution line. The local display of 30 electrical parameters is
carried out by 4 display with red LED guaranteeing a good and contemporary
reading of more measures. A simple front panel completes the intuitive selection
of several electrical parameters, with a great quantity of information.
These instruments, over of the instantaneous measures, display the maximum
peak of the main parameters (maximum peak and maximum demand).
The presence of the serial port communication EIA485 (option) allows the
connection in network of more instruments to realize centralized measure
networks.
These multimeters replace in a unique device, all the functions of voltmeters,
ammeters, energy meters, cosphimeters, wattmeters, varmeters, frequency
meters permitting a great economic saving, a reduction of dimension and the
wiring energy and a simplification in the purchase and management of the
instruments because this is a model usable at all of need of local measure in the
electrical panel, machine, etc.
OPTIONS
- internal CT
- digital output (in alternative to the serial port)
- serial port (in alternative to the digital output)
- power supply different from standard version
- current input 1A
MEASURED PARAMETERS
phase and three phase voltages
phase to phase and three phase system voltages
phase and three phase currents
phase and three phase power factors
phase and three phase active powers
phase and three phase system reactive powers
phase and three-phase system apparent powers
frequency
temperature
three phase system active energy
three phase system reactive energy
three phase system apparent energy
hours counter
peak value (maximums):
maximum phase voltages
maximum phase currents
maximum three-phase powers
maximum average phase currents (maximum demand)
maximum average three-phase powers (maximum demand)
average phase currents
average three-phase powers
EMM-5
www.fanox.com
fanox@fanox.com
ELECTRICAL MULTIFUNCTION METER
parameters
instruction manual
unit of measurement
[V-kV]
[V-kV]
[A-kA]
[W-kW-MW]
[VAr-kVAr-MVAr]
[VA-kVA-MVA]
[Hz]
[°C]
[kWh]
[kVArh]
[kVAh]
[hr]
[V-kV]
[A-kA]
[W-VAr-VA (k-M)]
[A-kA]
[W-VAr-VA (k-M)]
[A-kA]
[W-VAr-VA (k-M)]
IM441-EU-F v0.4
Tel: 0034 94 471 14 09
initial identification
V
V
V
L1-N
L2-N
L3-N
V
V
V
L1-L2
L2-L3
L3-L1
A
A
A
L1
L2
L3
PF
PF
PF
L1
L2
W
W
W
L1
L2
VAr
VAr
VAr
L1
L2
VA
VA
VA
L1
L2
Hz
L3
T
kWh
kVArh
kVAh
h
V
V
L1-N max
L2-N max
A
A
L1 max
L2 max
W
VAr
max
max
I
I
L1 max (avg)
L2 max (avg)
W
VAr
max (avg)
max (avg)
A
A
L1 avg
L2 avg
W
VAr
avg
avg
Fax: 0034 94 471 05 92
V
L-N
V
L-L
A
PF
L3
W
L3
VAr
L3
VA
L3
V
L3-N max
A
L3 max
VA
max
I
L3 max (avg)
VA
max (avg)
A
L3 avg
VA
avg
pag. 1
Pag 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the EMM-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for FANOX EMM-5

  • Page 1 INSTRUCTION MANUAL IM441-EU-F v0.4 EMM-5 ELECTRICAL MULTIFUNCTION METER GENERALITY These digital multimeters series allow to monitor all the electrical parameters present on a distribution line. The local display of 30 electrical parameters is carried out by 4 display with red LED guaranteeing a good and contemporary reading of more measures.
  • Page 2: Installation

    For safety reasons, place an external fuse protection at the input voltages, and use adequate cables for the working voltages and currents, with a cross sections from 0,5 to 2,5 mm EMM-5 instruction manual IM441-EU-F v0.4 pag.
  • Page 3: Wiring Diagrams

