USE INSTRUCTIONS UCF-000R001-GB
E-Drive sur CF80 en Anglais
Fixed rack bakery oven
UCF-000R001-GB
Control of the following functions (According to the
oven equipement) :
Steam
Exhaust vent (damper)
Hood
Energy saving
Smells absorber
Speed drive (Electric oven)
Energy saving function - Half load (Electric
oven)
Weekly planning
100 possible registered programs :
1 manual program
3 continuous baking programs
96 recipes with 6 possible phases
F.M:08/14
577, rue Célestin Hennion
59144 Gommegnies - France
Tel : (33) 03 27 28 18 18
Fax : (33) 03 27 49 80 41
http://www.eurofours.com
email:infos@eurofours.com
p: 1/41

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF80 and is the answer not in the manual?

Questions and answers

Related Manuals for Eurofours CF80

Summary of Contents for Eurofours CF80

  • Page 1 96 recipes with 6 possible phases 577, rue Célestin Hennion 59144 Gommegnies - France Fixed rack bakery oven Tel : (33) 03 27 28 18 18 Fax : (33) 03 27 49 80 41 http://www.eurofours.com email:infos@eurofours.com E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 1/41...

  • Page 2: Table Of Contents

    SIMPLIFIED USE OF THE CONTROL BOARD - - - - - - - - - - - - - - - - - - - - - - - - - p.41 The company reserves the right to change specifications without notice - Copying forbidden E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14...

  • Page 3: General Points

    Any different use will be considered improper and therfore unwise PRESENTATION OF THE CONTROL BOARD Take time to read the manual to familiarize yourself with the use of the appl E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 3/41...
  • Page 4 USB Jack authorization level Weekly programming Displaying of the oven condition Menus secured with access codes ( Example : Baking in progress ) BAGUETTES Program 1 Manufacturer menu Installer menu User settings E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 4/41...
  • Page 5 Gas or Fuel oven : 0=Yes 10=No Low speed hood Baking in progress High speed hood No baking in progress Exhaust vent open No steam injection in progress Exhaust vent (damper) closed Steam injection in progress E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 5/41...

  • Page 6: Speed Drive Option

    The values reported below are given as a guide but may slightly vary from one machine to another. No ventilation Fan operation (%) E-Drive setting range Fan operation (rev / min) E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 6/41...

  • Page 7: Access Level

    Steam Start / Stop for all the recipes for all the recipes Exhaust vent ON / OFF « » * Look at the paragraph : Fast modification of the cycle in progress E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 7/41...

  • Page 8: Use

    These information are displayed few starting-up by seconds when starting the regulator pressing the key. Then, the screen displays the last program used. BAGUETTES The rise in temperature begins immediately with the last program used. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 8/41...

  • Page 9: Recipes Selection

    SMALL BRIOCHES CONTINUOUS BAKING Baking periods can overlap. It means that three 4 BOWLS BRIOCHES successive loadings can be done with each time CONTINUOUS BAKING Select the desired recipe partial loading. IMPERATIVE E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 9/41...

  • Page 10: Baking Start And Stop

    Baking over (accumulation of the 6 duration phases). (accumulation of the remaining 3 phases). Baking stop If the door is opened during baking, the buzzer rings intermittently and the countdown is suspended. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 10/41...

  • Page 11: Use Of The Recipe "Continuous Baking

    (accumulation of the 3 loadings) CONTINUOUS BAKING Baking in progress for the 3 loadings Bell Start of the 2nd loading Start of the 3rd Baking over loading Baking stop E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 11/41...

  • Page 12: Fast Modification Of The Cycle In Progress

    • Type of energy supply to the oven Steam inject. time 10 s • Options Fan control • Current recipe Damper bef. end • Cycle progression baking Full power control Check hereafter E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 12/41...
  • Page 13 0 to 10 Yes / No Without speed drive option Full power control : Yes / No With «Half load» function Without «Half load» function Option not present Not applicable E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 13/41...
  • Page 14 As long as the initial recipe is not restored, the modified program can be used. To restore the initial recipe, press the recipe name and select it again in the recipes list or select another one (OUT OF BAKING). E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 14/41...
  • Page 15 3 loading cycles. For the recipe Even if the duration may be selected (becomes green after «CONTINUOUS pressing), it can not be BAKING» modified. Displayed only if option present E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 15/41...

  • Page 16: Postponed Starting - Weekly Planning

    Access to the weekly Press the box corresponding to the To access the settings of the desired slot, it must be enabled programming. day you want to program. (Push the icon to activate/deactivate). E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 16/41...
  • Page 17 Keying of the hour : OVEN ready to BAKE (The preheating start before this time so that the oven is hot to the scheduled time) OVEN : Keying of stop time E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 17/41...

  • Page 18: Hood Using

    The hood never stops. High speed hood Low speed hood When the control panel stops, the hood continues to run at high speed for 3mn. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 18/41...

  • Page 19: Steam Exhaust Vent (Damper) Using

    (except for the program «CONTINUOUS BAKING») Push the key to open the When pushing the key, the steam exhaust exhaust vent. vent (damper) opens, the icon becomes green and represents the open damper. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 19/41...

