Craftsman CMXLHB1 Instruction Manual

3 WATT HIGH-POWERED LED
HEADLAMP WITH LED AREA LIGHTS
INSTRUCTION MANUAL
1
2
3
4
4
5
5
6
FEATURES
1. Power/light mode button
8. Back cover latch
2. Headlamp body
9. Integrated connector tape (connects the back cover
3. Adjustable head strap to the battery compartment)
4. Two white LED area lights 10. Back cover fastening buckles
5. Two red LED area lights 11. Battery compartment fastening buckle
6. 3 watt LED bulb 12. Battery compartment
7. Back cover latch release groove 13. 3 AAA Alkaline Batteries (may be sold separately)
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
Copyright © 2020 Baccus Global LLC
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
■
Increase the separation between equipment and receiver.
■
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
■
Consult the dealer or an experienced radio/TV technician for help.
■
Changes or modifications not approved by the party responsible for compliance could void user' s authority to operate the equipment.
SAFETY GUIDELINES / DEFINITIONS
DANGER:
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING:
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:
Used without the safety alert symbol indicates potentially hazardous situation which, if not avoided, may result in property damage.
RISK OF UNSAFE OPERATION.
When using tools or equipment, basic safety precautions should always be followed to reduce the risk of personal injury.
Improper operation, maintenance or modification of tools or equipment could result in serious injury and property damage. There are certain applications for which tools
and equipment are designed. Manufacturer strongly recommends that this product NOT be modified and/or used for any application other than for which it was designed.
Read and understand all warnings and operating instructions before using any tool or equipment.
READ ALL INSTRUCTIONS
WARNING:
Read all instructions before operating the LED headlamp. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
IMPORTANT SAFETY INSTRUCTIONS
GENERAL SAFETY WARNINGS AND INSTRUCTIONS
WARNING –
WHEN USING THIS HEADLAMP, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE
FOLLOWING, TO REDUCE THE RISK OF ELECTRIC SHOCK OR INJURY TO PERSONS:
Use in a dry location only.
■
To reduce the risk of injury, close supervision is necessary when the headlamp is used near children.
■
Do not put the headlamp in water or other liquid. Do not place or store the headlamp where it can fall or be pulled into water or become wet.
■
Use only attachments recommended or sold by the manufacturer.
■
Never look directly into the light or shine the light into another person' s eyes.
■
CMXLHB1_ManualENSP_042020.indd 1 CMXLHB1_ManualENSP_042020.indd 1
Keep sharp objects away from lens — it can crack or break.
■
CMXLHB1
Do not drop or throw this headlamp. It contains alkaline batteries.
■
Do not operate the light near flammable liquids or in gaseous or explosive atmospheres. Internal sparks may ignite fumes causing personal injury.
■
When not in use, the appliance should be stored in a dry, well ventilated place out of the reach of children.
■
WARNING –
FIRE HAZARD:
Keep headlamp away from materials that may burn.
■
Do not expose this unit to extremely high temperatures, sparks or flames.
■
Inspection and repairs
Before use, check the unit for damaged or defective parts. Check for breakage of parts, damage to switches and any other conditions that may affect its operation.
■
Do not use the unit if any part is damaged or defective.
■
Have any damaged or defective parts repaired or replaced by the manufacturer.
■
Never attempt to remove or replace any parts other than those specified in this manual or disassemble the main body of the unit. Other than the 3 AAA size dry cell
■
batteries, there are no user-replaceable parts.
Do not operate this unit with a missing or damaged lens.
■
ALKALINE BATTERY SAFETY INSTRUCTIONS
8
7
WARNING –
Batteries can explode, or leak, and can cause injury or fire. To reduce this risk:
Use only AAA alkaline dry cell batteries in this unit.
■
Carefully follow all instructions and warnings on the battery label and package.
■
Always insert batteries correctly with regard to polarity (+ and –), marked on the battery and the equipment.
■
Do not short battery terminals.
■
9
Do not charge batteries.
■
Do not mix old and new or alkaline, standard (carbon-zinc) and rechargeable (nickel cadmium or nickel metal hydride) batteries. Replace all of them at the same time
■
with new batteries of the same brand and type.
10
Remove dead batteries immediately and dispose of per local codes.
10
■
11
Do not dispose of batteries in fire.
■
Keep batteries out of reach of children.
■
Remove batteries if the device will not be used for several months.
12 ■
"Transporting batteries can possibly cause fires if the battery terminals inadvertently come in contact with conductive materials such as keys, coins, hand tools and the
like. The US Department of Transportation Hazardous Material Regulations (HMR) actually prohibit transporting batteries in commerce or on airplanes (i.e. packed in
13
suitcases and carryon luggage) UNLESS they are properly protected from short circuits. So when transporting individual batteries, make sure that the battery terminals are
protected and well insulated from materials that could contact them and cause a short circuit."
SAVE THESE INSTRUCTIONS
INTRODUCTION
Congratulations on purchasing your new 3 Watt High-Powered LED Headlamp with LED Area Lights . Read this Instruction Manual and
follow the instructions carefully before using your new headlamp.
POWER SUPPLY
The unit is powered by three AAA alkaline dry cell batteries (may be sold separately) inside the battery compartment.