    Max 150mA Max 230Vac/dc NOTE: in the instrument version with digital outputs programmed like “pulse” output DO1 for ACTIVE ENERGY pulses output DO2 for REACTIVE ENERGY pulses EMM-5 instruction manual IM441-EU-F v0.4 pag. 3 www.fanox.com fanox@fanox.com Tel: 0034 94 471 14 09...
  • Page 4 SETUP. Pressing the A key on the G display will appear the message SET that will remain always displayed during the set of each parameter to highlight the SeTUp phase in running. The set values will be keep also in absence of auxiliary power supply. EMM-5 instruction manual IM441-EU-F v0.4 pag.
  • Page 5 8data 1stop-odd parity SET PAS Increase Set Password OFF - 0002 ÷ 9999 Decrease Confirm and end of general settings EMM-5 instruction manual IM441-EU-F v0.4 pag. 5 www.fanox.com fanox@fanox.com Tel: 0034 94 471 14 09 Fax: 0034 94 471 05 92...
  • Page 6 EIA485 communication network, proceed with the modality, already described. The settable values are from 1 to 247. To confirm, press the A key. EMM-5 instruction manual IM441-EU-F v0.4 pag.
  • Page 7 To enable the chosen type, press the B key to change the indication on display G from NO to yes. Confirm enabling cancellation, by pressing the A key. The indication on display G change from yes to --- . EMM-5 instruction manual IM441-EU-F v0.4...
  • Page 8 ALR LO Decrease (after 0 there is OFF) Set delay Increase ALR Dl Decrease Confirm and end of digital output settings. EMM-5 instruction manual IM441-EU-F v0.4 pag. 8 www.fanox.com fanox@fanox.com Tel: 0034 94 471 14 09 Fax: 0034 94 471 05 92...
  • Page 9 ALR DLY and the value expressed in seconds (range 1÷900). The modification of the value is done in the same way of the threshold set. With the confirmation (A key) the set is complete. The programming will be referred to the digital output indicated on G display (DO1 o DO2). EMM-5 instruction manual IM441-EU-F v0.4 pag.
  • Page 10 T°C temperature EMM-5 instruction manual IM441-EU-F v0.4 pag. 10 www.fanox.com fanox@fanox.com Tel: 0034 94 471 14 09 Fax: 0034 94 471 05 92 Pag 10...
  • Page 11 L1 display will indicate the first 3 digits, the display L2 the seconds 3 digits and the L3 display the last 3. For example if: L1=000, L2=028, L3=53.2 the reading is 2853.2 kWh. EMM-5 instruction manual IM441-EU-F v0.4...
  • Page 12 In some application where the secondary is connected to other instruments apart from the EMM multimeter, some problems could happen concerning the typology of the amperometric inputs. If there are some problem call the assistance service. EMM-5 instruction manual IM441-EU-F v0.4 pag.
  • Page 13 Max 32 EMM; max 1200 meters R=120 CONNECTION WITH SHIELDED CABLE RS485 RS232 For other information on the serial line it’s better to see the manual of EMI1 serial converter. EMM-5 instruction manual IM441-EU-F v0.4 pag. 13 www.fanox.com fanox@fanox.com Tel: 0034 94 471 14 09...
  • Page 14 DIMENSIONS cut panel EMM-5 instruction manual IM441-EU-F v0.4 pag. 14 www.fanox.com fanox@fanox.com Tel: 0034 94 471 14 09 Fax: 0034 94 471 05 92 Pag 14...
  • Page 15: Technical Features

    The liability of the producer for damage caused by defect of the product ”can be reduced or deleted (…) when the damage is caused joint by a defect of product or for blame of the damaged or a person of which the damaged is responsible” (Article 8, 85/374/CEE). EMM-5 instruction manual IM441-EU-F v0.4...
  • Page 16 Parque Tecnológico de Bizkaia, Edif. 604 48160 DERIO - BIZKAIA ESPAÑA Tel. 0034 94 471 14 09 Fax 0034 94 471 05 92 E-mail: fanox@fanox.com Web: www.fanox.com EMM-3 instruction manual / manual de in strucciones IM425-UE-F v2.2 pag. 16 www.fanox.com fanox@fanox.com...
