Summary of Contents for Cadillac Automobile

Page 121: Table Of Contents
Instruments and Controls Controls Steering Wheel Adjustment . . . 5-2 Steering Wheel Controls ..5-2 Heated Steering Wheel ..5-4 Horn ......5-4 Windshield Wiper/Washer .
Page 122: Controls
Instruments and Controls Airbag System Messages ..5-34 Anti-theft Alarm System Messages ....5-34 Tire Messages ....5-34 Transmission Messages .
Page 123 Radio To select preset or favorite radio stations: Press and release go to the next or previous radio station stored as a preset or favorite. CD/DVD To select tracks on a CD/DVD: Press and release go to the next or previous track. Navigating an iPod or USB Device on the Main Audio Screen 1.
Page 124: Heated Steering Wheel
Instruments and Controls To scan radio stations: 1. Press and hold until a beep is heard, to place the radio into SCAN mode. A station will play for five seconds before moving to the next station. 2. To stop the SCAN function, press again.
Page 125: Windshield Washer
(Adjustable Interval Wipes): Turn the band up for more frequent wipes or down for less frequent wipes. (Low Speed): Slow wipes. (High Speed): Fast wipes. (Off): Turns the windshield wipers off. Clear ice and snow from the wiper blades before using them. If frozen to the windshield, carefully loosen or thaw them.
Page 126 Instruments and Controls To adjust for compass variance, use the following procedure: Compass Variance (Zone) Procedure 1. Do not set the compass zone when the vehicle is moving. Only set it when the vehicle is in P (Park). Press the vehicle information button until PRESS CHANGE COMPASS ZONE displays.
Page 127: Calibrate Compass
cell phone antenna mount, a magnetic emergency light, magnetic note pad holder, or any other magnetic item. Turn off the vehicle, move the magnetic item, then turn on the vehicle and calibrate the compass. To calibrate the compass, use the following procedure: Compass Calibration Procedure 1.
Page 128: Cigarette Lighter
Instruments and Controls The accessory power outlets are powered, even when the ignition is in LOCK/OFF. Continuing to use power outlets while the ignition is in LOCK/OFF may cause the vehicle's battery to run down. Do not try to put the cigarette lighter in any of the accessory power outlets.
Page 129: Ashtrays
Ashtrays The front ashtray is located in the center console near the cupholders. Press on the access door to open it and use the ashtray. If papers, pins, or other flammable items are put in the ashtray, hot cigarettes or other smoking materials could ignite them and possibly damage the vehicle.
Page 130: Instrument Cluster
5-10 Instruments and Controls Instrument Cluster English Shown, Metric Similar...
Page 131: Speedometer
Speedometer The speedometer shows the vehicle speed in both kilometers per hour (km/h) and miles per hour (mph). Odometer The odometer works together with the Driver Information Center (DIC). Press the Trip/Fuel button on the instrument panel cluster to check the odometer mileage while the vehicle is not running.
Page 132: Engine Coolant Temperature
5-12 Instruments and Controls Engine Coolant Temperature Gauge This gauge shows the engine coolant temperature. If the indicator on the gauge moves towards the shaded area on the thermostat, it means that the engine coolant has overheated. If the vehicle has been operating under normal driving conditions, pull off the road, stop the vehicle and turn off the engine as soon as...
Page 133: Airbag Readiness Light
This cycle continues several times if the front passenger remains or becomes unbuckled while the vehicle is moving. If the front passenger safety belt is buckled, neither the chime nor the light comes on. The front passenger safety belt reminder light and chime may turn on if an object is put on the seat such as a briefcase, handbag, grocery bag, laptop, or other...
Page 134: Passenger Airbag Status Indicator
5-14 Instruments and Controls If there is a problem with the airbag system, a Driver Information Center (DIC) message can also come on. for more information. Passenger Airbag Status Indicator If the vehicle has the airbag status indicator pictured in the following illustration, then the vehicle has a passenger sensing system for the right front passenger position.
Page 135: Charging System Light
WARNING If the airbag readiness light ever comes on and stays on, it means that something may be wrong with the airbag system. To help avoid injury to yourself or others, have the vehicle serviced right away. See for more information, including important safety information.
Page 136 5-16 Instruments and Controls Malfunctions often are indicated by the system before any problem is apparent. Being aware of the light can prevent more serious damage to the vehicle. This system assists the service technician in correctly diagnosing any malfunction. If the vehicle is continually driven with this light on, the emission controls might...
Page 137: Emissions Inspection And Maintenance Programs
The following may correct an emission system malfunction: Check that the fuel cap is fully installed. See . The diagnostic system can determine if the fuel cap has been left off or improperly installed. A loose or missing fuel cap allows fuel to evaporate into the atmosphere.
Page 138: Brake System Warning Light
5-18 Instruments and Controls The OBD II (On-Board Diagnostics) system determines that critical emission control systems have not been completely diagnosed. The vehicle would be considered not ready for inspection. This can happen if the 12-volt battery has recently been replaced or run down.
