SEI Lynx-CustomFit LYNX2-LC Installation Manual

ETK1123160
For your safety operation
The Lynx‐CustomFit® Splice‐On Connector is designed and
manufactured to assure personal safety. Improper operation
can result in bodily injury and serious damage to this product.
Please read and observe all warnings instructions given in this
operation manual.
Wear safety glasses to protect your eyes when
!
handling optical fiber. h dli ti l fib
Never look into the end of a microscope or optical
!
cable connected to an optical output device that is
operating. Laser radiation is invisible, and direct
exposure can severely injure the human eye.
Alcohol is flammable, causes irritation and is harmful
! !
if swallowed or inhaled. Keep alcohol away from
heat, sparks, skin, and avoid contact with eyes.
In the case of the work at the high place, please be
!
careful not to drop an assembling tool.
Composition
Di Disposable
Holder (*1)
Front Front
Housing
(*1) 1 pc / 100 connectors
Recommended Program
Splicer Fiber
T‐25eS SMF
MMF
T‐39FH SMF
MMF
T‐Q101‐CA SMF
(T‐71C)
MMF
SMF SMF : G.652, G.657 G 652 G 657
MMF : MM50(OM2), MM50(OM3), MM50(OM4), MM62.5(OM1)
North Carolina (USA)
Sumitomo Electric Lightwave Corp.
78 Alexander Drive, P.O. Box 13445, RTP, NC 27709
TEL +1‐919‐541‐8100
http://www.sumitomoelectric.com/
Copyright © 2011 Sumitomo Electric Industries, LTD.
Lynx‐CustomFit® Splice‐On Connector Ver. 2
‐ LYNX2‐LC for Optical Cord (2.4/3mm) with Duplex LC Clip‐
Furcation Furcation
Rear Rear
bl
Stopper Boot
Protection Sleeve
Ferrule
Subassembly
Splicing Program Heater Program
SM1: SMF1C Lynx
or FPS (60mm)
MM1: MMF1C
LYNX‐SM Lynx
or FPS (60mm)
LYNX‐MM
Standard SMF Lynx
or 60mm 0.9
MMF 50&62.5
London (UK)
Sumitomo Electric Europe Ltd.
220 Centennial Avenue, Elstree, Herts. WD6 3SL, UK
TEL +44 (0)20‐8953‐8118
http://www.sumielectric.com/
Installation Manual
1. Improper assembly will result in a loss of performance.
Please read instructions
and the operation manual of the fusion splicer.
2. Never touch the fiber of the
in the factory.
3. The product is sensitive to dirt or dust. Do not take out
any parts from the package any parts from the package until it is to be used.
4. The characteristic will be influenced by the fiber
cleaved surface condition. Please use a cleaver which
has a good cleaving characteristic.
5. Do not remove the dust cap until the connector has
been completely assembled
high insertion loss due to them.
B l Below tools are required.
Tube
Fiber Holder
LYNX2‐UML‐S
and Spring
Below equipments or tools are examples.
Fusion Splicer
T‐Q101‐CA, etc.
Holder Type
Please perform Arc test prior to the splicing operation.
(See the operation manual of the splicer.)
*Fiber for testing is not included in the kit.
Please check fiber type inside the field fiber.
Precautions
given in this operation manual
stub. It has been inspected
until it is to be used
in order not to cause an
Assembling Tools
l i d
Cord Tool
LYNX2‐CORDTOOL
Fiber Cleaver Jacket remover
FC‐6S‐C, etc. JR‐M03, etc.
Cleave length:
10mm
Yokohama (Japan)
Sumitomo Electric Industries, Ltd.
(Lightwave Network Products Division)
1, Taya‐cho, Sakae‐ku, Yokohama 244‐8588, Japan
TEL +81‐45‐ 853‐7223, http://global‐sei.com/fttx/
Kevlar Cutter