Battery replacement/disposal
The battery compartment is located on the back of the head lamp. Refer to the illustrations at the beginning of these instructions and the steps that follow to replace the
batteries:
1. Use one hand to hold the head lamp body and place the thumb of the other hand into the back cover latch release groove. Gently lift up the back cover and push it
out by lightly applying force on the back cover latch.
2. Insert the batteries correctly according to the symbols shown inside the battery compartment, observing the cautions that follow.
3. Replace the back cover by aligning the fastening buckles between the battery compartment and back cover.
4. Snap the back cover into the head lamp body through the back cover latch.
CAUTIONS:
Always read and follow all warnings in the Alkaline Battery Safety Instructions section of this Instruction Manual before
■
replacing/disposing of the batteries in this unit.
The battery compartment inside the headlamp body is connected to the back cover by integrated connector tape. Do not damage the integrated connector tape or
■
attempt to disconnect it from either the back cover or the battery compartment at any time.
This unit may be delivered with the 3 AAA alkaline dry cell batteries already installed in the battery compartment. If so, they are protected by an insulation sheet. Make
■
sure this insulation sheet is removed before using the headlamp for the first time.
Remove batteries if the headlamp will not be used for a period of time.
■
OPERATING INSTRUCTIONS
Operating the headlamp
1. Place the headlamp on your head and adjust the strap to fit your head securely.
2. Turn the headlamp on by pressing the power/light mode button, choosing the desired light mode as follows:
Press once for high intensity on the 3W LED light bulb.
■
Press again for low intensity on the 3W LED light bulb.
■
Press a third time for the two white LED area lights.
■
Press a fourth time for the two red LED area lights.
■
Press a fifth time for to turn the headlamp off.
■
Press and hold the power/light mode button for about two seconds for flashing (SOS) mode (a continuous sequence of three short flashes/three longer flashes/three
■
short flashes). Press and hold it again for about two seconds to return to the previous operating intensity.
IMPORTANT: When the headlamp dims, the 3 AAA alkaline dry cell batteries need to be replaced.
Pivoting the headlamp main body
The headlamp body is adjustable, allowing the headlamp to be tilted forward and backward to adjust the area of illumination, as shown below:
CAUTION –
TO REDUCE THE RISK OF PROPERTY DAMAGE:
The headlamp was designed to tilt forward and backward only. Do not attempt to "force" the headlamp beyond its maximum angle.
■
The headlamp body is not designed to be detached from the head strap. Do not attempt to detach it at any time.
■
Forcibly and repeatedly tilting the headlamp forward and backward may damage the pivoting mechanism.
■
CARE AND MAINTENANCE
If the unit gets dirty, gently clean the straps of the headlamp with a soft cloth moistened with a mild solution of water and detergent. Never immerse the main light unit
(with battery case) in water or any other liquid.
TROUBLESHOOTING
The light will not operate
1. Make sure the Power/Light Mode Button is not pressed to the Off mode.
2. The batteries may be installed with incorrect polarity (+ and –). Follow the directions marked on the batteries and inside the battery compartment.
3. The batteries may be completely discharged. Replace the batteries following the directions given in this manual.
4. If the headlamp does not operate after replacing the batteries as directed, contact manufacturer at 888-331-4569.
ACCESSORIES
Recommended accessories for use with your tool may be available from the manufacturer. If you need assistance regarding accessories, please contact the manufacturer
at 888-331-4569.
WARNING:
The use of any accessory not recommended for use with this appliance could be hazardous.
SERVICE INFORMATION
Whether you need technical advice, repair, or genuine factory replacement parts, contact the manufacturer at 888-331-4569.
ONE-YEAR LIMITED WARRANTY
The manufacturer warrants this product against defects in materials and workmanship for a period of ONE (1) YEAR from the date of retail purchase by the original end-
user purchaser ("Warranty Period").
If there is a defect and a valid claim is received within the Warranty Period, the defective product can be replaced or repaired in the following ways: (1) Return the product
to the manufacturer for repair or replacement at manufacturer' s option. Proof of purchase may be required by manufacturer. (2) Return the product to the retailer where
product was purchased for an exchange (provided that the store is a participating retailer). Returns to retailer should be made within the time period of the retailer' s return
policy for exchanges only (usually 30 to 90 days after the sale). Proof of purchase may be required. Please check with the retailer for their specific return policy regarding
returns that are beyond the time set for exchanges.
This warranty does not apply to accessories, bulbs, fuses and batteries; defects resulting from normal wear and tear, accidents; damages sustained during shipping;
alterations; unauthorized use or repair; neglect, misuse, abuse; and failure to follow instructions for care and maintenance for the product.
This warranty gives you, the original retail purchaser, specific legal rights and you may have other rights which vary from state to state or province to province. This
product is not intended for commercial use.
Please complete the Product Registration Card and return within 30 days from purchase of the product to: Baccus Global LLC, 621 NW 53rd St., Suite 450, Boca Raton,
FL 33487. Baccus Global LLC, toll-free number: 888-331-4569.
SPECIFICATIONS
Light: One 3 watt LED bulb
Two white LED area lights
Two red LED area lights
Power source: 3 AAA alkaline batteries (may be sold separately)
Imported by Baccus Global LLC,
621 NW 53rd St., Suite 450, Boca Raton, FL 33487
www.Baccusglobal.com • 888-331-4569