Page 139: Antilock Brake System (Abs) Warning Light
WARNING The brake system might not be working properly if the brake system warning light is on. Driving with the brake system warning light on can lead to a crash. If the light is still on after the vehicle has been pulled off the road and carefully stopped, have the vehicle towed for service.
Page 140: Stabilitrak ® Off Light
5-20 Instruments and Controls ® StabiliTrak OFF Light This light comes on briefly while starting the engine. If it does not, have the vehicle serviced by your dealer. If the system is working normally, the indicator light then goes off. Press and release the Traction Control System (TCS)/StabiliTrak button to turn off TCS, and a...
Page 141: Engine Oil Pressure Light
When the Light Is On Steady This indicates that one or more of the tires are significantly underinflated. A Driver Information Center (DIC) tire pressure message may also display. See for more information. Stop as soon as possible, and inflate the tires to the pressure value shown on the Tire and Loading Information label.
Page 142: High-Beam On Light
5-22 Instruments and Controls If the light stays on and the engine does not start, there could be a problem with the theft-deterrent system. This light is also used to indicate the status of the anti-theft alarm system when the ignition is turned off. The light will flash rapidly if the alarm system is arming and one or more of the monitored entry points is not...
Page 143: Cruise Control Light
Cruise Control Light The cruise control light comes on whenever the cruise control is set. The light goes out when the cruise control is turned off. See for more information. Instruments and Controls Information Displays Driver Information Center (DIC) Your vehicle has a Driver Information Center (DIC).
Page 144 5-24 Instruments and Controls DIC Buttons The buttons are the trip/fuel, vehicle information, customization, and set/ reset buttons. The button functions are detailed in the following pages. (Trip/Fuel): Press to display the odometer, trip odometer, fuel range, average economy, fuel used, timer, transmission temperature, instantaneous economy, and average vehicle speed.
Page 145 Fuel Range Press the trip/fuel button until FUEL RANGE displays. This display shows the approximate number of remaining kilometers (km) or miles (mi) the vehicle can be driven without refueling. The display will show LOW if the fuel level is low. The fuel range estimate is based on an average of the vehicle's fuel economy over recent driving history...
Page 146 5-26 Instruments and Controls Instantaneous Economy If your vehicle has this display, press the trip/fuel button until INST ECON displays. This display shows the current fuel economy at a particular moment and will change frequently as driving conditions change. This display shows the instantaneous fuel economy in liters per 100 kilometers (L/100 km) or miles per gallon (mpg).
Page 147 Tire Pressure On vehicles with the Tire Pressure Monitor System (TPMS), the pressure for each tire can be viewed in the DIC. The tire pressure will be shown in either kilopascals (kPa) or pounds per square inch (psi). Press the vehicle information button until the DIC displays FRONT TIRES kPa (PSI) LEFT ## RIGHT ##.
Page 148: Vehicle Messages
5-28 Instruments and Controls Vehicle Messages Messages displayed on the DIC indicate the status of the vehicle or some action may be needed to correct a condition. Multiple messages may appear one after another. The messages that do not require immediate action can be acknowledge and cleared by pressing any DIC button.
Page 149: Door Ajar Messages
vehicle. Restart the vehicle and check for the message on the DIC display. If the message is still displayed or appears again when you begin driving, the brake system needs service. See your dealer. Door Ajar Messages DRIVER DOOR OPEN This message displays and a chime sounds if the driver door is not fully closed and the vehicle is shifted out...
Page 150: Engine Oil Messages
5-30 Instruments and Controls ENGINE OVERHEATED IDLE ENGINE If you drive the vehicle while the engine is overheating, severe engine damage may occur. If an overheat warning appears on the instrument panel cluster and/or DIC, stop the vehicle as soon as possible. for more information.
Page 151: Oil Pressure Low Stop Engine
OIL PRESSURE LOW STOP ENGINE If you drive the vehicle while the engine oil pressure is low, severe engine damage may occur. If a low oil pressure warning appears on the Driver Information Center (DIC), stop the vehicle as soon as possible. Do not drive the vehicle until the cause of the low oil pressure is corrected.
Page 152: Key And Lock Messages
5-32 Instruments and Controls Key and Lock Messages REPLACE BATTERY IN REMOTE KEY This message displays if a Remote Keyless Entry (RKE) transmitter battery is low. The battery needs to be replaced in the transmitter. See Battery Replacement under Lamp Messages TURN SIGNAL ON This message displays and a chime sounds if a turn signal is left on for...
Page 153: Service Suspension System
SERVICE SUSPENSION SYSTEM This message displays when the Road Sensing Suspension (RSS) system is not operating properly. Have your vehicle serviced by your dealer. SERVICE TRACTION CONTROL If your vehicle has StabiliTrak, this message displays when there is a problem with the Traction Control System (TCS).
