- Page 1 Dishwasher User’s Manual DFN15X10B DFN15X10X Document Number : 15 0763 0100_AA_BEKO_B6_EN/ 26-07-16.(13:17)
- Page 2 Dishwasher User’s Manual DFN15X10B DFN15X10X Document Number : 15 0763 0100_AA_BEKO_B6_EN/ 26-07-16.(13:17)
- Page 3 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
- Page 4 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 5: Table Of Contents
CONTENTS 1 INSTRUCTIONS FOR SAFETY 5 OPERATING THE PRODUCT 22 Keys ............23 AND ENVIRONMENT Preparing the machine...... 23 General safety ........4 Programme selection ......23 Intended use ..........4 Auxiliary functions ......25 Children’s safety ........5 Scheduling the washing time ..26 Disposing of packaging material ..5 Starting the programme ....27 Transportation of the product ....5... -
Page 6: Instructions For Safety And Environment
Instructions for safety and envIronment This section contains safety electric shock! instructions that will help to Never touch the plug with • give protection from risk of wet hands! Never unplug by personal injury or property pulling on the cable, always damage. -
Page 7: Children's Safety
Instructions for safety and envIronment It must be used to do the Store all detergents and • • domestic type dishes only. additives in a safe place This appliance is intended away from the reach of the • to be used in household and children. -
Page 8: Compliance With Weee Directive And Disposing Of The Waste Product
Instructions for safety and envIronment Compliance with WEEE collection points designated by the local authorities. Directive and Disposing of the Waste Product This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). -
Page 9: Dishwasher Overview
Dishwasher Overview 1. Top Cover (depends on model) 2. Upper impeller 3. Lower basket 4. Lower impeller 5. Filters 6. Rating Label 7. Control panel 8. Door 9. Detergent dispenser 10. Lower impeller slot 11. Cutlery basket 12. Salt reservoir lid 13. -
Page 10: Technical Specifications
Dishwasher Technical specifications Compliance to standards and test data / EC declaration of conformity This product complies with the following EU directives; Development, production and sales stages of this product comply with the safety rules included in all pertaining European Community regulations. 2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power input 220-240 V, 50 Hz (see rating label) -
Page 11: Installation
Installation To make the product ready for use, Do not install the product at places • make sure that the electricity, tap water where temperature may fall below supply and water drainage systems are 0ºC. appropriate before calling the Authorised Place the product on a rigid floor. -
Page 12: Adjusting The Feet
Installation connected to the drain hole or sink’s the frequency shown in the rating label drainage. The length of this connection corresponds to your electricity supply. must be min. 50 cm and max. 100 cm from the floor. A discharge hose longer than 4 We recommend that this appliance be meters will cause washing performance connected to the mains supply via a... -
Page 13: Fitting A Different Plug
Installation Fitting a different plug Initial use As the colours of the wires in the mains Before starting to use the product, make lead of this appliance may not correspond sure that all preparations are made in with the coloured markings identifying the accordance with the instructions in terminals on your plug, proceed as follows: sections “Important safety instructions”... -
Page 14: Preparation Tips For Energy Saving
Preparation Tips for energy saving operates with the same performance continuously. Dishwasher salt is used for Following information will help you use the this purpose. product in an ecological and energy-efficient Use only special softening salts manner. produced particularly for the Wipe away any coarse food remnants on dishwashers in your machine. -
Page 15: Water Hardness & Regeneration Settings
Preparation 2. Turn the salt reservoir lid counter 4. Replace the lid and tighten it securely clockwise to open it (A, B). when the reservoir is full. 5. If you will not start a washing Salt reservoir will fill with water programme immediately after adding when you start the product. - Page 16 Preparation Test Strip 1 second Level 1 No Lime Level 2 Very low lime content Level 3 Low lime content Level 4 Medium lime content 1 minute Level 5 High lime content Very High lime content Level 6 Remove the Let the water Take the test strip Hold for...
-
Page 17: Detergent
Preparation If you move your house, it Contact the detergent producer is very important to make if the dishes are wet and/or the water hardness level if you notice limescale spots adjustment of your machine particularly on glasses after the according to the new location washing programme is over. -
Page 18: Tablet Detergents
Preparation Inside the detergent dispenser, Excessive usage of powder there are level markings that detergents will cause the help you use appropriate detergent not dissolve amount of detergent. When completely and will also cause brimful, detergent dispenser scratches on the glassware. will contain 40 cm³... -
Page 19: Rinse Aid
Preparation Open the lid of the rinse aid reservoir 2in1: Contains detergent, rinse aid or water by pressing its latch (B). softening salt 3in1: Contains detergent, rinse aid and water softening salt 4in1: Contains glass protectors in addition to detergent, rinse aid and water softening salt 5in1: Contains glass and stainless steel protectors in addition to detergent, rinse aid and water softening salt... - Page 20 Preparation decreased. This is set to position 4 as which you can place your dishes in the factory default. dishwasher. Place the heavily soiled and bigger items in the lower basket Items not suitable for washing in the and smaller, delicate and light items in dishwasher the upper basket.
