Arzel RegiDamper Installation Instructions

Arzel

RegiDamper™ Installation Instructions

The Arzel

RegiDamper™ is used where the branch ducts are inaccessible in finished ceilings or

in slabs, which prevent the use of the original Arzel

installed in the register boot just behind the register and is operated by a low pressure air and

vacuum pump (contained in the Arzel

Rated) tubing.

•

Remove all registers and fit damper assemblies into boots with tubing connection facing

into the duct opening (see fig. 1-a).

•

Once damper fit is verified, remove dampers from boot.

•

Cut an opening in the main trunk large enough to view the take-offs of the runs you are zoning

with RegiDampers. Locate the opening as close to the take-offs as possible. Tape the cut

edges of the opening with duct tape to prevent cutting yourself.

Zoning Technology, Inc.

Application

panel) by way of a 1/4 inch plenum rated Dekoron (UL

Fig 1-a: Inserting RegiDamper™

fig. 1-a - Fitting damper into boot

EzySlide™ dampers. The RegiDamper™ is

U.S. and Foreign Patents and Patents Pending

Table of Contents

Do you have a question about the RegiDamper and is the answer not in the manual?

Page 1 Zoning Technology, Inc. ® RegiDamper™ Installation Instructions Application The Arzel RegiDamper™ is used where the branch ducts are inaccessible in finished ceilings or ® in slabs, which prevent the use of the original Arzel EzySlide™ dampers. The RegiDamper™ is ®...
Page 2 (Leave the red orifice in place to provide flow and quiet operation.) • Insert the RegiDamper™ into the boot and hold damper in place with one screw on each end (holes provided.) Do not tighten screw against end plate. This will pull damper frame out of square and cause it to bind.