Page 154: Airbag System Messages
5-34 Instruments and Controls The message turns off as soon as the conditions that caused the message to be displayed are no longer present. Airbag System Messages SERVICE AIR BAG This message displays if there is a problem with the airbag system. Have your dealer inspect the system for problems.
Page 155: Transmission Messages
come on. See . You can receive more than one tire pressure message at a time. To read the other messages that may have been sent at the same time, press the set/reset button or the trip odometer reset stem. If a tire pressure message appears on the DIC, stop as soon as you can.
Page 156: Vehicle Personalization
5-36 Instruments and Controls Vehicle Personalization Your vehicle may have customization capabilities that allow you to program certain features to one preferred setting. Customization features can only be programmed to one setting on the vehicle and cannot be programmed to a preferred setting for two different drivers.
Page 157: Auto Door Lock
ITALIANO: All messages will appear in Italian. FRANCAIS: All messages will appear in French. ESPANOL: All messages will appear in Spanish. ARABIC: All messages will appear in Arabic. CHINESE: All messages will appear in Chinese. NO CHANGE: No change will be made to this feature.
Page 158: Remote Door Lock
5-38 Instruments and Controls ALL AT KEY OUT: All of the doors, including the tailgate, will unlock when the key is taken out of the ignition. ALL IN PARK (default): All of the doors, including the tailgate, will unlock when the vehicle is shifted into P (Park).
Page 159: Exit Lighting
LIGHTS ON (default): The exterior lamps will flash when you press the unlock button on the RKE transmitter. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
Page 160: Approach Lighting
5-40 Instruments and Controls APPROACH LIGHTING This feature allows you to select whether or not to have the exterior lamps turn on briefly during low light periods after unlocking the vehicle using the Remote Keyless Entry (RKE) transmitter. Press the customization button until APPROACH LIGHTING appears on the DIC display.
Page 161: Park Tilt Mirrors
There is no default for chime volume. The volume will stay at the last known setting. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC. PARK TILT MIRRORS This feature allows you to select whether or not the outside mirror(s) will automatically tilt down when the vehicle is shifted into R (Reverse).
Page 162: Memory Seat Recall
5-42 Instruments and Controls The automatic easy exit seat movement will only occur one time after the key is removed from the ignition. If the automatic movement has already occurred, and you put the key back in the ignition and remove it again, the seat and steering column will stay in the original exit position, unless a...
Page 163: Remote Start
NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC. REMOTE START If your vehicle has this feature, it allows you to turn the remote start off or on.
Page 164: Universal Remote System
5-44 Instruments and Controls To select a setting, press the set/ reset button while the desired setting is displayed on the DIC. EXIT FEATURE SETTINGS This feature allows you to exit the feature settings menu. Press the customization button until PRESS TO EXIT FEATURE SETTINGS appears in the DIC...
Page 165 This system provides a way to replace up to three remote control transmitters used to activate devices such as garage door openers, security systems, and home automation devices. Do not use this system with any garage door opener that does not have the stop and reverse feature.
Page 166 5-46 Instruments and Controls It can usually be found where the hanging antenna wire is attached to the motor-head unit and may be a colored button. Press this button. After pressing this button, complete the following steps in less than 30 seconds.
Page 167 To program up to three devices: 1. To verify that the garage door opener is a Fixed Code unit, remove the battery cover on the hand-held transmitter supplied by the manufacturer of the garage door opener motor. If there is a row of dip switches similar to the graphic above, the garage door opener is a Fixed Code unit.
Page 168 5-48 Instruments and Controls A switch in the down position could be labeled as Down, , or Off. A switch in the middle position could be labeled as Middle, 0, or Neutral. 2. Write down the 8 to 12 switch settings from left to right as follows: When a switch is in the up...
Page 169: Universal Remote System Operation
6. Press and hold the button that will be used to control the garage door until the garage door moves. The indicator light above the selected button should slowly blink. This button may need to be held for up to 55 seconds.
Page 170 5-50 Instruments and Controls NOTES...
Page 181 Infotainment ....7-1 Theft-Deterrent Feature ..7-3 Overview ..... . 7-4 AM-FM Radio .
Page 182 All functions are available when the vehicle is parked. Do the following before driving: Become familiar with the navigation system operation, buttons on the faceplate, and touch-sensitive screen buttons. Set up the audio by presetting favorite stations, setting the tone, and adjusting the speakers.
Page 183 traffic restrictions or the latest road changes, it may suggest using a road that is now closed for construction or a turn that is prohibited by signs at the intersection. Always evaluate whether following the system's directions is safe and legal for the current conditions.
Page 184 (Power/Volume) (Eject) C. Mark Touch Screen Button (Zoom In) Touch Screen Button E. Map Scale North Up/Heading Up Symbol G. No GPS Symbol H. Full map Touch Screen Button Source (AM, FM, XM, CD, etc.) Clock Touch Screen Button K. POI (Point of Interest) Touch Screen Button (Zoom Out) Touch Screen Button...
