- Page 1 FireClass FC600 Panels and Repeaters User Manual 120.515.929_FC-FC600-P- Doc. version 2.0 24. March 2021...
- Page 2 © 2021 Johnson Controls. All rights reserved. All specifications and other information shown were current as of doc- ument revision date and are subject to change without notice. Tyco Fire & Security GmbH, Victor von Bruns-Strasse 21, 8212 Neuhausen am Rheinfall, Switzerland...
-
Page 3: Table Of Contents
FireClass Panels and Repeaters Contents Contents About this manual ........................5 Keywords and symbols ........................5 Who is this manual for? ........................5 What products are covered by this manual?..................5 What firmware version is covered?..................... 5 Operating instructions......................6 Indicators and controls......................... 6 Clear unexpected restart error...................... - Page 4 Contents FireClass Panels and Repeaters 4.2.2 Point I/P only............................20 4.2.3 Point O/P only ............................21 4.2.4 Zone.................................21 4.2.5 Zone Maps...............................21 4.2.6 Network Status ............................21 4.2.7 Commissioning Overview........................21 Disablements ............................21 4.3.1 Full Point ..............................22 4.3.2 Point I/P Only ............................22 4.3.3 Point O/P Only ............................22 4.3.4...
-
Page 5: About This Manual
Keywords and symbols Who is this manual for? In this manual symbols are used in the margin to indi- This manual is aimed at users of FireClass FC600 panels cate warnings and helpful information. and repeaters who have already received training. -
Page 6: Operating Instructions
Your panel version may not match the figure exactly, but the same items will be present, although perhaps not in the positions shown. Fig. 2: FireClass FC600 series panel front panel- Scandina- vian variant 1 – Colour LCD display 2 – Alphanumeric keypad 3 –... - Page 7 FireClass Panels and Repeaters Indicators and controls TEST- use to automatically inform the monitoring Usage station that the panel is in Test mode. The TEST con- Use to enter the number 1 or special sym- trol key can only be configured if the panel is con- bols.
-
Page 8: Clear Unexpected Restart Error
The date and time. information that you have requested. The panel text. Text is configurable with a limit of 19 characters. The panel text is set to FIRECLASS 2.3.6 Function key labels FC600 in the Fig. 3 example. The function key labels correspond with the function keys F1, F2, F3, F4, and F5. -
Page 9: Event Panel Behaviour
FireClass Panels and Repeaters Event panel behaviour 2.5.1 Event alerts Day mode has the following characteristics, which dif- ferentiate it from Night mode: To alert you to an event, any combination of the follow- The INVESTIGATE option is available. See section ing may occur: 2.8.1 “Alarm investigate option“... -
Page 10: Alarm Panel Behaviour
Alarm panel behaviour FireClass Panels and Repeaters Accepting an event will remove it from the Responding to an event operator window even if the event is still Optional: Press the SILENCE BUZZER control key to active. The accepted active event will still silence the buzzer while responding to an event. -
Page 11: Delays To Outputs
FireClass Panels and Repeaters Alarm operator actions DANGER state by performing a fire reset. In accordance with VDS In an alarm situation, inappropriate use 2496, type B dependency is not permitted for the trig- of the panel functions may lead to gering of fire extinguishing systems. -
Page 12: Evacuate Control Key
Alarm operator actions FireClass Panels and Repeaters SOUNDERS ON/OFF control key to enable or disable 3 In the LCD general window, note the Del mm:ss (minutes:seconds) indication. Before this delay the external sounders. If the SOUNDERS ON/OFF con- counts down to 0, press the INVESTIGATE control trol key is set to OFF, the sounders will not resound if a key. -
Page 13: Clear A System Fault On Repeater
2.8.5 Clear a system fault on repeater The following procedure details how to clear the system fault on a MT2 FireClass FC600 repeater. 1 Open the repeater door. 2 Press the Reset button inside the repeater on the CUI board, near the keyswitch shown in Fig.6. -
Page 14: Resetting The Panel
One of the signalling units available with the FC600 The FC32AR 32 zone AC Repeater is in housing that can series panels supports a Test mode option. This feature... -
Page 15: Functions
FireClass Panels and Repeaters 3 Functions Functions The control panel functions allow you to view the event The access levels are as follows: log and set the date and time. Login Level EN54-Access Level Access levels Enable Key OFF/No Logon... - Page 16 3.1 Access levels FireClass Panels and Repeaters Function See Page Login Level Enable Key 2 – Point I/P Only 1 (ON) User 3 – Point O/P Only 1 (ON) User 4 – By Function 1 (ON) User 5 – By Loop...
-
Page 17: Logging On
FireClass Panels and Repeaters 3.1 Access levels Function See Page Login Level Enable Key 3 – Diagnostics 1 (ON) Engineer 1 – Force Point 1 (ON) Engineer 3 – Shutdown/Rstart 1 (ON) Engineer 4 – Point Log 1 (ON) Engineer 5 –... - Page 18 3.1 Access levels FireClass Panels and Repeaters Automatic log off You are automatically logged off after a period of inactivity. User Manual Doc. version 2.0...
