Summary of Contents for GWL GWL/Modular-BCC
- Page 1 Technical manual GWL/Modular (Batt ery Communicator and Controller) www.gwl.eu...
-
Page 2: Module Description
Module description • BCC is an expanding, independent communication unit designed exclusively for the GWL CPM, which expands the protection options and enables remote management of batteries protected by the CPM. • It contains a 10 Mbps LAN interface for remote reading and writing of parameters to the CPM and two programmable potential-free switching NO/NC relays max 30V / 1A AC/DC. - Page 3 UTP cable to the minus (-) pole and the brown and white-brown wires to the plus (+) pole: RJ-45 Pin number Designation Color Tx + Tx - Rx + PoE - PoE- Rx - PoE + PoE + www.gwl.eu...
-
Page 4: Installation
(I2C bus). All 4 COM.i2c terminals on the CPM are equipped with an optocoupler with galvanic isolati on from the BCC, so there is no risk of potenti al diff erence damage if the BCC unit is powered, for example, by a switching power supply from a source other than the CPM. www.gwl.eu... - Page 5 IP address of the BCC module into the compatible web browser (Microsoft Edge, Chrome, FireFox) – default address is http://192.168.0.100. Secure HTTPS and DHCP clients are not supported, the device must always have a static IP address. www.gwl.eu...
- Page 6 Next is displayed the last incident which caused the acti vati on of outputs Umin, Umax or Uemergency. You can see the kind of incident, which cells caused it, what was the voltage of the cell and batt ery during the incident. www.gwl.eu...
- Page 7 9. With the RESET RELAYS button, terminals 3 and 4 on Umin, Umax and Uemergency of the CPM are set to operating state (closed with GND) and GND appears on terminals 1 on Umin, Umax and Uemergency for 150 ms. www.gwl.eu...
- Page 8 Remove user name and password • • • • • • • • Password: min. 3, max 12 characters, no specials Choose a fi le Start upload Firmware Upload: Nevybrán žádný soubor All changes was saved and acti vated! BACK SAVE & BOOT www.gwl.eu...
- Page 9 TCP/IP port to it. Hacking robots will soon detect the BCC module or open port and flood it with meaningless HTTP requests so that you can no longer connect to it. For remote access to the BCC, use only a VPN or a local network separated from the Internet. www.gwl.eu...
- Page 10 I2C communication with CPM is running <status>0xFFFF</status> CPM board status (FFFF = fully functional) <relay1>SWITCHED</relay1> Relay 1 on BCC is closed (N-O = connected) <relay2>NORMAL</relay2> Relay 2 on BCC is open (N-O = disconnected) </data> end of XML file www.gwl.eu...
- Page 11 (options ON, OFF or NA, this example leaves Terminals 1 and 2 of CPM terminal block Uemergency without impulse/response) <EMER3>ON</EMER3> (options ON, OFF or NA, this example connects Terminal 3 of CPM terminal block Uemergency with GND) </IO> (end of file structure) www.gwl.eu...
- Page 12 ‘BCC + CPM’ assembly and therefore, in the extreme case, to the destruction of the connected battery. Before entering values, please double-check that the values are selected correctly and that they make logical sense. Incorrect value settings can, in extreme cases, destroy the connected battery. www.gwl.eu...
- Page 13 Switch to ON when battery voltage is> 12800 mV and switch to OFF when battery voltage is <13200 Example of correctly entered condition: Switch to OFF when battery voltage is < 10500 mV and switch to ON when battery voltage is > 11800 mV. www.gwl.eu...
- Page 14 Strongest cell voltage: 3.35V Difference Umax - Umin: 0.2V HEX timestamp: E1EAEF04 (number of seconds that have elapsed since midnight on January 1st, 1900 in the hexadecimal HEX system) Relay 1: SWITCHED (closed) position Relay 2: NORMAL (idle) position www.gwl.eu...
- Page 15 Second example of channel configuration: www.gwl.eu...
- Page 16 ‘FREE ACCESS bcc.xml file’ field. In this case, the bcc.xml file is available without authentication. The name and password can be deleted by checking the ‘Remove user name and password’ field and confirming this option with the ‘Save & Reboot’ button, or by HW reset using the DEF button. www.gwl.eu...
- Page 17 STOP button on the web interface on the title page. Wiring diagram: NOT PROTECTED BATTERY OUTPUT (use independent power suply, e.g. PoE or backup power). CELLS GWL/CPM V1.8 GWL/BCC Ucells Umin Umax Emergency COM.
- Page 18 CPM). voltage of a 12V DC coil (same as the battery) to the NC terminals of Relay 2 and we use it to control the battery charger and load (appliance). Diagram: CELLS GWL/CPM V1.8 GWL/BCC Ucells Umin Umax Emergency...
- Page 19 ‘semaphore’, turn on cell balancing, etc. PROTECTED BATTERY OUTPUT Wiring diagram of a simple local semaphore: (e.g. use emergency protection CPM). DATA COLLECTION AND ANALYSIS CELLS GWL/CPM v. 1/8 GWL/BCC Ucells Umin Umax Emergency TOTAL BATTERY...
- Page 20 The manufacturer reserves the right to change this manual or fi rmware without noti ce and assumes no responsibility for damage, injury, loss, or expenses resulti ng from an error or omission in the manual or soft ware. GWL a.s. Průmyslová 11, 102 00 Prague 10 Czech Republic, European Union...