Page 185 Q. AUDIO R. FAV (Favorite) (Phone) (Sound) U. CONFIG (Configure) V. DEST (Destination) W. RPT (Repeat) X. NAV (Navigation) To change the language of the navigation screens or to change the navigation screens from English or metric, see for more information.
Page 186 The navigation system time and the analog clock operate independently. Changing the time through the navigation system does not change the time on the analog clock. See to change the analog clock time. To set the time for the navigation system: 1.
Page 187 8. Once a street has been selected, select the House # screen button to enter the house number. The system displays the house number range that is available for the street. 9. Press GO. A map screen, with the destination marked appears. 10.
Page 188 6. Press and hold one of the screen buttons at the bottom of the screen until the name appears in the screen button on the display. The name appears in that preset destination screen button and is now available to select from the Destination Entry screen.
Page 189 1. Press to turn the audio system on and off. 2. Turn to increase or to decrease the volume. 3. Press and hold for more than two seconds to turn off the navigation system, the Rear Seat Entertainment (RSE) video screen, and Rear Seat Audio (RSA).
Page 190 If viewing a map screen, press the source screen (AM, FM, XM (if equipped), CD, etc.) button. The display splits between the audio screen and the map screen. All station-changing functions can be performed from this screen. If you do not want to view a split screen or you are not on a map screen, press AUDIO.
Page 191 XM (if equipped) lists also contain a category to select and the stations or channels that have broadcasts that relate to that category. For XM (if equipped), press the left and right arrow screen buttons to change categories. The station information appears on the display.
Page 192 The XM Tune Select menu displays with options to store by the song title or the artist's name. Up to 10 favorites by song title or artist can be saved. Press to save the song that is currently playing by the song title.
Page 193 Press this key or press CONFIG to access the Sound menu to adjust the treble, midrange, bass, fade, balance, and Digital Signal Processing (DSP). The system automatically stores audio adjustment settings as changes are made for each audio source including AM, FM, XM (if equipped), CD, and AUX.
Page 194 Centerpoint delivers five independent audio channels from conventional two channel stereo recordings (not available for AM or FM). Adjusts the audio to give the driver the best possible sound quality. Adjusts the audio to give the rear seat occupants the best possible sound quality.
Page 195 The Bose AudioPilot noise compensation technology. ® To use AudioPilot 1. Press CONFIG to enter the menu screen, then press CONFIG repeatedly until Radio is selected or press the Radio screen button 2. Press Automatic Volume Control to access the AudioPilot menu. 3.
Page 196 is a satellite radio service that is based in the 48 contiguous United States and 10 Canadian provinces. XM Satellite Radio has a wide variety of programming and commercial-free music, coast-to-coast, and in digital-quality sound. A service fee is required to receive the XM service.
Page 197 The XM receiver may have previously been in another vehicle. For security purposes, XM receivers cannot be swapped between vehicles. If this message is received after having your vehicle serviced, check with your dealer. If tuned to channel 0, this message will alternate with the XM Radio eight digit radio ID label.
Page 198: Radio Reception
Cellular phone usage may cause interference with the vehicle's radio. This interference may occur when making or receiving phone calls, charging the phone's battery, or simply having the phone on. This interference causes an increased level of static while listening to the radio.
Page 199 If the ignition or radio is turned off with a CD in the player, it stays in the player. When the ignition or radio is turned on, the CD starts playing where it stopped, if it was the last selected audio source. As each new track starts to play, the track number displays.
Page 200 2. Press the down arrow to go to the start of the current track, if more than eight seconds have played. 3. If either arrow is pressed more than once, the player continues moving backward or forward through the CD. The sound mutes while seeking.
Page 201 3. Press and hold for more than two seconds to turn off the navigation system, RSE video screen, and RSA. If the vehicle has not been tuned off, the RSE and the RSA can be turned back on by pressing this knob and will continue play of the last active source.
Page 202 Press to display the audio options. Select the audio options that best improve sound quality. This is not available on all DVDs or when the DVD is stopped. This button is not available for DVD audio. Press to playback the video with subtitles.
Page 203 Press English, French, or Spanish to change the default language that the DVD player uses for each disc. The audio language must be available on the disc. The audio language may vary for each DVD. Press English, French, or Spanish to change the default language of the subtitles that the DVD player uses for each disc.
Page 204 1. Turn counterclockwise one notch to go to the start of the current chapter/track, turn it again to go to the previous chapter/track. 2. Turn clockwise to go to the next chapter/track. Sound quality can be reduced due to disc quality, recording method, quality of the music recorded, and how the disc has been handled.
Page 205: Cd/Dvd Player
There may have been a problem while burning the CD/DVD. The label may be caught in the CD/DVD player. If the CD/DVD is not playing correctly, for any other reason, try a known good CD/DVD. If any error occurs repeatedly or if an error cannot be corrected, contact your dealer.
