Instruction Manual for JET Series Mixer
JET-20I, JET-30I, JET-40WI
CONTENTS
................................................................. P. 2
................................................................. P.3
................................................................. P. 4
................................................................. P. 7
................................................................. P. 8
................................................................. P.9
Mode
l #:__________________
Serial
#:__________________
Revised Date: JAN., 2015
Advertisement
Table of Contents
Summary of Contents for Metos JET Series
-
Page 1: Table Of Contents
Mode l #:__________________ Serial #:__________________ Instruction Manual for JET Series Mixer JET-20I, JET-30I, JET-40WI CONTENTS Overall View of the Mixer ……………………………………….…………….… P. 2 Installation Instructions ……………………………………..………………… P.3 Operating Instructions ……………………………………….….…………… P. 4 Cleaning Instructions …………………………………….……………….… P. 7 Maintenance ………………………………...……….………….… P. 8 Troubleshooting ……………………………………..………..…….…... - Page 2 CAUTION Read before you operate the machine It is important to read this manual and following the instructions before operate the machines. This mixer is designed as a safe and efficient food processing product as long as the machine is used in accordance with the instructions in this manual and is properly maintained.
-
Page 3: Overall View Of The Mixer
Overall View of the Mixer Model JET-30I A) Speed Control B) Planetary Shaft C) Bowl Guard D) Bowl E) Start / Stop Button F) Bowl Lift Handle G) Chute* H) Bowl Cradle I) Hand Wheel* Remark: Chute is only available for JET-30I and JET-40WI. -
Page 4: Installation Instructions
Installation Instructions INSTALLATION The machine is supplied factory lubricated and ready to run. It should be positioned on any solid, level and non-skid work surface that is nonflammable. Install in work area with adequate light and space. For Model JET-20I, you may place the mixer on bench which is capable of supporting a load of mixer’s weight. -
Page 5: Operating Instructions
Installation Instructions The mixer should be plugged into a switched socket which isolates all poles and has a minimum contact clearance of 3mm and located close to the mixer for use in an emergency and to facilitate servicing. The machine must be incorporated into a potential equalization system. The leakage current for this appliance is no greater than 1 mA/KW. - Page 6 Operating Instructions CORRECT USE OF THE MIXER It is the responsibility of the operators to use the mixer correctly within the recommended limitations. Always follow the instructions on the side of the machine when changing gear. If the motor labors, please stop the machine and reduce the size of the mix immediately. Damage resulting from improper use is will void the warranty.
- Page 7 Operating Instructions FITTING THE MIXING TOOL Slide the bayonet fitting of the agitator onto the drive shaft and twist clockwise to secure it in position. To remove the agitator, slide the tool up the shaft slightly and twist counter clockwise. Please refer to Figure 3. NOTE: Install the bowl BEFORE inserting agitators.
-
Page 8: Cleaning Instructions
Operating Instructions SPEED SELECTION Before changing speeds, the mixer must always be STOPPED first. The necessary speed can then be selected before restarting the machine by pressing the Green Start Button. The speed selected depends largely on the quantity and consistency of the product. It is recommended that mixing is always started at the lowest speed and progressively increased to the desired setting. -
Page 9: Maintenance
Maintenance It is recommended that any servicing or maintenance work must be carried out by a trained technician or electrician. CAUTION: ALWAYS DISCONNECT OR UNPLUG THE ELECTRICAL POWER FROM THE MIXER BEFORE DOING MAINTENANCE. MAINTENANCE Regular maintenance is necessary on all machines if they are to remain in good working condition. -
Page 10: Troubleshooting
Troubleshooting FAULT FINDING FAULT CHECK POSSIBLE REASON AND ACTION REQUIRED No power to mixer Check plug socket Mixer not plugged into a live socket or not switched on Check wiring in plug Plug incorrectly wired – rewire correctly Check fuse in plug Possible faulty fuse –...
