6120EE3.31eEDQ(W)

HK7111WA

(EN) INSTRUCTION MANUAL

IO-CFS-1524 / 8508292

(04.2021 / v2)

Table of Contents

Need help?

Do you have a question about the HK7111WA and is the answer not in the manual?

Questions and answers

Summary of Contents for Juro-Pro HK7111WA

Page 1 6120EE3.31eEDQ(W) HK7111WA (EN) INSTRUCTION MANUAL IO-CFS-1524 / 8508292 (04.2021 / v2)
Page 2 DEAR CUSTOMER, The cooker is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the cooker will be easy. Before being packaged and leaving the manufacturer, the cooker was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully.
Page 3: Table Of Contents
TABLE OF CONTENT Safety instructions ......................4 Description of the appliance ..................... 9 Installation ..........................11 Operation ........................... 14 Baking in the oven – practical hints ................18 Test dishes...........................21 Cleaning and maintenance ....................23 Technical data ........................29...
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning...
Page 5 SAFETY INSTRUCTIONS Warning: Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass. Warning: Ensure that the appliance is switched off before re- placing the lamp to avoid the possibillity of electric shock.
Page 6 SAFETY INSTRUCTIONS  Always keep children away from the cooker. While in operation direct contact with the cooker may cause burns!  Ensure that small items of household equipment, including connection leads, do not touch the hot oven or the hob as the insulation material of this equipment is usually not resistant to high temperatures.
Page 7 HOW TO SAVE ENERGY Using energy in a respon-  Make use of residual heat from the sible way not only saves oven. money but also helps the If the cooking time is greater than 40 minutes environment. So let’s save switch off the oven 10 minutes before the energy! And this is how you end time.
Page 8 DISPOSAL OF THE APPLIANCE UNPACKING Old appliances should not sim- During transportation, protec- ply be disposed of with normal tive packaging was used to household waste, but should protect the appliance against be delivered to a collection and any damage. After unpack- recycling centre for electric and ing, please dispose of all electronic equipment.
Page 9: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE 3, 4 5, 6 1 Temperature control knob 2 Oven function selection knob 3, 4, 5, 6 Heating zone control knobs 7 Temperatureregulatorsignal light L 8 Cooker operation signal light R 9 Oven door handle 10 Drawer 11 Electric hob 12 Cover...
Page 10 SPECIFICATIONS OF THE APPLIANCE Cooker fittings: Grill grate Baking tray* (drying rack) Roasting tray* Sideracks *optional...
Page 11: Installation
INSTALLATION Mounting the overturning prevention Installing the cooker bracket.  The kitchen should be dry and airy and The bracket is mounted to prevent overtur- have effective ventilation according to the ning of the cooker. When the overturning existing technical provisions. prevention bracket is installed, a child who climbs on the oven door will not overturn the ...
Page 12 INSTALLATION Electrical connection Warning! All electrical work should be carried out by a suitably qualified and authorised electrician. No alterations or wilful changes in the electric- ity supply should be carried out. Fitting guidelines The cooker is manufactured to work with three–phase alternating current (400V 3N~50Hz).
Page 13 INSTALLATION CONNECTION DIAGRAM Recommen- Caution! Voltage of heating elements 230V type of connection Caution! In the event of any connection the safety lead wire must be connected to the PE terminal For 230 V earthed one–phase connection, bridges connect 1–2–3 H05VV-F3G4 terminals and 4–5 terminals, safety wire to...
Page 14: Operation
OPERATION Before first use Remove packaging, empty the drawer, clean the interior of the oven and the hob. Take out and wash the oven fittings with warm water and a little washing–up liquid. Switch on the ventillation in the room or open a window. Heat the oven (to a temperature of 250°C, for approx.
Page 15 OPERATION Rapid Preheating Oven functions and operation. Ring heater and roaster on. Use to preheat the oven. Oven with automatic air circulation (including a fan and an ultra-fan heater) Defrosting The oven can be heated up using the bottom Only fan is on and all heaters are off. and top heaters, the grill or the ultra-fan he- ater.
