Oxygen ANUBIS Manual

Power Input
Motor
Working Temperature
Relative Humidity
Open and close force 600N 800N 1000N 1200N

1. Functions

One button to control opening, stopping and closing. The light is on while opening or
closing the door, three minutes later the light is off automatically. The unit running is
controlled by a computer program. Test the force of the door's opening or closing , the
optional function is photocell, auto-close, lock door, etc. The door pauses temporarily
then rebounds when it reaches the hinders on the closing way. The protecting functions
are overload, over hot or low power input, etc.
DC motor —— Low noise, soft start, slow stopping to protect the unit and make sure it
can be used for a long time.
LED display —— Working situation can be shown on the LED screen.
Decoding —— Rolling code.
Manual Unlocking —— Open and close the door by hand without power.
Optional Functions —— Photocells, battery backup and wall button.
WARNING: IT IS VITAL FOR THE SAFETY OF ALL PEOPLE TO INSTALL AND USE THIS OPENER
FOLLOWING THE INSTALLATION INSTRUCTIONS AND SAFETY WARNINGS. FAILURE TO COMPLY MAY
LEAD TO SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE AND FAILURE OF THE OPENER
SYSTEM
ANUBIS

Technical Specifications

220V AC ±10% 50～ 60Hz
24V DC
>-20℃,<+50 ℃
≦90%
1
Reception
433.92MHz
frequency
Decoding Rolling Code
Transmitter
27A 12V Battery
power
IP20 24V 5W
Courtesy light
3 minutes
time