-
Page 19: Valid Values
FireClass Panels and Repeaters 3.2 Valid values Valid values Example - discovering the status of a point 1 Enter your passcode to display the Main Menu. When using the menus you will be entering various val- Note: This is not strictly necessary when viewing ues, such as point numbers. -
Page 20: Menu Details
4 Doc. version 2.0Menu details FireClass Panels and Repeaters Doc. version 2.0Menu details The sections below detail the menu options. Access the Active menu options with the alphanumeric keypad. Pre-Alarm For further information on accessing the Main Menu and viewing different menu options, see section 3.1.1... -
Page 21: Point O/P Only
FireClass Panels and Repeaters 4.3 Disablements 4.2.3 Point O/P only For each node there is an indication as follows: Use the 3 – Point O/P only option on the View Status An upper case letter indicates that communications with the node are OK. -
Page 22: Full Point
4.3 Disablements FireClass Panels and Repeaters Disabling dual input and output devices 4.3.3 Point O/P Only Some devices are both input and output Use the 3 – Point O/P Only option on the devices, on the same point address. These Disablements screen to disable only output points. -
Page 23: By Loop
FireClass Panels and Repeaters 4.4 Time/Date Disabled count Time/Date When disabling you may see a Matches and Use the 4 – Time/Date option on the Main Menu to a Successes number indicated. set the time and date settings, and review the daylight For example you might use All SND, and saving adjustment settings. -
Page 24: Print Event Log
4.6 View/Print Data FireClass Panels and Repeaters 4.5.2 Print Event Log Pts Unt./Failed Use the Pts Unt./Failed option during a Walk Test. For Use the 2 – Print Event Log option on the Event Log more information see section 4.7.1 “Walk Test” on screen to print events. -
Page 25: View Faults
FireClass Panels and Repeaters 4.7 Service Loop Point Status On printing, all the point values in the selected loop are Printer output, not just the displayed point. The Printer menu option is only available if at least one printer is configured to the panel. -
Page 26: Walk Test
4.7 Service FireClass Panels and Repeaters 4.7.1 Walk Test Type: For multiple device Area settings (such as All), Type is a filter setting to specify the type of detec- Use 1 – Walk Test on the Service screen to individu- tors to be used in a test. -
Page 27: Maintenance
Devices disappear when you test them if the test is suc- uration of the panel. Configuration information includes cessful. project information and FIRECLASS Express informa- If any devices are left in the list at the end of the test, tion. - Page 28 Use the 5 – Poll Addr 255 option on the Diagnostics work card details. screen to enable and disable polling the loop devices Note: A printer must be configured in FIRECLASS with addresses of 255. The feature is provided for com- Express before selecting this option.
-
Page 29: Calibrate Ddm
FireClass Panels and Repeaters 4.7 Service 4.7.6 Switches If more than 1 panel has been configured, provide the panel number for the panel you would like to see the Use the 6 – Switches option on the Service screen to details. -
Page 30: Panel Setup
RSM Test mode The necessary firmware and configuration files must have been placed on the USB drive using FIRECLASS Note that the RSM Test mode option may have been Express. For full details refer to the FIRECLASS Express disabled in the configuration, and so may not be pres- Help and the FireClass FC600 Series Panels Commis- ent. -
Page 31: Insert Point
FireClass Panels and Repeaters 4.8 Configuration Step through the number and letter characters on a key address, and priority of the event (as determined by with quick repeated presses. Pause after reaching the rules configured into the panel). required character. -
Page 32: Auto Config
4.9 Test Buzzer, LEDs & Display FireClass Panels and Repeaters Navigate to a point address and press Enter. The number of devices, the detector can see from The screen displays the point Description, Device Type the left- side of the loop. -
Page 33: Routine Checks
FireClass Panels and Repeaters Routine checks Routine checks General Weekly checks Completing a weekly check In order to comply with local regulations, the installation must be checked on a regular basis by a responsible 1 If necessary, clean the front panel of the fire alarm member of staff. - Page 34 FireClass Panels and Repeaters Index Index Fire Input - definition firmware - covered by guide 5 Accept Events menu option firmware version access levels Function keys active point - definition Active Points (View/Print Data) menu option Address - network and non-network...
- Page 35 FireClass Panels and Repeaters Index Panel Text menu option Test Buzzer, LEDs & Display menu item 32 passcodes – entering Point I/P Only (Isolate/De-isol) menu option Point I/P only (Status) menu item Point O/P only (Status) menu option Unaccepted events 10...
- Page 36 120.515.929_FC-FC600-P-U, doc. version 2.0, 24. March 2021 Further information about FIRECLASS can be found on the Internet at www.fireclass.com Company stamp...