Page 206 The navigation audio system can control a USB storage device or an iPod by using the radio touch screens and steering wheel controls. 1. Press AUX and then the USB button. 2. Press the center screen button to enter the music navigator main screen.
Page 207 A warning message will display for a few seconds. A message to safely remove the device displays. There are guidelines that must be met, when creating an MP3 disc. If the guidelines are not met when recording a CD-R(W), the CD may not play.
Page 208 If a root directory or a folder exists somewhere in the file structure that contains only folders/subfolders and no compressed files directly beneath them, the player advances to the next folder in the file structure that contains compressed audio files and the empty folder is not displayed or numbered.
Page 209 Press to pause the CD. This button will then change to the play button. Press the play button to play the CD. 1. Press to hear the tracks in random, rather than sequential, order. 2. Press Random again to turn off random play.
Page 210: Auxiliary Devices
When playing an MP3 the rear seat operator can power on the RSE video screen and use the remote control to navigate through the MP3. The navigation system has an auxiliary input jack located on the faceplate and in the center console. This is not an audio output;...
Page 211 2. Press AUDIO then press AUDIO again, repeatedly until AUX (auxiliary) is selected or press the AUX screen button. An auxiliary device must be connected for the AUX screen button to appear as an option to select. 3. For the second row display select the Rear AUX screen button next to Rear Display 1 and for the third row display...
Page 212 The RSE system may have a Parental Control feature, depending on which radio the vehicle has. To start Parental Control, press and hold the radio power button for more than two seconds to stop all system features such as: radio, video screen, Rear Seat Audio (RSA), DVD, and/or CD.
Page 213 move too far forward or step out of the vehicle, the headphones lose the audio signal. To adjust the volume on the headphones, use the volume control located on the right side. For optimal audio performance, the headphones must be worn correctly. Headphones should be worn with the headband over the top of the head for best audio reception.
Page 214 connectors or cables (not included) may be required to connect the auxiliary device to the A/V jacks. Refer to the manufacturer s instructions for proper usage. The yellow jack (A) is for the video input. The white jack (B) is for the left audio input.
Page 215 When a device is connected to the A/V jacks, or the radio's auxiliary input jacks (front auxiliary jack or the USB port), the rear seat passengers are able to hear audio from the auxiliary device through the wireless or wired headphones as long as the rear seat audio is turned on.
Page 216 Objects blocking the line of sight could also affect the function of the remote control. If a CD or DVD is in the Radio DVD slot, the remote control (power) button can be used to turn on the video screen display and start the disc.
Page 217 continues playing in a slow play mode. Also, reverse can be played slowly by pressing the play/pause button and then pressing the fast reverse button. To cancel slow play mode, press the play/pause button. Press to return to the start of the current track or chapter.
Page 218 To change the remote control batteries: 1. Slide the rear cover back on the remote control. 2. Replace the two batteries in the compartment. Make sure they are installed correctly using the diagram on the inside of the remote control. 3.
Page 219 After stopping the player, and pushing Play, sometimes the DVD starts where it left off and sometimes at the beginning. The auxiliary source is running, but there is no picture or sound. Sometimes the wireless headphone audio cuts out or buzzes. The remote and/or the headphones are lost.
Page 220: (Rse) System
Video distortion can occur when operating cellular phones, scanners, CB radios, Global Position Systems (GPS)*, two-way radios, mobile fax machines, or walkie talkies. It might be necessary to turn off the DVD player when operating one of these devices in or near the vehicle. ®...
Page 221 Press this button to turn the RSA on or off. Turn this knob to increase or to decrease the volume of the wired headphones. The left knob controls the left headphones and the right knob controls the right headphones. Press this button to switch between the radio (AM/ FM), XM (if equipped), CD, and if...
Page 222: Rear Seat Audio (Rsa)
This section presents basic information needed to operate the navigation system. Use the buttons located on the navigation system along with the available touch-sensitive screen buttons on the navigation screen to operate the system. See for more information. Once the vehicle is moving, various functions are disabled to reduce driver distractions.
Page 223 Press to view the vehicle's current position on the map screen. Each press of this button cycles through Full Map and the tab that displays the current audio source (AM, FM, XM (if equipped), CD, etc.). Full Map displays the screen in full map view. Selecting the audio tab splits the screen between the map screen and the current audio source...
Page 224 This section includes basic information that you need to know about the map database. The maps are stored on a compact flash drive that is built into the navigation system. Road network attributes are contained in the map database for detailed areas.
Page 225 Press anywhere on the map screen and the scroll symbol appears. Use this feature to scroll across the map. Move your finger in any direction on the map screen and the map continues to scroll in that direction until you remove your finger from the screen.
Page 226 The stopover symbol displays on the map after a stopover has been added to the route. The stopover symbols are numbered one through three, depending on how many stopovers have been set. The distance to destination symbol indicates the distance to the final destination.
