Summary of Contents for Herman Miller Echo 2G System
- Page 1 HERMAN MILLER INC page 1 of 9 Echo 2G System User Manual HMS Space Utilization Service Echo 2G System User Manual Copyright, 2010, Herman Miller Inc. Revision: 1.1...
-
Page 2: System Overview
3 to 5 weeks to capture space utilization rates. The system employs three technology tiers to capture, aggregate, and transmit workplace utilization data for analysis and trend reporting. Figure 1 Echo 2G System Diagram illustrates the relationship between those tiers. - Page 3 Motes communicate occupancy data to receivers, receivers communicate occupancy data to the Herman Miller DCS over the Internet, and the DCS stores occcupancy data in a database, where it is later used to generate customer reports.
- Page 4 In this step, Herman Miller obtains the necessary customer IT approvals if the Echo 2G system is to be connected to the customer LAN.
- Page 5 5 of 9 Important Changes not expressly approved by Herman Miller, Inc. could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 6 Connect Receiver to AC power via power adaptor Step 3. Confirm that the Receiver LCD displays the following test results in sequence within 30 seconds: host <version>…ok sbc <version>…ok radio module <version>…ok backhaul…ok network…ok Echo 2G System User Manual Copyright, 2010, Herman Miller Inc. Revision: 1.1...
- Page 7 Confirm that Mote sounds single beep tone indicating it is powered on Step 8.11 Confirm that within 3 seconds, the Mote sounds at least 3 additional beep tones, indicating Received Signal Strength (RSS) of Receiver signal is acceptable. Echo 2G System User Manual Copyright, 2010, Herman Miller Inc. Revision: 1.1...
- Page 8 2 Receivers provide acceptable RSS. Step Three: Monitor Once all equipment has been installed, data will be transmitted to Herman Miller via the Internet for analysis. A Herman Miller analyst will determine whether data is being collected properly, and may contact the customer to assist in simple troubleshooting, e.g., to check whether a receiver’s AC power plug has become unplugged.
- Page 9 Step 12. If you want to note comments either about the condition of the Receiver or its environment, type those comments in the Comments section Step 13. Click Submit Echo 2G System User Manual Copyright, 2010, Herman Miller Inc. Revision: 1.1...