Page 16 OPERATION Bottom heater on Convection with ring heating ele- When the knob is set to this position ment and bottom heater on the oven is heated using only the With this setting the convection fan bottom heater. Baking of cakes from and bottom heater are on, which in- the bottom until done (moist cakes creases the temperature at the bottom...
Page 17 OPERATION Use of the grill The grilling process operates through infrared rays emitted onto the dish by the incandes- cent grill heater. In order to switch on the grill you need to:  Set the oven knob to the position marked grill ...
Page 18: Baking In The Oven - Practical Hints
BAKING IN THE OVEN – PRACTICAL HINTS Baking  we recommend using the baking trays which were provided with your cooker;  it is also possible to bake in cake tins and trays bought elsewhere which should be put on the drying rack; for baking it is better to use black trays which conduct heat better and shorten the baking time;...
Page 19 BAKING IN THE OVEN – PRACTICAL HINTS ECO Fan Heater ECO Fan Heater is an optimised heating function designed to save energy when  preparing food. You cannot reduce the cooking time by setting a higher temperature; preheating  the oven is not recommended. Do not change the temperature setting and do not open the oven door during ...
Page 20 BAKING IN THE OVEN – PRACTICAL HINTS Oven with automatic air circulation (including a fan and ring heater) Type of Type Temperature ( Level Time dish of heating (min.) Sponge cake 160 - 200 2 - 3 30 - 50 Yeast cake/ 160 - 170 25 - 40...
Page 21: Test Dishes
TEST DISHES. According to standard EN 60350-1. Baking Type of dish Accessory Level Type Temperature Baking of heating time (min.) Baking tray 28 - 32 Baking tray 23 - 26 Baking tray 26 - 30 Small cakes 2 + 4 Baking tray 2 - baking tray 27 - 30...
Page 22 TEST DISHES. According to standard EN 60350-1. Grilling Type of dish Accessory Level Type Temperature Time of heating (min.) White bread Wire rack 3 - 7 toast Wire rack + 4 - wire rack roasting tray 1st side 13 - 18 Beef burgers 3 - roasting (to gather...
Page 23: Cleaning And Maintenance
CLEANING AND MAINTENANCE By ensuring proper cleaning and mainte- Oven nance of your cooker you can have a sig- nificant influence on the continuing fault-free  The oven should be cleaned after every operation of your appliance. use. When cleaning the oven the lighting should be switched on to enable you to Before you start cleaning, the cooker must see the surfaces better.
Page 24 CLEANING AND MAINTENANCE Replacing the halogen bulb in the oven Regular inspections Before replacing the halogen bulb, make sure the appliance is disconnected from Besides keeping the cooker clean, you the electric mains to avoid a possible should: electric shock. ...
Page 25 CLEANING AND MAINTENANCE  Ovens in cookers marked with the letter D are equipped with easily removable wire shelf supports. To remove them for washing, pull the front catch, then tilt the support and remove from the rear catch. Removing wire shelf supports Installing wire shelf supports...
Page 26 CLEANING AND MAINTENANCE Removing the inner panel Door removal 1. Pull the upper door slat loose. (fig. B, C) In order to obtain easier access to the oven chamber for cleaning, it is possible to remove the door. To do this, tilt the safety catch part of the hinge upwards (fig.
Page 27 CLEANING AND MAINTENANCE 2. Pull the inner glass panel from its seat Regular inspections (in the lower section of the door). Re- move the inner panel (fig. D). Besides keeping the oven clean, you should: 3. Clean the panel with warm water with ●...
Page 28 OPERATION IN CASE OF EMERGENCY In the event of an emergency, you should:  switch off all working units of the cooker  disconnect the mains plug  call the service centre  some minor faults can be fixed by referring to the instructions given in the table below. Before calling the customer support centre or the service centre check the following points that are presented in the table.
Page 29: Technical Data
TECHNICAL DATA Electrical supply 230 / 400 V ~50Hz Maximum load 9,6 kW Electric hob HK7111WA: 14,5 cm heating zone x 2 1,0 kW 18 cm heating zone 2,0 kW 22 cm heating zone 2,0 kW Oven HK7111WA: bottom heater...