Page 227: System
The north up symbol indicates the map with North Up, known as North Up mode. While in North Up mode, the vehicle icon follows the north direction on the map regardless of which direction the vehicle is traveling. Press this screen symbol to switch between North Up, Heading Up, and 3-D view modes.
Page 228 Displaying POI icons on the map shows where POIs (e.g. restaurants, gas stations, etc.) are located. This screen appears after selecting the POI screen button. 1. Select one of the POI categories to display the POI icon at the top of the map screen.
Page 229: System
Press to add this POI to the address book. See Nav under for information on editing address book entries. Press to make this POI a destination or a stopover. Press to display the map showing the location of the POI. Press to dial the phone ®...
Page 230 Some major metropolitan areas may include a 3-D lane guidance feature for highway exits and junctions. This feature gives you an enhanced representation of the exits and junctions on the route. This dual screen symbol displays when the screen is in dual mode. Dual mode displays the route on half of the screen and a maneuver or Interstate Exit list on the other...
Page 231 To enter a destination by inputting the city name first: 1. Press DEST. 2. Select (Address Entry). 3. Select the state/province screen button, if needed, to change the current state or province. A list of all of the available states and provinces appear.
Page 232 3. Select the state/province screen button, if needed, to change the current state or province. A list of all of the available states and provinces appear. Select the state or province. 4. Select Street and start entering the street name or press the Last 5 Streets screen button.
Page 233 available, a list displays. If more than five are available, the List screen button displays a number. This number represents the number of available streets. Press this button to view the list and select a street. 5. Once a street has been selected, select Cross Street and start entering the cross street name.
Page 234 5. Press GO, located next to the POI. The map screen, with the destination marked displays. 6. Select the route preference for Fastest, Shortest, or Other. The system calculates and highlights the route. 7. Press Start Guidance. The route is now ready to be started. See Getting Started on Your Route in this section for more information.
Page 235 Press to access the Address Book screen. From this screen an address that already exists can be selected as the destination. To use the address book entry method: 1. Press DEST. 2. Press A list of the address book addresses display. 3.
Page 236: Destination
3. Select a previous destination from the list. Use the arrow to the right of the destination to view the entire destination name as necessary. Use the scroll arrows to the left to scroll through the list. 4. Press GO, located next to the destination.
Page 237 Press to access the Coordinates Entry screen. To use the coordinates destination entry method: 1. Press DEST. 2. Press From Map. 3. Press Map Coordinates. 4. Press Latitude and select either N (North) or S (South) to enter the direction of the latitude coordinate.
Page 238 the name that was selected for the destination when it was stored. The map screen, with the destination marked displays. 3. Select the route preference for Fastest, Shortest, or Other. The system calculates and highlights the route. 4. Press Start Guidance. The route is now ready to be started.
Page 239 downloaded, the navigation system will search for the address in the mapping disc's database. When the address is found, it will be shown on your navigation system's screen along with the buttons described below. Press GO, the navigation system calculates route(s). Select a route (i.e.
Page 240 Important Notes regarding OnStar Destination Download: If the navigation system is turned off when the destination download is attempted, the navigation system will automatically turn on and display the OnStar Destination Download Screen. The radio will remain on after the download occurs.
Page 241 Press to view the list of turn maneuvers for the entire route and to avoid turns on the route. Press the arrows to scroll through the list of maneuvers. Press this screen button, next to the adjacent street name, to avoid the maneuver.
Page 242 the current route between the start point and final destination. Once a stopover has been added, the points can be edited or deleted. To add a stopover: 1. Press DEST. 2. Press the Add Stopover screen button. This button only appears if a route has been calculated.
Page 243 Press the Add to Address Book screen button when available on POI information screens, Destination Entry screens, or POI screens. The system automatically saves this information in the address book. See Nav under for information on editing address book entries. This feature allows additions or changes one of five preset destinations.
Page 244: Configure Menu
Press CONFIG to adjust several of the system's features and preferences. The last selected CONFIG screen is the screen that displays: Sound, Radio, Nav (navigation), Display, or Time. Press CONFIG to enter the configure menu options, then press CONFIG again, repeatedly until Sound is selected or press the Sound screen button to make speaker and DSP (Digital Signal...
Page 245 Press + or to increase or to decrease the volume of the voice prompts. The system will respond with the adjusted voice level. Press On or Off to turn voice instructions on and off while traveling on a planned route. Press the Route Preference screen button to change route options when the system calculates a route.
Page 246 5. Press the Phone # screen button and use the numeric keyboard to input or change the phone number. 6. Press OK to save your changes, then press Back to return to the Address Book information screen. To change the map icon of an address book entry: 1.
Page 247: Service
1. Press the Map Database Information/Remove Map Data screen button to display the Map Coverage Area screen. 2. Press the Remove Map Data screen button to remove the map data. A screen showing, The Map can now be safely removed displays. 3.
Page 248 Three types of traffic information for major roadways are displayed on the navigation system: Unscheduled traffic incident data, such as accidents and disabled vehicles Scheduled traffic incident data, such as road construction and road closures Traffic flow information (rate of speed data) Traffic information is delivered to the vehicle by the XM Radio satellites.