- Page 21 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware 19 / 39 EN Dishwasher / User’s Manual...
-
Page 22: Cutlery Basket
Preparation Cutlery basket Grab one of the upper basket wires (right or left) and lift it up (A). Cutlery basket is designed to wash your Repeat the same process to raise the other dishes such as knife, fork, spoon, etc. in an side of the basket. -
Page 23: Collapsible Lower Basket Tines
Preparation Collapsible lower basket tines Upper basket height adjustable rack There are foldable tines (A) located at the lower basket of the machine are designed for Use the lower and upper parts of the height an easier placement of large pieces such as adjustable racks in the upper basket of pans, bowls, etc. -
Page 24: Operating The Product
Operating the product On/Off key 5. Function keys 2. Display Half Load Function 3. Start/Pause/Cancel key Super Rinse Function 4. Time Delay key 6. Program Selection key 7. Programme indicator 11. Rinse aid ( ) indicator 8. Program Follow-up indicator 12. -
Page 25: Keys
Operating the product Keys On/Off key It is used to turn on or off the machine. Machine will turn on with economy programme in On mode and the number of the economy programme will appear on the programme indicator. In Of mode, indicators on the display will turn off. - Page 26 Operating the product /39 EN Dishwasher / User’s Manual...
-
Page 27: Auxiliary Functions
Operating the product Auxiliary functions 4. Start the programme by pressing Start / Pause / Cancel key. Washing programmes of your dishwasher are designed to obtain the best cleaning effect, considering the type of the soiling, With the Half Load function you soiling degree and properties of the dishes can save both water and power to be washed. -
Page 28: Scheduling The Washing Time
Operating the product Tablet Detergent function may If the door is opened while cause change in the programme the Time Delay is active, the duration. countdown will be paused and start icon will start to flash. Scheduling the washing To exit time delay mode time without activating the Time Time Delay... -
Page 29: Starting The Programme
Operating the product Starting the programme Cancelling the programme To start your machine after selecting the Press Start/Pause/Cancel key for 3 programme and auxiliary functions, press seconds to cancel the programme. Start/Pause/Cancel key. 2. Release the key when the programme Your machine performs water indicator starts flashing. -
Page 30: End Of Programme
Operating the product End of programme stops and safety is assured, P1 icon will disappear. If P1 does not disappear, there End of Programme indicator will light up is a permanent fault. In this case the once the washing programme is over. authorised service should be contacted. -
Page 31: Maintenance And Cleaning
Maintenance and cleaning Cleaning the filters Service life of the product extends and frequently faced problems decrease if it is Clean the filters at least once a week in order cleaned at regular intervals. for the machine operates efficiently. Check Unplug the product and turn off if food residues are left on the filters. -
Page 32: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the impellers 4. Clean all three filters under tap water by means of a brush. Clean the impellers at least once a week in 5. Replace the metal/plastic filter. order for the machine operates efficiently. 6. Place the coarse filter into the Lower impeller microfilter. -
Page 33: Upper Impeller
Maintenance and cleaning Upper impeller Check if the holes on the upper impeller (1) are clogged. If they are clogged, remove and clean the impeller. Turn its nut to left to remove the upper impeller (A, B). Make sure that the nut is tightened well when installing the upper impeller. -
Page 34: Troubleshooting
Troubleshooting Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 35 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 36 Troubleshooting • Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole while adding salt. Make sure that the salt reservoir lid is tightly closed after finishing the filling process. Run the prewash programme to remove the salt that spilled inside the machine.
- Page 37 Troubleshooting • Kitchen utensils that are already corroded are washed in dishwasher. >>> Rust on a corroded item can migrate to other stainless steel surfaces and cause corrosion on those surfaces as well. Such items should not be washed in dishwashers. Detergent remains in detergent dispenser.
- Page 38 Troubleshooting A smear remains on glasses that resembles milk stain which can not be removed when wiped by hand. A bluish / rainbow appearance occurs when the glass is pointed to light. • Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when adding rinse aid.
-
Page 39: Guarantee
The cost of functional replacement • parts, but excluding consumable is recommended for all Washing items. Machines, Dishwashers and Electric The labour costs of a Beko approved Cookers • repairer to carry out the repair Gas Cookers must only be installed by •... - Page 40 If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee agreement document. Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Beko Customer Help-Line. Tel: 0845 6004911 e-mail: service@beko.co.uk...
