- Page 1 Drawing : - TPC445 Issue : - 1 Date : - 02/12/15 CS90H INDUSTRIAL DEHUMIDIFIER OWNER’S MANUAL Page 1 of 12 E B A C C S - 9 0 - H D E H U M I D I F I E R...
-
Page 2: Package Contents
Drawing : - TPC445 Issue : - 1 Date : - 02/12/15 CS90H PACKAGE CONTENTS Item Description Quantity 10590GH-US Dehumidifier 3944110 PVC tube – 3/8” I/D 7.8 M 3086144 Quick release hose coupling TPC445 Manual Page 2 of 12 E B A C C S - 9 0 - H... - Page 3 Date : - 02/12/15 INTRODUCTION Designed for a wide range of applications, the CS90H dehumidifier is a rugged, industrial unit which utilizes an energy-efficient compressor and a compact portable design to provide easy efficient drying. The CS90H has a number of special features: •...
-
Page 4: Specifications
Drawing : - TPC445 Issue : - 1 Date : - 02/12/15 SPECIFICATIONS : CS60H ODEL : 15.2” (386mm) EIGHT : 14” (353mm) IDTH : 22” (564mm) EPTH : 84lbs (38 kg) EIGHT : 230 CFM (390M3/hr) IRFLOW : 110V/ 60Hz/ 1 ph OWER UPPLY : Powder-coated Epoxy... -
Page 5: Operation
: - 1 Date : - 02/12/15 OPERATION The following procedures should be followed to test the CS90H for correct operation: After unpacking, examine all external features to confirm damage- free shipment. Report all defects and damage at once. Connect the power cable to a grounded 15 Amp electrical outlet. - Page 6 Drawing : - TPC445 Issue : - 1 Date : - 02/12/15 i. If the air temperature is below 80° F, an even coating of frost should cover the entire evaporator coil ii. If the air temperature is above 80° F, frost and/or droplets condensed water should...
-
Page 7: Routine Maintenance
Drawing : - TPC445 Issue : - 1 Date : - 02/12/15 ROUTINE MAINTENANCE WARNING: ENSURE THAT THE POWER CORD TO THE MACHINE HAS BEEN DISCONNECTED BEFORE CARRYING OUT ROUTINE MAINTNENANCE To ensure continued full efficiency of the dehumidifier, maintenance procedures should be performed as follows: Clean the surface of the evaporator and condenser coils by blowing the dirt out from behind the fins with compressed air. - Page 8 Drawing : - TPC445 Issue : - 1 Date : - 02/12/15 REPAIRS Should an electrical component fail, consult the Factory Service Center to obtain the proper replacement part. If refrigerant gas is lost from the machine, it will be necessary to use a refrigeration technician to correct the fault.
-
Page 9: Troubleshooting
Drawing : - TPC445 Issue : - 1 Date : - 02/12/15 TROUBLESHOOTING YMPTOM AUSE EMEDY 1. Check the power from Unit inoperative 1. No power to unit power supply panel 1. Replace the fan motor 1. Fan motor burnt out 2. - Page 10 Drawing : - TPC445 Issue : - 1 Date : - 02/12/15 CS90H SPARE PARTS LIST ESCRIPTION UMBER UANTITY UMBER Defrost Timer 1619508 Filter 2013831 Condenser Coil 2059000 Evaporator Coil 2059001 Capillary Tube 3014249 2 x 30” Drain Tubing 3014338...
-