Page 249 The Traffic Icon has three different condition displays. These are: No XM NavTraffic subscription. No Traffic is found in the local area. The Traffic Feature is turned off. Traffic events are in the area, but none are on route. Traffic events are on route.
Page 250 An arrow may appear before the distance. The arrow indicates the distance is a straight line distance and it shows the direction of the event from the current vehicle's position. If no arrow appears, the distance indicates how far the event is ahead on current Interstate highway or route.
Page 251 Yellow indicates slightly impaired traffic flow with average speed between 40 km/h (25 mph) and 72 km/h (45 mph). Green indicates normal traffic flow with average speed above 72 km/h (45 mph). Orange indicates construction. Traffic flow data arrows display on the map when scaled up to eight miles.
Page 252 While scrolling the map, traffic condition icons may appear. Traffic events may appear up to 75 mi (125 km) from your current position. To receive information about the traffic condition, place the cross hairs over the traffic condition icon. After pressing the INFO (information) screen button, the type of traffic condition, the street name, and a description of the traffic...
Page 253 The detailed Traffic Event screens are used to display additional details of a traffic event condition. This screen may display if: Scrolling to an event on the map and then pressing INFO. Selecting a traffic event listed on the Traffic Event List screen. The Traffic Event screen may display when approaching a traffic event.
Page 254 The RPT (Repeat) button is for navigation traffic maneuvers only. It is not used to repeat traffic prompts. During a traffic voice prompt, if RPT is pressed, the current prompt playback cancels. Traffic prompts are disabled during OnStar (if equipped) or Voice Recognition activity.
Page 255 Press CONFIG to enter the configure menu options, then press CONFIG repeatedly until Display is selected or press the Display screen button. Press this screen button to turn the display off. Press any control button to view the display. Press this screen button to change the brightness, contrast, and mode of the display.
Page 256 For more information about the Rear Vision Camera, see in the vehicle owner manual. Press the Rear Display(s) screen button to allow the choice of sources for rear display between front disc, rear aux, or usb, if connected. The navigation system time and the analog clock operate independently.
Page 257 This system may not be available or interferences may occur if any of the following are true: Signals are obstructed by tall buildings, trees, large trucks, or a tunnel. Objects are located on the front dash of the vehicle. Satellites are being repaired or improved.
Page 258 Vehicle is driving in heavy traffic where driving is at low speeds, and the vehicle is stopped and started repeatedly. See your dealer if other problems occur. Inappropriate route guidance may occur under one or more of the following conditions: You have not turned onto the road indicated.
Page 259 The navigation system's voice recognition allows for hands-free operation of the navigation system, audio system, and OnStar (if equipped) features. Voice recognition can be used when the ignition is on or when Retained Accessory Power (RAP) is active. for more information.
Page 260 The following list shows all of the voice commands available for the navigation system with a brief description of each. The commands are listed with the optional words in brackets. To use the voice commands, refer to the instructions listed previously. The following are voice tag commands that can be accessed by clearly stating the commands...
Page 261 Instructs the system to go to a specific channel on the XM band (if equipped). Instructs the system to assist with radio commands. The following are CD, MP3, and DVD commands that can be accessed by clearly stating the commands exactly as they are written.
Page 263 Press to answer incoming calls, confirm system information, and start speech recognition. Press to end a call, reject a call, or cancel an operation. A Bluetooth enabled cell phone must be paired to the Bluetooth system and then connected to the vehicle before it can be used.
Page 264 6. Repeat Steps 1 through 5 to pair additional phones. The system can list all cell phones paired to it. If a paired cell phone is also connected to the vehicle, the system responds with is connected after that phone name. 1.
Page 265 1. Press and hold two seconds. 2. Say Store. 3. Say the phone number or group of numbers you want to store all at once with no pauses, then follow the directions given by the system to save a name tag for this number.
Page 266 1. Press and hold two seconds. 2. Say Dial or Call. 3. Say the entire number without pausing, or say the name tag. Once connected, the person called will be heard through the audio speakers. The digit dial command allows a phone number to be dialed by entering the digits one at a time.
Page 267: Voice Recognition
Three way calling must be supported on the cell phone and enabled by the wireless service carrier. 1. While on a call, press 2. Say Three way call. 3. Use the dial or call command to dial the number of the third party to be called.
Page 268 The Bluetooth system can send numbers and the numbers stored as name tags during a call. You can use this feature when calling a menu driven phone system. Account numbers can also be stored for use. 1. Press . The system responds Ready, followed by a tone.
Page 453 Statement ....13-21 Your satisfaction and goodwill are important to your dealer and to Cadillac. Normally, any concerns with the sales transaction or the operation of the vehicle will be resolved by your dealer's sales or service departments.
