Automatica LINE SEIKI MB Series Quick Start Manual

MB
PREDETERMINING ELECTRIC COUNTER
4 or 5 DIGITS
PANEL MOUNT (by BAIL/CLIP)
BUILT-IN RESET GUARD
BUILT-IN SURGE PROTECTION CIRCUIT
DUSTPROOF COVER
ECONOMICAL

MODEL SELECTION

TYPE
ADDITION
PRESET COUNTER

SPECIFICATIONS

Model
Display
Power Source
Voltage Fluctuation
Power Consumption
Continuous Energizing
Counting Method
Counting Speed
Pulse Width
Make (Duty)
Reset Time
Output
Connection
Operating Temperature
Operating Humidity
Test Voltage
Insulation Resistance
Vibration
Shock
Construction
Weight
SERIES
MODEL DIGITS
MB−4111 4
MB−5111 5
MB−4211 4
MB−5211
5
MB−4111
4 (3.8 × 2.6mm)
Count : 5.0 VA (AC) ; 3.6 W (DC)
One pulse − One count (energizing − ½ count, unenergized − ½ count )
(manual)
Endurance : 16.7Hz, double amplitude 4mm
Endurance : 300 m/s² (30G)
260 grams
Automática Electrónica y Control, S.L. Lacy, 30 Acc. - 08202 Sabadell (Barcelona)
Tel 937 207 066 Fax 937 209 999 www.automatica-elec.es info@automatica.cat
RESET MODE WEIGHT
260g
MANUAL
260g
290g
ELECTRIC /
MANUAL
290g
MB−5111
5 (3.8 × 2.6mm) 4 (3.8 × 2.6mm)
DC24V, AC100/110V, AC200/220V (50 / 60 Hz)
± 10%
/ Reset : 25 VA (AC) ; 16 W (DC)
Permissible (count), less than 1 minute (reset)
10 Hz (maximum)
50msec. ON, OFF
1 : 1
1C Relay AC 250V
Screw Terminal
-5°C ~ +40°C (non-freezing)
85%RH maximum (non-condensing)
AC1,500V for 1 minute
20MΩ minimum (DC500V megger)
/ Mismovement : 10 ~ 55Hz, double amplitude 0.5mm
/ Mismovement : 50 m/s² (5G)
Gray, plastic (Noryl)
260 grams
MB−4211
MB−5211
5 (3.8 × 2.6mm)
approx. 0.5 seconds
5A
290 grams 290 grams