  • Page 20: Steam Injection

    The manual steam injection is not possible when the «CONTINUOUS BAKING» program is in progress. When the oven is not equipped with a steam system, the corresponding icon is not displayed : E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 20/41...

  • Page 21: Errors List

    COMPONENT. Thermocouple (1, 2, 3, 4) Clock Safety thermostat Burner Speed drive Front cart overheats Relay card overheats Front card T°sensor Relay card T° sensor Communication Compatibility Memory Version After-sales department E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 21/41...

  • Page 22: Energy Saving

    The oven remains energized and the Activation regulator maintains the requested temperature (here : 80°C) Press simultaneously the keys (OUT OF BAKING) To stop the «Energy saving» mode, press the key E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 22/41...
  • Page 23 <80°C. It results that the regulator automatically engages and stops heating alternately to maintain a real internal temperature around 80°C . E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14...

  • Page 24: Smells Absorber

    When the cycle is finished, the door has to be open progressively to avoid burning risks by steam. The best to do when the oven is hood equipped, is to set the door ajar and start the hood for few seconds in order to evacuate a maximum of steam. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14...

  • Page 25: Recommandations For Baking

    5 mn pastry kit» is strongly recommended. Fresh air inlet PRE BAKED BREAD allowing to avoid the humidity saturation of the air 20 mn 200°C within the baking chamber. PUFF PASTRY E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 25/41...

  • Page 26: Capacity Per Level

    Since the temperature inside the oven can reach very high values, it is FORBIDDEN to cook alcoholic products in this oven. The manufacturer will not be held responsible of possible problems in case of breaking these rules. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 26/41...

  • Page 27: Before Any Work On The Equipment

    3) Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's instructions. 4) If you cannot reach your gas supplier, call the fire department Installation and service must be performed by a qualified installer, service agency or the gas supplier. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14...

  • Page 28: Maintenance

    Periodic maintenance by a qualified technician in accordance with the service booklet, is the prerequisite for maintaining the warranty CAUTION BEFORE ANY DISMANTLING AND/OR CLEANING OPERATION PLEASE MAKE SURE THAT THE OVEN IS COLD AND POWER OFF. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 28/41...

  • Page 29: Water Quality

    The water hardness is its calcium and magnesium content. The hydrotimetric title (TH) is measured in French N.B : degrees (°f): 1°f = 4 mg of calcium + 2.4 mg of magnesium per liter. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14...

  • Page 30: Option : Minicom (Backup Controller)

    Switch-inverter The stopgap control panel is located at the front of the electric box. To reach it, take off the hood nosing, unscrew the 4 butterfly screws and remove the protection plate. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 30/41...
  • Page 31 As soon as electronic regulator is repaired, do not forget to switch the inverter on «AUTO» position. Furthermore, it is IMPERATIVE to reinstall the protection metal sheet with the 4 butterfly screws E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 31/41...

  • Page 32: Door Opening

    If for any reason, the oven is power off, the door opens itself Thus, if a postponed starting is programmed it will not start, except when the door is closed back before the programmed starting time E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14...

  • Page 33: Door Opening From The Inside Of The Oven

    It is the reason why, weekly, it is imperative to clean the door opening mechanism and control its correct operation. We could not be held responsible of any malfunctioning of the door opening mechanism if the above mentioned recommendations have not been respected E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 33/41...

  • Page 34: Changing The Light Bulbs

    1) To replace the lighting bulbs, remove the door frame (hinges side). 2) Remove the bulb and replace it. For maximum service life, use a clean, dry rag when handling the bulbs. 3) Refit the door panel then check that the light is working E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14...

  • Page 35: Problem Solving

    . On networks up to 5 bars, it is necessary to schedule a pressure regulator calibrated on (if option). 5 bars. To change the quantity of steam, increase/decrease the steam duration with the regulator. If the flow remain insufficient, contact the technical department E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 35/41...
  • Page 36 Check on the summary screen that no automatic start program was activated for the time and Unintended starting of the oven day of the unintended starting of the oven If the problem persists, contact the technical department. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 36/41...

  • Page 37: Summary Of Risks Linked With Improper Use

    With steam when opening the door. NEVER open the door during a steam injection. Wound Risks with working parts Protruding metal parts may cause cuts In order to avoid the accidents, it is imperative to wear protective gloves. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 37/41...
  • Page 38 Since the temperature inside the oven can reach very high values, it is FORBIDDEN to cook alcoholic products in this oven. The manufacturer will not be held responsible of possible problems in case of breaking these rules. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 38/41...
  • Page 39 In that case, 1 minute later, try again to ignite the burner by pressing the reset button. FOR SECURITY REASONS, THIS PERIOD CAN NOT BE SHORTENED IN ANY WAY. A yearly chimney-sweeping is IMPERATIVE. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14...
  • Page 40 Air blowers MUST NOT BE USED. To keep the room free from any explosion risk and to minimise the allergy risk, you must ensure that precautions are taken to restrict dust emissions. E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 40/41...

  • Page 41: Simplified Use Of The Control Board

    Fan control Delay before light «MANUAL» Damper bef. end Full power control 1 + 2 + 3 if : Preheating in progress : if : Baking in progress : (Phase in progress) E-Drive sur CF80 en Anglais UCF-000R001-GB F.M:08/14 p: 41/41...