Page 454 U.S., call the Cadillac Customer Assistance Center at 1 800 458 8006. In Canada, call the Canadian Cadillac Customer Care Centre at 1-888-446-2000. We encourage you to call the toll-free number in order to give your inquiry prompt attention.
Page 455 In the event that you do not feel your concerns have been addressed after following the procedure outlined in Steps One and Two, General Motors of Canada Limited wants you to be aware of its participation in a no-charge mediation/arbitration program. General Motors of Canada Limited has committed to binding arbitration of owner disputes involving...
Page 456 Cadillac encourages customers to call the toll-free number for assistance. However, if a customer wishes to write or e-mail Cadillac, the letter should be addressed to: Cadillac Customer Assistance Center Cadillac Motor Car Division P.O. Box 33169 Detroit, MI 48232-5169 www.Cadillac.com...
Page 457 From Puerto Rico: 1-800-496-9992 (English) 1-800-496-9993 (Spanish) From U.S. Virgin Islands: 1-800-496-9994 General Motors of Canada Limited Canadian Cadillac Customer Care Centre, Mail Code: CA1-163-005 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7 www.gm.ca 1-888-446-2000 1-800-263-3830 (For Text Telephone devices (TTYs))
Page 458 To assist customers who are deaf, hard of hearing, or speech-impaired and who use Text Telephones (TTYs), Cadillac has TTY equipment available at its Customer Assistance Center. Any TTY user can communicate with Cadillac by dialing: 1-800-833-2622. TTY users in Canada can dial 1-800-263-3830.
Page 459 Roadside Service is not a part of the New Vehicle Limited Warranty. Cadillac and General Motors of Canada Limited reserve the right to make any changes or discontinue the Roadside Service program at...
Page 460 Cadillac's exceptional Roadside Service is more than an auto club or towing service. It provides every Cadillac owner in the United States with the advantage of contacting a Cadillac advisor and, where available, a Cadillac trained dealer technician who can provide on-site service.
Page 461 Impound towing caused by violation of any laws. Legal fines. Mounting, dismounting, or changing of snow tires, chains, or other traction devices. Towing or services for vehicles driven on a non-public road or highway. Reimbursement is approximately $5 Canadian. Diesel fuel delivery may be restricted.
Page 462 For more information about the renewal of this program at the end of its term, contact the Cadillac Customer Assistance Center at 01-800-466-0805. : If unable to change a flat tire, Roadside...
Page 463 Cadillac dealership to repair the vehicle the same day, requiring the vehicle to stay at the dealership for a night or more.
Page 464 Roadside Assistance program. Any damage to the vehicle without intent, derived from the services provided. Cost of towing a trailer when choosing a Cadillac dealer that is nearest to the temporary storage facility for the disabled vehicle. Cost of all maneuvers required to access the vehicle when it is not available to be towed.
Page 465 When the vehicle requires warranty service, contact your dealer and request an appointment. By scheduling a service appointment and advising the service consultant of your transportation needs, your dealer can help minimize your inconvenience. If the vehicle cannot be scheduled into the service department immediately, keep driving it until it can be scheduled for service,...
Page 466 original receipts and can only be up to the maximum amount allowed by GM for shuttle service. In addition, for U.S. customers, should you arrange transportation through a friend or relative, limited reimbursement for reasonable fuel expenses may be available. Claim amounts should reflect actual costs and be supported by original receipts.
Page 467 Recycled original equipment parts may also be used for repair. These parts are typically removed from vehicles that were total losses in prior crashes. In most cases, the parts being recycled are from undamaged sections of the vehicle. A recycled original equipment GM part may be an acceptable choice to maintain the vehicle's originally designed appearance and safety...
Page 468 If there has been an injury, call emergency services for help. Do not leave the scene of a crash until all matters have been taken care of. Move the vehicle only if its position puts you in danger, or you are instructed to move it by a police officer.
Page 469 Service Manuals have the diagnosis and repair information on the engines, transmission, axle, suspension, brakes, electrical, steering, body, etc. Service Bulletins give additional technical service information needed to knowledgeably service General Motors cars and trucks. Each bulletin contains instructions to assist in the diagnosis and service of the vehicle.
Page 470 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying General Motors. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group...
Page 471 Transport Canada) in a situation like this, notify General Motors. Call 1-800-458-8006, or write: Cadillac Customer Assistance Center Cadillac Motor Car Division P.O. Box 33169 Detroit, MI 48232-5169 In Canada, call 1 888 446 2000, or write: Canadian Cadillac Customer Care...
Page 472 This data can help provide a better understanding of the circumstances in which crashes and injuries occur. EDR data is recorded by the vehicle only if a non-trivial crash situation occurs; no data is recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) is recorded.
Page 473 RFID technology is used in some vehicles for functions such as tire pressure monitoring and ignition system security, as well as in connection with conveniences such as key fobs for remote door locking/ unlocking and starting, and in-vehicle transmitters for garage door openers.

This manual is also suitable for:

2012 escalade ext

Save PDF
