Sonken DJ Buster MDJ-003
P
S
2 W
M
MP4000 I
*
OWERED
PEAKER WITH
IRELESS
ICROPHONES AND
NCLUDED
Complete Connection Guide Contents
DJ Buster Main Unit (Powered Speaker) ..................................... 2
MP4000 Component Within DJ Buster (How To Use) ................. 6
DJ Buster Options / Accessories Available ................................ 15
1
© Copyright 2018 Karaoke Home Entertainment
www.khe.com.au
/
www.khe.co.nz
/
www.picknmix.com.au
Advertisement
Summary of Contents for Sonken DJ Buster MDJ-003
- Page 1 Sonken DJ Buster MDJ-003 MP4000 I OWERED PEAKER WITH IRELESS ICROPHONES AND NCLUDED Complete Connection Guide Contents DJ Buster Main Unit (Powered Speaker) ........2 MP4000 Component Within DJ Buster (How To Use) ....6 DJ Buster Options / Accessories Available ........ 15 ©...
- Page 2 DJ Buster Main Unit – Powered Speaker DJ Buster Powered Speaker Contents Page DJ Buster Bluetooth C onnectivity ............................. 3 Connect A Karaoke Machine ............................. 4 Play Your Music From A USB Stick ............................ 4 Wireless Microphones ..............................4 Guitar Input ..................................5 Rechargeable Battery ................................
-
Page 3: Bluetooth Connection
How to Connect / Use Your Powered Speaker The DJ Buster unit itself is a Bluetooth enabled Powered 150 Watt (RMS) speaker with 2 Wireless Microphones included and Blue LED Light Trim. The above image is the back panel of connections and controls. Connections from Other Devices You have a few options for how to connect external devices to play your music, you have Bluetooth, Audio Line Input, and USB / Mini SD Card slot. -
Page 4: Wireless Microphones
Wireless Microphones The DJ Buster MDJ-003 unit includes two Professional Wireless Microphones, so you can sing without the complication of cables in the way. The Wireless Microphones need 2x AA batteries in each microphone to operate. -
Page 5: Guitar Input
The DJ Buster MDJ-003 rechargeable battery has approx. 5 hours playing time depending on usage. Please Note: As the DJ Buster MDJ-003 has a rechargeable battery you should use it on the battery power until its flat, then recharge it to full power. If you do run it continuously on mains power, you may damage the battery and it may cease to work. - Page 6 MP4000 Component within DJ Buster MP4000 Component Contents Page How To C onnect MP4000 to DJ Buster ..........................7 MP4000 Operations ................................7 Multiplex (MPX) – Full Guide Vocals On/Off ........................8 MP4000 Bluetooth ................................8 Meet Your MP4000 Remote ............................. 9 MP4000 Functions Explained ............................
- Page 7 How to Connect Your MP4000 to the DJ Buster MDJ-003 Your DJ Buster MDJ-003 has a AUX Single Input 3.5mm Jack Plug connection for the sound, allowing you to plug in an MP4000 Karaoke Machine which is designed to fit in the slot.
- Page 8 Multiplex (MPX) – Full Guide Vocals On/Off As standard, karaoke songs show the on-screen lyrics (when played in a karaoke player like the MP4000), and plays the music, whilst you sing the main vocal and you get cover backing vocals in the chorus line and where ever else the original singer had vocals;...
- Page 9 Meet Your MP4000 Remote Power On/Off Eject the C D drive To generate a songbook Track numbers to select a particular track on a disc or enter a song number from your song book Key C ontrol, from left to right: Lower key, bring back to centre (original key) and Switch Bluetooth Mode on and off...
- Page 10 MP4000 Functions Explained USB Stick The MP4000 has a USB port for Karaoke MP3+G files to play them, record back to the USB stick, create a songbook on the USB which you can then format on your PC . The Maximum Capacity for this USB Memory Stick is 32GB, or you can plug in an external hard drive up to 1TB but it must have its own power supply and ALL Memory stick / HDDs must be formatted to FAT32 prior to being used with the MP4000, even if it was brand new.
- Page 11 Understanding the MP4000 USB Platform When you insert a USB stick (up to 32GB), you have to press the USB/SD card button on the bottom of the remote to switch to USB mode where it will show you two columns, like below. At the top you will see the currently title and artis t that you have highlighted, if you’re having trouble reading the song titles in this view, click “GUI SWITC H”...
- Page 12 Recording Assistance on MP4000 Step 1 Make sure the machine is connected (see Page 2), plug in your microphones and insert your disc/USB/SD Card. If you are singing off a disc, you will need to insert a USB as well, to record your performance to.
- Page 13 Create a Songbook on the MP4000 The Sonken MP4000 has a very useful feature, an in-built songbook generator which means you can create a printable songbook with all your songs for a super easy song selection. In order to create the song book, you must have all your songs in MP3+G format (2 files per song .cdg and .mp3) on no more than an 32GB USB stick [or up to 1TB HD with its own power supply], with no other documents [Word Files, Photos etc] present on the USB.
- Page 14 MP4000 FAQ Q: Can I plug in my hard drive? A: Yes, you can use up to a 1TB hard drive with MP3+G karaoke songs (maximum 5000 songs). The hard drive must have its own power supply and be formatted to FAT32 prior to being loaded up with songs. Q: Can I use my TV for the crowd and a monitor for the singer to see? A: Yes, you can use HDMI (sold separately) or AV yellow to a TV for the lyrics and dually use a VGA (not included) cable to a monitor for two screens simultaneously.
- Page 15 DJ Buster Options / Accessories Available 1. You can purchase the DJ Buster MDJ-003 Speaker Box with 2 Wireless Microphones on its own as a powered speaker with the empty slot (no MP4000) and just use it with your own devices via Bluetooth and AUX Input (no connection to TV unless you connect your own device to TV [dependant on your own connections]).
